🏷️ Basic Information

Make:

Mitsubishi

Model:

3000GT GTO

Year:

1993

Chassis Code:

Z16A

👋 Introduction

Positioning:

High-performance grand tourer, competing with cars like the Nissan 300ZX (Z32) and Toyota Supra (Mk IV) in its era.

Competitors:

Nissan 300ZX, Toyota Supra, Mazda RX-7

Aerodynamics:

Active aerodynamics system (Active Aero) with a deployable front lip spoiler and adjustable rear wing (on select models).

All Wheel Drive:

Advanced All-Wheel Drive (AWD) with Active Electronically Controlled Center Differential (Viscous coupling type with electronically controlled clutch pack) and electronically controlled rear differential on some models.

All Wheel Steering:

All-Wheel Steering (AWS) system, referred to as '4WS' or HICAS (High Capacity Actively Controlled Suspension) for improved maneuverability and stability at speed.

Powertrain Options:

Available in naturally aspirated and twin-turbocharged variants, offering significant performance.

📋 Manual Details

Primary Coverage:

Full Service Repair and Maintenance

Secondary Coverage:

Diagnostics, Troubleshooting, Electrical Systems, Wiring Diagrams

Estimated Page Count:

Highly comprehensive, likely exceeding 1500 pages based on typical full service manuals for this era.

Type:

Full Service Repair Manual

Language:

English

Digital Format:

PDF Download

Method:

Instant Download

📖 Manual Coverage

Powertrain:

Engine mechanical, fuel system, ignition system, exhaust system, cooling system, lubrication system

Drivetrain:

Transmission (manual & automatic), drivetrain components (driveshafts, differentials), all-wheel-drive system (if applicable)

Chassis And Suspension:

Front suspension, rear suspension, steering system, wheels, tires, brakes

Electrical:

Starting and charging system, lighting system, instrument panel, body electrical, audio system, climate control electrical

Body And Interior:

Body construction, exterior panels, interior trim, seats, glass, doors, locks

Interior Systems:

Climate control system (HVAC), power windows, power seats, power mirrors, central locking, interior lighting, dashboard illumination, warning lights.

Maintenance:

Routine maintenance, fluid changes, filter replacements, scheduled service intervals

Repair:

Component removal, disassembly, inspection, repair, reassembly, installation

Diagnostics:

Troubleshooting guides, fault code interpretation, diagnostic procedures for all major systems

Technical Specifications:

Torque specifications, clearances, measurements, tolerances

Rebuild:

Detailed procedures for engine rebuilds, transmission overhauls, differential rebuilds, and suspension component rebuilds.

Depth:

Comprehensive, suitable for professional technicians and advanced DIY enthusiasts. Covers detailed rebuild procedures.

Wiring Diagrams:

Comprehensive, fully detailed wiring diagrams for all electrical systems, color-coded for ease of tracing.

Troubleshooting Charts:

Extensive troubleshooting charts that guide technicians through diagnosing symptoms, identifying causes, and performing corrective actions.

📊 Manual Specifications

Format:

PDF

Printability:

Full Printable

Binding:

Digital (Downloadable PDF)

Digital Medium:

Electronic Storage (Hard Drive, CD-ROM)

Software Requirements:

Adobe PDF Reader, WinRAR (for potential archive extraction)

Operating Systems:

All Versions of Windows & Mac

⚙️ Engine Specifications

Engine Code:

6G72

Engine Type:

60-degree V6, SOHC or DOHC (depending on trim)

Displacement:

3.0 Liters (2972 cc)

Naturally Aspirated Horsepower:

Approx. 222 hp @ 6000 rpm (NA models)

Twin Turbo Horsepower:

Approx. 300 hp @ 6000 rpm (Twin-Turbo models)

Twin Turbo Torque:

Approx. 307 lb-ft @ 4500 rpm (Twin-Turbo models)

Fuel Delivery:

Multi-point Fuel Injection (MPI)

Recommended Fuel:

Premium Unleaded Gasoline (91 octane or higher)

Timing Belt Replacement Interval:

Recommended every 60,000 - 90,000 miles or 6-8 years, depending on operating conditions. Critical maintenance item.

