Mitsubishi Endeavor 2004-2010 Full Service Repair Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

The Endeavor is a mid-size crossover SUV produced for the North American market from 2004 to 2011. Built on the PS platform, it is powered by a 3.8-liter V6 engine,...

29 people are viewing this right now

类型: Car

斯库: 57779

标签: 2004 2005 2006 2007 2008 2009 2010 Car Cars Endeavor Featured Mitsubishi

产品多属性

Description

The Endeavor is a mid-size crossover SUV produced for the North American market from 2004 to 2011. Built on the PS platform, it is powered by a 3.8-liter V6 engine, offering 215 to 225 horsepower depending on the model year. Known for its spacious interior, comfortable ride, and distinctive styling, the Endeavor was available with both front-wheel drive and an electronically controlled all-wheel drive system. Its robust engineering and focus on practicality positioned it as a competitive option within its segment, appealing to families and individuals seeking a versatile vehicle. This comprehensive service repair manual covers the Endeavor models from 2004 through 2010. It provides detailed information on all major systems, including powertrain, chassis, electrical, and body. Within its pages, you will find essential maintenance procedures, diagnostic troubleshooting guides, repair instructions, and technical specifications. This manual is designed to assist owners, mechanics, and technicians in performing routine maintenance, diagnosing issues, and completing repairs accurately and efficiently, ensuring the continued reliability and performance of the vehicle.

🏷️ Basic Information

Identification

Make:

Mitsubishi

Model:

Endeavor

Model Years Covered:

2004, 2005, 2006, 2007, 2008, 2009, 2010

Codes

Platform:

Mitsubishi PS platform (shared with Mitsubishi Airtrek/Outlander)

👋 Introduction

Market Position

Vehicle Segment:

Mid-size crossover SUV

Competitive Analysis

Key Competitors:

Ford Edge, Toyota Highlander, Honda Pilot, Nissan Murano, Chevrolet Equinox.

Key Features

Vehicle Selling Points:

Spacious interior, available all-wheel drive (AWD), comfortable ride, distinctive styling for its era.

Manual Value Proposition

Benefit To Owner:

Empowers owners and technicians with in-depth knowledge for efficient maintenance, accurate diagnostics, and successful repairs, saving time and money.

📋 Manual Details

Coverage Areas

Primary Coverage:

North America (USA, Canada)

Page Count

Estimated Page Count:

Varies by specific edition, typically 1000+ pages for comprehensive manuals

Manual Type

Type:

Full Service Repair Manual

Language

Language:

English

Format

File Format:

📖 Manual Coverage

Systems Covered

Powertrain:

Engine mechanical, fuel system, ignition system, exhaust system, cooling system, lubrication system, engine control system (ECU), transmission (automatic), transaxle.

Chassis:

Suspension (front and rear), steering system, brake system (including ABS), wheels and tires.

Electrical:

Charging system, starting system, lighting, instruments and indicators, body electrical, power accessories, HVAC controls, infotainment system, airbags, wiring diagrams.

Body:

Body construction, interior trim, exterior trim, doors, windows, seats, safety restraints.

Procedures Included

Maintenance:

Scheduled maintenance, fluid changes, filter replacements, belt inspections, spark plug replacement, brake pad/rotor replacement, tire rotation.

Diagnostics:

Troubleshooting guides, diagnostic trouble codes (DTCs), electrical system diagnostics, component testing.

Repair:

Engine overhaul, transmission repair, suspension component replacement, brake caliper replacement, electrical component repair, body panel repair, interior component replacement.

Technical Depth

Depth:

Comprehensive, covering detailed repair procedures, specifications, diagnostic information, and wiring diagrams. Suitable for professional technicians and advanced DIY mechanics.

