🏷️ Basic Information

Make:

Pontiac

Model:

Solstice

Years Covered:

2005, 2006, 2007, 2008, 2009

Chassis Code:

Skyline (Kappa platform)

👋 Introduction

Vehicle Segment:

Roadster, Sports Car

Target Audience:

Enthusiasts, DIY Mechanics, Professional Technicians

Key Competitors:

Mazda Miata MX-5, Honda S2000, BMW Z4, Porsche Boxster

Manual Value Proposition:

Comprehensive, factory-accurate information for all maintenance, repair, and diagnostic tasks, providing significant cost savings over dealership service.

Vehicle Appeal:

Affordable rear-wheel-drive sports car with distinctive styling and engaging driving dynamics.

📋 Manual Details

General Coverage:

Full Service & Repair

Primary Focus:

Mechanical, Electrical, Body, Diagnostics

Estimated Pages:

Hundreds (specific count not provided, but described as 'very detailed')

Type:

Factory Service Repair Workshop Manual

Language:

English

Format:

Downloadable PDF

Cross Platform Compatibility:

Windows & MAC Computers

Device Compatibility:

Computer, Tablet, Smart Phone

License Type:

Lifetime Use, No Expiry Dates, No Renewal Fees

Usage Rights:

Install on unlimited devices

Content Quality:

Detailed Photos & Diagrams, Step-by-Step Instructions, Exploded Diagrams

📖 Manual Coverage

Powertrain:

Engine, Transmission, Drivetrain, Fuel System, Exhaust System

Chassis:

Suspension (Front & Rear), Steering, Brakes (ABS, Parking Brake)

Electrical:

Battery, Charging System, Ignition System, Lighting, Instrumentation, Body Electrical, Powertrain Control Module (PCM), HVAC Controls, Audio System

Body:

Body Panels, Doors, Hood, Trunk, Interior Trim, Convertible Top System

Maintenance:

Oil Changes, Filter Replacements, Fluid Checks & Replacements, Spark Plugs, Belts & Hoses

Repair:

Engine Overhaul, Transmission Service, Brake System Repair, Suspension Component Replacement, Electrical Component Diagnosis & Replacement, Body Panel Repair

Troubleshooting:

Diagnostic Flowcharts, Symptom-Based Troubleshooting, Fault Code Interpretation

Diagnostics:

On-Board Diagnostics (OBD-II), Scan Tool Procedures, Circuit Testing

Depth:

Professional Level, covering all repairs, servicing, and troubleshooting procedures

📊 Manual Specifications

Format:

PDF

Searchability:

Likely text-searchable (standard for professional PDFs)

Print Capability:

Print single pages or entire manual

Binding:

Not Applicable (Digital Download)

Paper Quality:

Not Applicable (Digital Download)

⚙️ Engine Specifications

Engine Code 2005-2007:

L40 (2.4L Ecotec)

Engine Code 2008-2009:

LE5 (2.4L Ecotec - updated)

Displacement 2.4L:

2384 cc (145.5 cu in)

Bore X Stroke 2.4L:

88 mm x 98.4 mm (3.46 in x 3.87 in)

Compression Ratio 2.4L:

10.4:1

Horsepower 2.4L L40:

177 hp @ 6600 rpm

Torque 2.4L L40:

170 lb-ft @ 4800 rpm

Horsepower 2.4L Le5:

173 hp @ 6600 rpm (slight reduction due to tuning)

Torque 2.4L Le5:

167 lb-ft @ 4800 rpm (slight reduction)

Engine Code Gxp:

LSJ (2.0L Supercharged Ecotec)

Displacement 2.0L Supercharged:

1998 cc (121.9 cu in)

Horsepower 2.0L Supercharged:

260 hp @ 5300 rpm

Torque 2.0L Supercharged:

260 lb-ft @ 2500 rpm

Fuel Delivery:

Multi-Port Fuel Injection (MPFI)

Fuel Type:

Unleaded Gasoline (87 Octane recommended, 91+ for Supercharged)

ECU Type:

GM Delco E37 (for 2.4L), E39 (for 2.0L SC)

🔧 Transmission

Standard Transmission 2.4L:

5-Speed Manual (Aisin FG5M-R)

Standard Transmission Gxp:

5-Speed Manual (Getrag F23)

Optional Transmission 2.4L:

4-Speed Automatic (GM 4T45-E)

Optional Transmission Gxp:

5-Speed Automatic (GM 5L40-E)

Drivetrain:

Rear-Wheel Drive (RWD)

Differential:

Limited-Slip Differential (LSD) optional on some models, standard on GXP

📐 Dimensions

Length:

169.1 in (4295 mm)

Width:

70.5 in (1791 mm)

Height:

51.1 in (1298 mm)

Wheelbase:

97.2 in (2469 mm)

Curb Weight 2.4L Manual:

approx. 2,860 lbs (1,297 kg)

Curb Weight 2.0L Sc Manual:

approx. 3,025 lbs (1,372 kg)

🛡️ Safety Features

NHTSA Front Impact Driver:

Good (2006 Model Year)

NHTSA Front Impact Passenger:

Good (2006 Model Year)

IIHS Side Impact:

Acceptable (2006 Model Year)

ABS:

Standard (4-wheel disc brakes)

Airbags:

Driver and front passenger airbags

Rollover Protection:

Reinforced windshield frame, standard pop-up roll bars (behind headrests)

💡 Technology Features

Infotainment System:

Base AM/FM stereo with CD player, optional Monsoon premium audio system, optional navigation system (late models).

Traction Control:

Available on some models, standard on GXP

Stability Control:

Available on some models, standard on GXP

Auxiliary Input:

Available on later models

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles (12,000 km) or 6 months, whichever comes first (using synthetic oil)

Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on conditions

Spark Plug Replacement 2.4L:

Every 100,000 miles (160,000 km) (iridium plugs)

Coolant Replacement:

First at 100,000 miles (160,000 km), then every 50,000 miles (80,000 km)

Engine Oil Type 2.4L:

SAE 5W-30 Synthetic (API SN or equivalent)

Engine Oil Capacity 2.4L:

4.7 US quarts (4.4 liters) with filter

Transmission Fluid Type Manual:

Dexron III/VI ATF or specific manual transmission fluid (refer to manual for exact type)

Brake Fluid Type:

DOT 3 or DOT 4

Common Issues List:

Convertible top hydraulic leaks, clutch wear, suspension component noise, occasional electrical gremlins (especially related to convertible top operation), intake manifold gasket leaks on early 2.4L models.

📚 Vehicle History

Pontiac Legacy:

Pontiac was known for performance-oriented vehicles, often targeting a younger demographic.

Platform Shared With:

Opel GT, Saturn Sky (GM Kappa Platform)

Design Inspiration:

Pontiac GTO concept car (2002)

Production Start Year:

2005

Production End Year:

2009

Assembly Location:

General Motors Wilmington Assembly Plant, Delaware

🏆 Awards & Recognition

Design Award:

Recognized for its distinctive styling by automotive journalists.
