2004 Mitsubishi Grandis Workshop Repair Service Manual in Best

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Mitsubishi Model: Grandis Year: 2004 Codes Chassis Code: NA4W Engine Code: 4G69 (for most markets) 👋 Introduction Market Position Vehicle Segment: Compact/Mid-size MPV (Multi-Purpose Vehicle)...

28 people are viewing this right now

类型: Car

斯库: 586011

标签: 2004 Car Cars Grandis Mitsubishi

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Mitsubishi

Model:

Grandis

Year:

Codes

Chassis Code:

Engine Code:

4G69 (for most markets)

👋 Introduction

Market Position

Vehicle Segment:

Compact/Mid-size MPV (Multi-Purpose Vehicle) / Minivan

Target Audience:

Families, individuals seeking versatile and practical transportation.

Competitive Analysis

Key Competitors:

Toyota Sienna, Honda Odyssey, Nissan Quest, Kia Sedona, Ford Freestar (market dependent).

Key Features

Seating Capacity:

Typically 6 or 7 passengers.

Door Configuration:

Typically four doors and a rear liftgate (no sliding doors on most models).

Styling Design:

Distinctive 'face-forward' design with a flowing aerodynamic profile.

📋 Manual Details

Coverage Areas

Market Coverage:

Global (primarily Japanese Domestic Market and export markets)

Trim Level Coverage:

All trim levels

Page Count

Estimated Page Count:

1000+

Manual Type

Manual Type:

Comprehensive Workshop Repair Service Manual

Source Type:

Likely a factory service manual or a highly reputable aftermarket equivalent.

Language

Language:

English (with potential for original Japanese diagrams/schematics)

Format

Format:

Digital (PDF)

File Format

Digital Format:

PDF (Portable Document Format)

Print Quality

Digital Quality:

High-resolution scans, clear text, and legible diagrams/illustrations.

Binding Type

Digital Accessibility:

Searchable text for quick information retrieval.

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Complete overhaul procedures, cylinder head, block, crankshaft, pistons, connecting rods, timing system, lubrication system, cooling system.

Engine Performance:

Fuel injection system, ignition system, emission control system, diagnosis and troubleshooting.

Transmission Manual:

Service and repair of manual transmission (if applicable to specific models/markets).

Transmission Automatic:

Service and repair of INVECS-II or INVECS-III automatic transmission, torque converter, hydraulic control, electronic control unit (ECU) diagnosis.

Drivetrain:

Front-wheel drive (FWD) and All-Wheel Drive (AWD) systems, differential, drive shafts, CV joints, rear axle assembly.

Suspension:

Front suspension (McPherson strut), rear suspension (multi-link), shock absorbers, springs, control arms, bushings, wheel alignment specifications.

Steering:

Power steering system, steering gear, steering column, hydraulic pump, fluid specifications, troubleshooting.

Brakes:

Front and rear disc brakes, ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution), brake fluid specifications, bleeding procedures, caliper and rotor replacement.

Electrical System:

Battery, charging system (alternator), starting system (starter motor), lighting system, horn, power windows, mirrors, locks, wipers, HVAC blower motor.

Engine Control System:

ECU (Engine Control Unit), sensors (MAP, TPS, O2, Crankshaft Position, Camshaft Position, Coolant Temperature), actuators (injectors, ignition coils), diagnostic trouble codes (DTCs).

Body And Interior:

Body panel removal and installation, interior trim, seats, dashboard, door panels, bumpers, glass replacement, weatherstripping.

HVAC:

Heating, Ventilation, and Air Conditioning (HVAC) system, refrigerant R134a, compressor, condenser, evaporator, climate control unit, troubleshooting.

Safety Systems:

Airbag system (SRS - Supplemental Restraint System), seatbelt pre-tensioners, diagnostic procedures.

Procedures Included

Preventive Maintenance:

Oil change intervals, filter replacements (oil, air, cabin), spark plug replacement, coolant flush, brake fluid flush, timing belt inspection/replacement (if applicable).

Troubleshooting:

Systematic diagnostic procedures for common and uncommon faults, symptom-based troubleshooting guides, wiring diagrams for pinpoint diagnostics.

Repair And Rebuild:

Step-by-step instructions for component removal, installation, overhaul, and rebuilding of major and minor assemblies.

Component Replacement:

Detailed instructions for replacing parts such as alternators, starters, radiators, fuel pumps, sensors, actuators, brake components, suspension parts.

Wiring Diagrams:

Comprehensive electrical schematics for all vehicle systems, including power distribution, signal paths, and ground points.

Torque Specifications:

Precise torque values for all critical fasteners, engine components, suspension parts, and body hardware.

Technical Depth

Diagnostic Capability:

Advanced diagnostic information, including scan tool data interpretation, specific sensor readings, and parameter analysis.

Rebuild Depth:

Full rebuild procedures for engines, transmissions, and other major mechanical components, including machining specifications.

Specification Accuracy:

Highly detailed technical specifications for all parts, fluids, and operational parameters.

