Segment:
Mid-size Crossover SUV
Target Audience:
Families and individuals seeking versatile cargo and passenger capacity with a unique styling
Key Competitors:
Ford Escape, Toyota RAV4, Honda CR-V, Nissan Xterra
Design Philosophy:
Unconventional, distinctive styling with a focus on practicality and modularity
Unique Offerings:
Optional 'S.P.A.C.E.' (Stowage, Pull-out, Assist, Convenience, Entertainment) system including a pull-out tailgate cooler, tent and sleeping compartment attachment capability, rear seat multimedia player
Overall Coverage:
All repairs, servicing, and troubleshooting procedures
Estimated Pages:
Hundreds (specific count not provided, but described as extensive)
Type:
Full Service & Repair Workshop Manual
Powertrain:
Engine, transmission, drivetrain, exhaust
Chassis:
Suspension, steering, brakes, wheels, tires
Electrical:
Wiring diagrams, lighting, ignition, starting, charging, body electrical, comfort and convenience
Body And Interior:
Body panels, doors, glass, seats, trim, HVAC
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, inspections
Repair:
Component removal, installation, overhaul, and adjustment
Troubleshooting:
Diagnostic procedures, fault finding, symptom-based troubleshooting
Diagnostics:
OBD-II diagnostic trouble codes (DTCs), circuit testing, sensor data analysis.
Depth:
Complete factory level, from basic maintenance to complex repairs and diagnostics
Wiring Diagrams:
Includes detailed electrical wiring diagrams for all systems.
Exploded Views:
Features highly detailed exploded diagrams and pictures for repair procedures.
Printability:
Printable (single page or entire manual)
Digital Binding:
N/A (Digital download)
Digital Paper Equivalent:
N/A (Digital download)
Operating Systems:
Windows and MAC
Usage License:
Lifetime use on unlimited computers
Renewal Policy:
No expiry, no renewal fees
Configuration:
3.4L V6 (207 cu in)
Bore X Stroke:
3.50 in x 3.54 in (89 mm x 90 mm)
Horsepower:
185 hp @ 5200 rpm
Torque:
210 lb-ft @ 4000 rpm
Engine Family:
GM 3400 V6 (GM's LA1 engine)
Valvetrain:
SOHC (Single Overhead Camshaft) with 12 valves (2 valves per cylinder)
Fuel Delivery:
Sequential Electronic Fuel Injection (SFI)
Fuel Type:
Unleaded Gasoline
ECU Type:
GM ECM (Electronic Control Module)
Length:
185.1 in (4701 mm)
Height:
66.5 in (1689 mm)
Wheelbase:
109.0 in (2769 mm)
Curb Weight FWD:
approx. 3,720 lbs (1,687 kg)
Curb Weight AWD:
approx. 3,940 lbs (1,787 kg)
Cargo Volume Behind 2Nd Row:
62.1 cu ft (1,758 L)
Cargo Volume Max:
72.4 cu ft (2,050 L)
NHTSA Rollover Rating:
Four-star (FWD), Four-star (AWD)
IIHS Rating:
Varies by year and specific test; generally received 'Acceptable' to 'Good' ratings in frontal offset tests.
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Standard Traction Control System (TCS)
Airbags Front:
Driver and front passenger airbags
Airbags Side:
Optional front side-impact airbags
Seatbelts:
3-point seat belts with pretensioners and load limiters
Oil Change Interval:
Every 3,000-5,000 miles or as per owner's manual recommendations, depending on driving conditions.
Tire Rotation Interval:
Every 5,000-7,500 miles
Engine Air Filter Replacement:
Every 15,000-30,000 miles or as needed based on inspection.
Engine Oil Type:
SAE 5W-30 Synthetic Blend or Full Synthetic
Engine Oil Capacity:
4.5 US quarts (4.3 L) with filter change
Coolant Type:
Dex-Cool® (Orange, long-life) silicate-free, phosphate-free, borate-free, nitrité-free, and amine-free organic acid technology (OAT)
Transmission Fluid Type:
Dexron®-VI Automatic Transmission Fluid (or Dexron®-III H if Dexron®-VI is unavailable, but Dexron®-VI is preferred)
Brake Fluid Type:
DOT 3 or DOT 4
Power Steering Fluid Type:
GM Power Steering Fluid or equivalent Dexron® ATF
Evaporative Emissions System:
Common issues with the EVAP system, including vent and purge solenoids, leading to 'check engine' lights and P04xx codes.
Intake Manifold Gaskets:
Potential for coolant leaks due to failure of the composite intake manifold gaskets.
Rear Suspension Bushings:
Wear and tear on rear suspension control arm bushings can lead to clunking noises and alignment issues.
Wheel Bearings:
Front wheel bearings can be a wear item, leading to humming or grinding noises.
Alternator Failure:
Alternators can experience premature failure, especially on higher-mileage vehicles.
Pontiac Legacy:
Pontiac, known for performance-oriented vehicles and distinctive styling, aimed to create a unique segment with the Aztek.
Introduction Year:
2001 (as a 2001 model, production began in 2000)
Design Origin:
Based on the Pontiac 'Banshee' concept vehicle and the 'Piranha' show car.
Manufacturing Plant:
Fairfield, Ohio, USA
Production Years:
2000-2005 (model years 2001-2005)
