Target Audience:
Do-it-yourself enthusiasts and experienced mechanics seeking comprehensive repair and maintenance guidance for the Polaris Sportsman Touring 850.
Value Proposition:
An inexpensive and efficient way to maintain and repair the vehicle, avoiding costly dealership service fees.
Content Highlight:
Comprehensive, step-by-step instructions, hundreds of photos and illustrations, detailed electrical system diagnostics.
Regions Covered:
This manual is applicable to all Polaris Sportsman Touring 850 models sold globally during the 2012 and 2013 model years, as factory service information is generally universal.
Estimated Page Count:
Hundreds of pages (Specific number not provided in product info, but implies comprehensive depth).
Manual Type:
Workshop Service Repair Manual
Powertrain:
Engine, transmission, drivetrain, exhaust system.
Chassis:
Frame, suspension (front and rear), steering system, wheels and tires.
Electrical:
Ignition system, charging system, lighting, instrumentation, electrical diagnostics, wiring diagrams.
Brakes:
Hydraulic brake system (front and rear), brake components, fluid specifications.
Body And Trim:
Body panels, plastics, seating, luggage systems.
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, lubrication.
Repair:
Step-by-step instructions for disassembly, repair, and reassembly of all major components.
Troubleshooting:
Diagnostic procedures for common and uncommon issues, fault code interpretation (if applicable).
Diagnostics:
Detailed diagnostic procedures, including electrical system diagnosis with wiring diagrams.
Depth Of Coverage:
Complete factory service information, covering everything from basic maintenance to full engine and transmission rebuilds.
Detail Level:
Hundreds of photos and illustrations, detailed substeps, notes, cautions, and warnings for critical information.
Printability:
Printable without any restriction.
Binding Type:
N/A (Downloadable digital format).
Paper Type:
N/A (Digital format, printable on user's choice of paper).
Delivery:
Instant download link provided on checkout page after payment.
Required Software:
Adobe PDF Reader
Engine Type:
Liquid-cooled, 4-stroke, SOHC, V-twin
Engine Displacement:
850cc (Approximate, based on model designation)
Fuel Delivery:
Electronic Fuel Injection (EFI)
Horsepower:
Specifications available within the manual (typically around 70-77 HP for this era/model).
Torque:
Specifications available within the manual.
Transmission Type:
Automatic (PVT - Polaris Variable Transmission)
Drive Modes:
High, Low, Neutral, Reverse, Park
Engine Braking:
Standard feature of the PVT system for downhill control.
Length:
Specifications available within the manual.
Width:
Specifications available within the manual.
Height:
Specifications available within the manual.
Dry Weight:
Specifications available within the manual (typically around 700-750 lbs).
Ground Clearance:
Specifications available within the manual (typically around 11-12 inches).
Atv Safety Standards:
The manual covers procedures to maintain the vehicle's intended safety characteristics as designed by Polaris.
Braking System:
Hydraulic disc brakes front and rear for effective stopping power.
Roll Over Protection:
While not a car, the ATV design inherently includes rider positioning and chassis stability features detailed in the manual.
Instrument Cluster:
The manual will cover the operation and diagnostics of the digital instrument cluster, which displays speed, RPM, fuel level, gear selection, and warning indicators.
Throttle Control:
Details on the throttle linkage and potentially electronic throttle body (if equipped) for smooth power delivery.
Lighting System:
Comprehensive coverage of the electrical system, including headlights, taillights, brake lights, and auxiliary lighting.
Oil Change Interval:
Detailed in the manual, typically based on operating hours or mileage (e.g., every 100 hours or annually).
Air Filter Cleaning:
Recommended at regular intervals depending on operating conditions, detailed in the manual.
Engine Oil Type:
Specified in the manual (typically a specific SAE viscosity grade like 5W-50 or 10W-50 synthetic ATV oil).
Coolant Type:
Specified in the manual (typically an ethylene glycol based coolant, often a specific color like blue or green).
Brake Fluid Type:
Specified in the manual (typically DOT 3 or DOT 4 hydraulic brake fluid).
Gearcase Oil Type:
Specified in the manual for front and rear differentials/gearboxes.
Common Wear Items:
The manual will detail inspection and replacement of wear items such as brake pads, tires, suspension bushings, and drive belts.
Efi System Maintenance:
Procedures for checking and maintaining the fuel injection system, including potential cleaning of injectors, will be covered.
Polaris Offroad Legacy:
Polaris has a long-standing reputation for producing durable and capable off-road vehicles, including the Sportsman line, known for its versatility and comfort.
Sportsman Touring Development:
The Touring variant of the Sportsman 850 is designed for extended comfort and utility, often featuring a passenger seat and enhanced storage solutions compared to standard models.
Manufacturing Location:
Polaris vehicles are primarily manufactured in the United States.
