Segment:
Subcompact car, budget-friendly, practical transportation.
Key Competitors:
Chevrolet Aveo, Toyota Yaris, Honda Fit, Ford Fiesta, Hyundai Accent, Kia Rio.
Value Proposition:
Affordable price point, decent fuel economy, practical for urban environments, available in hatchback and sedan.
Target Audience:
First-time car buyers, students, budget-conscious individuals, small families.
Professional Reference:
Provides detailed, factory-level information that surpasses generic DIY guides, enabling accurate and efficient repairs.
Scope:
Complete Factory Service Repair Workshop Manual
Regions Covered:
North America (USA, Canada), and potentially other markets where the Pontiac Wave/G3 or Chevrolet Aveo was sold.
Estimated Pages:
Hundreds (specific number not provided, but described as 'very detailed' with 'hundreds of pages')
Type:
Full Service & Repair Manual / Workshop Manual
Accessibility:
Compatible with Windows & MAC computers, tablets, and smartphones.
Licensing:
Lifetime use, no expiry dates, no renewal fees.
Edition:
Full Version (No limitations or trial periods)
Powertrain:
Engine mechanical, lubrication, cooling, fuel, ignition, exhaust, engine control systems (ECM/PCM), emissions.
Drivetrain:
Manual transmission, automatic transmission, clutch, drive axles, propeller shafts (if applicable), differentials.
Chassis:
Suspension (front and rear), steering system, braking system (ABS, hydraulic, parking brake), wheels and tires.
Electrical:
Battery, charging system, starting system, lighting, instruments and gauges, horn, wipers and washers, power windows, locks, mirrors, audio system, basic wiring diagrams.
Body:
Body panels, doors, windows, interior trim, seats, bumpers, exterior trim, HVAC (Heating, Ventilation, and Air Conditioning).
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), diagnostic procedures, component testing.
Maintenance:
Routine checks, oil changes, fluid top-offs, filter replacements, spark plug replacement, belt inspections/replacement.
Repair:
Engine component replacement (e.g., alternator, starter, water pump), transmission service, brake caliper/rotor replacement, suspension component replacement, exhaust system repair, electrical component diagnosis and replacement.
Troubleshooting:
Step-by-step diagnostic flowcharts for common symptoms (e.g., no-start, poor performance, strange noises).
Rebuilds:
Detailed instructions for engine and transmission rebuilds (if applicable and within scope of a factory manual).
Specifications:
Torque specifications, clearances, fluid types and capacities, electrical values, diagnostic data.
Depth:
Professional-grade, step-by-step instructions with detailed photos and exploded diagrams, equivalent to factory technician manuals.
Engine Code:
LXT (1.6L DOHC I4, GM Family II / Ecotec)
Displacement:
1598 cc (97.5 cu in)
Bore X Stroke:
79.0 mm x 81.5 mm (approximate)
Compression Ratio:
10.5:1 (typical for LXT)
Horsepower:
106 hp @ 6400 rpm (approximate, depending on market/configuration)
Torque:
105 lb-ft @ 3800 rpm (approximate)
Fuel Delivery:
Multi-point Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline
Octane Rating:
87 octane (minimum required)
Engine Control Module:
GM ECM/PCM with OBD-II (On-Board Diagnostics II) diagnostics.
Type:
5-speed Manual Transmission (MY5)
Type:
4-speed Automatic Transmission (4T45-E, often shared with other GM platforms)
Manual Fluid Type:
API GL-4, SAE 75W-90 synthetic manual transmission fluid (specific GM part number recommended).
Automatic Fluid Type:
Dexron-VI Automatic Transmission Fluid (ATF)
Clutch Type:
Dry single plate, hydraulically actuated (for manual transmission).
Body Styles:
5-door Hatchback, 4-door Sedan
Length:
Hatchback: ~161.1 inches (4092 mm) / Sedan: ~173.3 inches (4402 mm)
Width:
~67.1 inches (1704 mm)
Height:
~58.4 inches (1483 mm) (Hatchback) / ~57.7 inches (1466 mm) (Sedan)
Seating Capacity:
5 passengers
Cargo Volume Hatchback:
~10.1 cu ft (seats up) / ~21.7 cu ft (seats down, to window line)
Curb Weight:
~2400 - 2500 lbs (approximate, depending on body style and equipment)
Gross Vehicle Weight Rating:
Not specified in product info, typically around 3500-3700 lbs.
NHTSA Front Impact:
4-star driver, 4-star passenger (for Aveo sedan 2007-2008, likely similar for Wave G3)
IIHS Side Impact:
Acceptable (for Aveo sedan 2007-2008, likely similar for Wave G3)
IIHS Rear Impact:
Good (for Aveo sedan 2007-2008, likely similar for Wave G3)
ABS:
Standard on most trims, optional on base models.
Traction Control:
Optional on some higher trims.
Airbags:
Standard: Frontal airbags. Optional/Available: Side-impact airbags.
Seatbelts:
3-point seatbelts with pretensioners.
Child Seat Anchors:
LATCH (Lower Anchors and Tethers for Children) system.
Oil Change:
Every 5,000 - 7,500 miles (8,000 - 12,000 km) or 6 months, whichever comes first, depending on driving conditions and oil type used (consult manual for specific recommendation).
Air Filter Replacement:
Every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on inspection.
Spark Plug Replacement:
Platinum/Iridium plugs typically every 100,000 miles (160,000 km); copper plugs every 30,000 miles (48,000 km). Manual will specify exact type and interval.
Coolant Flush:
Every 30,000 - 60,000 miles (48,000 - 96,000 km) or 2-4 years, depending on coolant type (GM typically uses long-life OAT coolant).
Engine Oil Capacity:
Approximately 4.0 quarts (3.8 liters) with filter change (check manual for exact capacity and oil type, likely 5W-30 synthetic blend or full synthetic).
Brake Fluid Type:
DOT 3 or DOT 4 (consult manual for specific recommendation).
Power Steering Fluid:
If equipped with hydraulic power steering, typically Dexron-VI ATF or specific GM power steering fluid.
Common Complaints:
Interior rattles and build quality issues, occasional electrical gremlins, potential for exhaust manifold cracks (on some Ecotec variants), transmission issues (especially with higher mileage automatics).
Maintenance Focus:
Regularly check and change engine oil and filter, inspect and replace air filter, maintain cooling system, monitor tire wear, and address any unusual noises promptly.
Pontiac Brand:
General Motors' performance-oriented brand, known for sporty styling and muscle cars, later shifted to value-focused and rebadged models.
Wave G3 Origin:
The Pontiac Wave was a rebadged version of the Chevrolet Aveo, which itself was based on GM's global small car platform. The G3 designation was used for the second generation Aveo (T250) sold as a Pontiac in certain markets.
Manufacturing Location:
Primarily South Korea (Daewoo/GM Korea) for the Aveo platform, then assembled in various locations globally.
Pontiac Discontinuation:
Pontiac brand was officially discontinued by General Motors in 2010.
Safety Awards:
While specific awards for the Pontiac Wave G3 are scarce, its platform sibling, the Chevrolet Aveo, received some safety ratings from organizations like NHTSA and IIHS, as detailed in the safety section.
Fuel Economy:
Generally considered good for its class, with EPA estimates around 25-27 MPG city / 33-37 MPG highway, depending on transmission and body style.