⚙️ Engine Specifications

Primary Engine

Engine Name:

2.4L 16-Valve DOHC MIVEC Inline-4

Engine Code:

Performance

Horsepower Bhp:

Approximately 165-170 hp @ 6000 rpm (market dependent).

Torque Lb Ft:

Approximately 161-166 lb-ft @ 4000 rpm (market dependent).

Engine Technology:

MIVEC (Mitsubishi Innovative Valve timing Electronic Control) for improved performance and efficiency.

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI), Multi-point Injection (MPI).

Fuel Type:

Unleaded gasoline.

Engine Layout

Configuration:

Inline-4 cylinder, front-engine, transverse mount.

Engine Capacity

Displacement:

2378 cc

🔧 Transmission

Standard

Transmission Type:

INVECS-II or INVECS-III 4-speed or 5-speed Automatic Transmission.

Optional

Transmission Type:

5-speed Manual Transmission (less common in some markets).

Features

Drive Modes:

Available Sport Mode or 'Shift Logic' for adaptive transmission control.

Fluid Specifications

Automatic Transmission Fluid:

Mitsubishi DIAQueen ATF SP-III or equivalent.

📐 Dimensions

Exterior

Length:

Approx. 4640 mm (182.7 in)

Width:

Approx. 1775 mm (69.9 in)

Height:

Approx. 1660 mm (65.4 in)

Wheelbase:

Approx. 2830 mm (111.4 in)

Weights

Curb Weight:

Approx. 1600-1750 kg (3527-3858 lbs) depending on configuration.

Gross Vehicle Weight Rating:

Varies by market and configuration.

Cargo

Cargo Volume:

Flexible seating arrangements and cargo space, often with foldable rear seats.

🛡️ Safety Features

Ratings

Crash Test Data:

Refer to JNCAP, Euro NCAP, or NHTSA for specific ratings applicable to the region of sale.

Active Features

Standard Anti-lock Braking System.

Standard Electronic Brakeforce Distribution.

Traction Control:

Optional Traction Control System (TCL) or Active Stability Control (ASC) depending on trim.

Passive Features

Airbags:

Front airbags (driver and passenger), optional side airbags and curtain airbags.

Seatbelts:

Three-point seatbelts with pre-tensioners and force limiters for front seats.

Child Seat Anchors:

ISOFIX or LATCH compatible child seat mounting points.

💡 Technology Features

Infotainment

Audio System:

Factory-installed audio system with CD player, AM/FM radio. Higher trims may feature premium sound systems and subwoofer.

Navigation:

Optional factory or aftermarket navigation systems.

Driver Assistance

Cruise Control:

Standard cruise control on most models.

Connectivity

Auxiliary Input:

May feature an auxiliary audio input jack on some units.

🔧 Maintenance

Service Intervals

Engine Oil Change:

Typically every 7,500 - 10,000 miles (12,000 - 16,000 km) or 6-12 months, whichever comes first (check manual for specific intervals).

Air Filter Replacement:

Approximately every 30,000 miles (48,000 km) or as needed based on driving conditions.

Cabin Air Filter Replacement:

Typically every 15,000 - 30,000 miles (24,000 - 48,000 km) or annually.

Spark Plug Replacement:

Depending on plug type (Iridium/Platinum), intervals can range from 60,000 to 100,000 miles (96,000 to 160,000 km).

Transmission Fluid Change:

Automatic transmission fluid change recommended every 30,000 - 60,000 miles (48,000 - 96,000 km) depending on driving severity.

Fluid Specifications

Engine Oil Type:

SAE 5W-30 or 5W-40, API SN/SM or ILSAC GF-5/GF-4 compatible (check manual for exact specification).

Engine Coolant:

Long-life ethylene glycol based coolant, typically pink or red in color. Capacity approx. 7.0-7.5 liters.

Brake Fluid:

DOT 3 or DOT 4 brake fluid.

Power Steering Fluid:

Power steering fluid or ATF Dexron II/III compatible (check manual).

Known Issues

Engine:

Potential for oil consumption over time, ignition coil failures, MIVEC system issues if maintenance is neglected.

Transmission:

Occasional rough shifting or transmission control module (TCM) faults, especially with higher mileage or poor maintenance.

Suspension:

Wear on suspension bushings, ball joints, and sway bar links can lead to clunking noises and poor handling.

Electrical:

Window regulator failures, issues with power door locks, and corrosion on electrical connectors can occur.

📚 Vehicle History

Brand Heritage

Mitsubishi Motors Legacy:

Mitsubishi Motors has a long history in automotive manufacturing, known for robustness and engineering. The Grandis continues this lineage in the MPV segment.

Model Evolution

Predecessor:

Successor to the Mitsubishi Space Wagon/Chariot.

Generation Designation:

First generation (2003-2011).

Production

Manufacturing Plant:

Mizushima Plant, Kurashiki, Okayama, Japan.

Production Years:

2003-2011.

🏆 Awards & Recognition

Recognitions

Jnc Award:

The Mitsubishi Grandis achieved a 5-star rating in the Japan New Car Assessment Program (JNCAP) for safety in some configurations.

Ratings

Euro Ncap:

Refer to specific market's Euro NCAP results for applicable safety ratings.
