Segment:
Compact Pickup Truck
Competitors:
Toyota Tacoma, Chevrolet Colorado, GMC Canyon, Ford Ranger (previous generation)
Vehicle Highlights:
Body-on-frame construction, available V6 engine, robust design, utility-focused
Manual Benefits:
Licensed OE data, instant access, cost-effective alternative to printed manuals, broad system coverage
Powertrain:
Engine (VG33ER, VQ40DE), Transmission (5-speed Automatic, 6-speed Manual), Drivetrain (4WD/2WD systems, differentials)
Chassis:
Suspension (Front: Independent Double Wishbone, Rear: Solid Axle Leaf Spring), Steering (Hydraulic Power Steering), Brakes (Front: Ventilated Discs, Rear: Drums/Discs depending on configuration)
Electrical:
Wiring Diagrams, Lighting, HVAC Controls, Powertrain Control Modules (PCM), Body Control Modules (BCM), Audio System, Security System
Body:
Exterior Body Panels, Interior Trim, Glass, Doors, Seats, Body Sealing
Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection and replacement, tire rotation
Repair:
Engine component removal/installation (e.g., alternator, starter, water pump), transmission service and repair, brake system overhaul, suspension component replacement, steering system repair, exhaust system repair, HVAC system diagnosis and repair, electrical component troubleshooting and replacement
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), symptom-based diagnostics, wiring diagram interpretation
Depth:
Comprehensive Factory-Level Detail including diagnostics, repair procedures, specifications, and wiring diagrams
Engine Description 1:
3.5L DOHC 24-valve V6
Displacement 1:
3498 cc (213.4 cu in)
Horsepower 1:
261 hp @ 5600 rpm
Torque 1:
281 lb-ft @ 4000 rpm
Engine Code 2:
VG33ER (Supercharged - Less common for 2008, but possible in earlier D40 introduction periods or specific markets, VQ40DE is primary for 2008)
Engine Description 2:
3.3L SOHC V6 with Supercharger
Fuel Type:
Unleaded Gasoline
Injection:
Multi-Point Fuel Injection (MPFI)
Transmission Type Standard:
6-Speed Manual (FS5R30A)
Transmission Type Optional:
5-Speed Automatic (RE5R05A)
Drivetrain Options:
Rear-Wheel Drive (RWD), Electronic 4-Wheel Drive (4WD)
Wheelbase Long Bed:
127.1 inches (3228 mm)
Wheelbase Short Bed:
116.1 inches (2950 mm)
Length Long Bed:
219.4 inches (5573 mm)
Length Short Bed:
205.5 inches (5220 mm)
Width:
72.8 inches (1850 mm)
Height:
70.2 inches (1783 mm)
Bed Length Long:
73.3 inches (1862 mm)
Bed Length Short:
61.5 inches (1562 mm)
Curb Weight Minimum:
4,156 lbs (1885 kg) - RWD King Cab
Curb Weight Maximum:
4,670 lbs (2118 kg) - 4WD Crew Cab Long Bed
Towing Capacity Maximum:
6,500 lbs (2948 kg) - V6, 4WD, 5-spd Auto
NHTSA Front Driver Side Impact:
5-Star (2008 Model Year)
NHTSA Front Passenger Side Impact:
5-Star (2008 Model Year)
ABS:
Standard (4-wheel ABS)
Traction Control:
Available (Vehicle Dynamic Control - VDC)
Stability Control:
Available (Vehicle Dynamic Control - VDC)
Airbags Front:
Standard Dual-Stage Front Supplemental Airbags
Airbags Side:
Available Front Seat-Mounted Side-Impact Supplemental Airbags, Available Roof-Mounted Curtain Supplemental Airbags (Crew Cab)
Audio System:
AM/FM radio, CD player, MP3 capability, optional SiriusXM Satellite Radio, auxiliary audio input
Navigation:
Available factory-installed navigation system on higher trims.
Camera System:
Available rearview camera on some trims.
Bluetooth:
Available Bluetooth Hands-Free Phone System on select trims.
Oil Change Interval:
Every 3,750 miles or 3 months (severe duty) / Every 7,500 miles or 6 months (normal duty) with synthetic oil (consult manual for specific details)
Engine Air Filter Replacement:
Every 15,000 miles or 12 months (severe duty) / Every 30,000 miles or 24 months (normal duty)
Spark Plug Replacement Vq40De:
Approx. 105,000 miles (Iridium type)
Engine Oil Spec Vq40De:
API SN, ILSAC GF-5, SAE 5W-30 (Check manual for exact viscosity and API rating)
Transmission Fluid Automatic:
Nissan Genuine Matic S ATF or equivalent
Transmission Fluid Manual:
Nissan Genuine Manual Transmission Fluid (MTF) HQ 75W-85 GL-4 or equivalent
Coolant Type:
Nissan Genuine Super Long Life Coolant (Blue) or equivalent silicate-free, extended-life antifreeze
Common Complaints Engine:
Occasional oil consumption, potential camshaft/crankshaft position sensor issues, timing chain stretch (higher mileage)
Common Complaints Transmission:
Some automatic transmission shifting issues or premature wear reported in early D40 models, but generally robust.
Common Complaints Suspension Steering:
Ball joint wear, steering rack leaks, or noises can occur with mileage.
Nissan Truck Legacy:
Nissan has a long history of producing durable and capable trucks, starting with models like the Datsun Truck and earlier Frontiers.
D40 Introduction:
The D40 generation of the Frontier was introduced for the 2005 model year, offering a significant redesign with a larger platform, more powerful engines, and improved capabilities.
Manufacturing Location:
Smyrna, Tennessee, USA