📊 Manual Specifications

File Format

Print Quality:

Full Printable (High Resolution)

Delivery

Delivery Method:

Instant Download

Requirements

Software Requirements:

Adobe PDF Reader, WinRAR (for extraction if applicable)

Compatibility

Operating Systems:

All versions of Windows and Mac OS

Binding Type

Binding:

Not Applicable (Digital Format)

Paper Type

Paper Type:

Not Applicable (Digital Format)

⚙️ Engine Specifications

Primary Engine

Engine Type:

6G72 SOHC V6

Displacement:

3.8 Liters (3828 cc)

Bore X Stroke:

91.1 mm x 95.0 mm

Compression Ratio:

9.5:1

Performance

Horsepower 2004-2006:

215 hp @ 5750 rpm

Torque 2004-2006:

255 lb-ft @ 3750 rpm

Horsepower 2007-2010:

225 hp @ 5750 rpm

Torque 2007-2010:

257 lb-ft @ 3750 rpm

Fuel System

Fuel Delivery:

Multi-point Fuel Injection (MPI)

Fuel Type:

Unleaded gasoline, 87 octane (minimum recommended)

Engine Management

ECU Type:

Mitsubishi Electronic Control Unit (ECU)

🔧 Transmission

Standard

Transmission Type:

F4A51 4-speed automatic with Active Adaptive Control (ACD)

Optional

Drive Type:

Front-Wheel Drive (FWD) or All-Wheel Drive (AWD)

Features

AWD System:

Electronically controlled all-wheel drive (provides power to rear wheels as needed).

📐 Dimensions

Exterior

Length:

Approx. 192.1 inches (4880 mm)

Width:

Approx. 73.0 inches (1854 mm)

Height:

Approx. 66.7 inches (1694 mm)

Wheelbase:

Approx. 110.0 inches (2794 mm)

Weights

Curb Weight FWD:

Approx. 4,123 lbs (1870 kg)

Curb Weight AWD:

Approx. 4,321 lbs (1960 kg)

🛡️ Safety Features

Ratings

NHTSA Front Impact Driver:

5-Star (2004 models)

NHTSA Front Impact Passenger:

5-Star (2004 models)

NHTSA Side Impact Front Driver:

5-Star (2004 models)

NHTSA Side Impact Front Passenger:

5-Star (2004 models)

NHTSA Side Impact Rear Driver:

5-Star (2004 models)

NHTSA Side Impact Rear Passenger:

5-Star (2004 models)

Active Features

Standard Anti-lock Braking System (ABS)

Traction Control:

Available Traction Control System (TCS)

Passive Features

Airbags:

Front airbags, available side curtain airbags.

💡 Technology Features

Infotainment

Audio System:

Available premium audio systems with CD player, and optional SiriusXM satellite radio. Navigation systems were optional on higher trims.

Driver Assistance

Cruise Control:

Standard cruise control system.

Connectivity

Auxiliary Input:

Optional auxiliary audio input jack on later models.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 miles or 6 months (whichever comes first), using synthetic blend or full synthetic oil.

Engine Coolant Change:

First at 105,000 miles, then every 52,500 miles thereafter.

Transmission Fluid Change:

Every 60,000 miles (using specified ATF).

Fluid Specifications

Engine Oil Viscosity:

SAE 5W-30

Engine Oil Capacity:

Approximately 4.5 quarts (4.3 liters) with filter change.

Transmission Fluid Type:

DIA QUEEN ATF SP-III (or equivalent specification)

Power Steering Fluid:

Dexron III ATF (or equivalent specification)

Brake Fluid:

DOT 3

Known Issues

Common Problems:

Transmission solenoid issues, wheel bearing wear, ABS sensor failures, interior trim rattles, HVAC blower motor resistor failures.

Engine Performance Tips:

Regular maintenance of the cooling system and timely replacement of the serpentine belt are crucial for optimal V6 engine performance.

📚 Vehicle History

Brand Heritage

Manufacturer Legacy:

Mitsubishi Motors Corporation, a Japanese multinational automotive manufacturer with a history of producing robust and reliable vehicles, particularly SUVs and performance cars.

Model Evolution

First Generation:

The Endeavor was introduced for the 2004 model year as Mitsubishi's entry into the North American mid-size SUV market, designed specifically for this region.

Facelift Updates:

Received a minor facelift for the 2007 model year, featuring updated styling, interior refinements, and powertrain enhancements.

Production

Manufacturing Location:

Normal, Illinois, USA (at Mitsubishi Motor Manufacturing of America, Inc. - MMMA)

Production End Year:

🏆 Awards & Recognition

Recognitions

Safety Awards:

Received 5-star safety ratings from NHTSA for front and side impacts in early models, indicating strong structural integrity and safety system performance.
