Market Segment:
Subcompact hatchback, known for its unique, boxy design and practical interior space.
Competitors:
Honda Fit, Toyota Yaris, Scion xB.
Unique Selling Points:
Distinctive asymmetrical interior design, exceptionally flexible seating (e.g., 'Kira Kira' mode), compact exterior dimensions with surprisingly spacious interior.
Diy Advantage:
Empowers DIY enthusiasts with factory-derived information, enabling cost savings on repairs and maintenance.
Convenience:
Online access provides immediate and convenient access to critical repair data, superior to outdated printed manuals.
Coverage:
Comprehensive service and repair information for the 2009 Nissan Cube.
Page Count:
N/A (Digital - Full Year Access)
Manual Type:
Online Service and Repair Manual Software
Format:
Web-based Software (PC, Laptop, Smartphone, Tablet Compatible)
Engine Systems:
Engine mechanical, lubrication, cooling, fuel, ignition, emissions control, starting and charging.
Transmission Systems:
Automatic transmission (CVT) service, diagnosis, and repair.
Drivetrain Systems:
Front-wheel drive, axle shafts, differentials.
Suspension Systems:
Front and rear suspension components, alignment, shock absorbers, struts.
Steering Systems:
Power steering system, steering gear, steering column.
Brake Systems:
Front and rear brakes (disc/drum), ABS, brake hydraulics, parking brake.
Electrical Systems:
Wiring diagrams, lighting, instruments, power distribution, starting/charging, body electrical.
Climate Control Systems:
Heating, ventilation, and air conditioning (HVAC) system diagnosis and repair.
Body And Interior Systems:
Body panels, doors, windows, interior trim, seating systems.
Maintenance Procedures:
Scheduled maintenance, oil changes, filter replacements, fluid checks, spark plug replacement.
Repair Procedures:
Component removal and installation, brake caliper replacement, CV joint boot replacement, radiator service.
Diagnostic Procedures:
Troubleshooting guides, fault code interpretation (where applicable), symptom-based diagnostics.
Depth:
Factory-level detail for diagnosis, repair, and maintenance.
Engine Type:
Inline 4-cylinder, DOHC, 16-valve
Displacement:
1.5 Liters (1498 cc)
Horsepower:
Approximately 109 hp @ 6000 rpm (JDM Spec)
Torque:
Approximately 104 lb-ft @ 4400 rpm (JDM Spec)
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline
Oil Type And Capacity:
API SN, ILSAC GF-5 0W-20 synthetic oil recommended. Capacity: Approx. 3.9 US quarts (3.7 liters) with filter change (consult manual for exact spec).
Spark Plugs:
NGK LFR5AIX-11 (Iridium) or equivalent. Gap: 1.1 mm (0.043 in).
Transmission Type:
Continuously Variable Transmission (CVT) - Xtronic CVT
Optional Transmission:
Not typically offered for this generation and market.
Cvtf Fluid Type:
Nissan CVT Fluid NS-2 (Consult manual for exact part number and specifications).
Cvtf Fluid Capacity:
Approx. 3.6 US quarts (3.4 liters) for drain and refill (consult manual for exact spec).
Length:
Approx. 3950 mm (155.5 in)
Width:
Approx. 1690 mm (66.5 in)
Height:
Approx. 1600 mm (63.0 in)
Curb Weight:
Approx. 1050-1150 kg (2315-2535 lbs) depending on trim and options.
Gross Vehicle Weight Rating Gvwr:
Consult manual or vehicle placard for specific GVWR.
NHTSA Front Impact:
Likely 4-star (for models sold in markets with NHTSA ratings at the time, exact rating needs verification for specific market).
IIHS Crash Test Results:
Varies by test; refer to IIHS website for specific model year and test type if available for the market.
ABS:
Standard Anti-lock Braking System (ABS) with EBD (Electronic Brakeforce Distribution).
Traction Control:
Available Traction Control System (TCS).
Airbags:
Front airbags, side airbags, curtain airbags (market dependent).
Seatbelts:
Front pretensioner seatbelts with load limiters, rear 3-point seatbelts.
Audio System:
AM/FM stereo with CD player, possibly MP3 capability and auxiliary input (market dependent).
Navigation:
Optional factory navigation system available on higher trims.
Cruise Control:
Standard or optional cruise control.
Bluetooth:
May be available on higher trim levels or as an aftermarket option.
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months, whichever comes first (severe duty). Every 7,500 miles (12,000 km) or 12 months (normal duty) with synthetic oil. Consult manual for exact recommendation.
Air Filter Replacement:
Inspect every 15,000 miles (24,000 km), replace as needed. Replacement recommended every 30,000 miles (48,000 km).
Cabin Air Filter Replacement:
Replace annually or every 15,000 miles (24,000 km).
Coolant Replacement:
Nissan Genuine Super Long Life Coolant (50/50 mix). First replacement at 105,000 miles (170,000 km), then every 75,000 miles (120,000 km) or 5 years.
Transmission Fluid Change Interval:
CVT fluid is typically a 'lifetime' fill but regular inspection is recommended. Drain and fill every 30,000-60,000 miles (48,000-96,000 km) under severe conditions or as indicated by manual/dealership. Consult specific Nissan recommendations for CVT fluid changes.
Brake Fluid:
DOT 3 or DOT 4 brake fluid.
Power Steering Fluid:
Nissan Genuine Power Steering Fluid or equivalent Dexron III ATF.
Common Problems:
CVT issues (though generally reliable for the era), occasional minor electrical gremlins, wear on suspension components due to age, catalytic converter efficiency (depending on mileage and fuel quality).
Nissan Heritage:
Nissan Motor Corporation has a long history of producing reliable and innovative vehicles, from compact cars to sports cars and SUVs.
Cube History:
The Nissan Cube, initially launched in Japan in 1998 (Z10), is renowned for its distinctive, quirky, and utilitarian design. The Z11 generation (2002-2008, with MY2009 being an extension/facelift) continued this unique identity, emphasizing interior space and versatility within a compact footprint.
Manufacturing Location:
Japan (primarily, for JDM market)