🔧 Transmission

Manual Transmission:

5-speed manual (on some NA and Twin-Turbo models)

Automatic Transmission:

4-speed automatic with electronically controlled torque converter lock-up (on some NA models)

Active Aero Integration:

The manual will detail the operation and servicing of the active aerodynamics system, including actuators and control modules.

📐 Dimensions

Length:

Approx. 4,620 mm (181.9 in)

Width:

Approx. 1,840 mm (72.4 in)

Height:

Approx. 1,250 mm (49.2 in) (Twin-Turbo, lower due to styling)

Curb Weight:

Varies by model, but Twin-Turbo AWD models can exceed 3,800 lbs (1724 kg).

Wheelbase:

Approx. 2,450 mm (96.5 in)

🛡️ Safety Features

Crash Test Data:

While specific official ratings for 1993 may vary by region, contemporary performance cars were subject to various safety evaluations. The manual would provide structural details and potential weak points for repair.

Anti Lock Brakes:

Standard ABS on most models.

Traction Control:

Active Skid Control (ASC) on Twin-Turbo models.

Airbags:

Driver's side airbag standard.

Seatbelts:

Pretensioner seatbelts.

💡 Technology Features

Audio System:

Factory radio/cassette player, potentially with CD changer compatibility. Manual provides wiring and servicing information.

Cruise Control:

Electronic cruise control system.

Climate Control:

Automatic climate control system on higher trims, often with electronic controls.

Diagnostics Ports:

OBD-I diagnostic port, requiring specific diagnostic tools or methods for engine management troubleshooting. Manual details these procedures.

🔧 Maintenance

Oil Change:

Every 3,750 - 5,000 miles or 6 months, or based on oil condition monitoring.

Engine Air Filter:

Inspect every 7,500 miles, replace as needed or every 15,000 miles.

Cabin Air Filter:

Inspect every 7,500 miles, replace as needed or every 15,000 miles (if equipped).

Engine Oil:

API SG or SH, SAE 10W-30 or 10W-40 recommended. Consult manual for exact viscosity based on temperature.

Coolant:

Ethylene glycol-based coolant (long-life type), typically a 50/50 mix with distilled water. Consult manual for specific type and capacity.

Transmission Fluid Manual:

API GL-4, SAE 75W-90 gear oil.

Transmission Fluid Automatic:

Diamond SP-III ATF or equivalent. Consult manual for exact specification and capacity.

Power Steering Fluid:

Dexron II or equivalent ATF. Consult manual for exact specification.

Turbo Maintenance:

Turbocharger health is critical. Regular oil changes, proper warm-up/cool-down procedures are essential. Manual covers turbocharger servicing and diagnostics.

Hicas System:

Potential for issues with the HICAS system (wear, fluid leaks, electrical faults). Manual provides diagnostic and repair procedures.

Active Aero:

The active aero system can experience actuator failures or linkage binding. The manual details its maintenance and troubleshooting.

Exhaust System:

Exhaust manifold cracks on some earlier twin-turbo models, leading to boost leaks and performance degradation. Manual details inspection and repair.

Clutch Wear:

Standard wear item for manual transmission vehicles. Manual covers clutch inspection, replacement, and related components.

📚 Vehicle History

Brand Focus:

Mitsubishi has a history in motorsport and performance vehicles, carrying this expertise into the 3000GT.

Generation:

First generation (Z16A), introduced in 1990 globally, with the 1993 model representing an evolution of the initial design.

Manufacturing Location:

Japan

Model Naming:

Sold as the Mitsubishi GTO in Japan and the Mitsubishi 3000GT in export markets.

🏆 Awards & Recognition

Automotive Journalism:

Consistently received positive reviews from automotive press for its technological advancements and performance in its class during the early to mid-90s.
