Target Audience:
Proton and Renault technicians, as well as advanced automotive enthusiasts.
Value Proposition:
Provides detailed, factory-level information for specific, critical vehicle systems (engine, gearbox, wiring), ensuring accuracy and completeness for repair and maintenance.
Manual Distinctiveness:
Designed to meet the needs of worldwide technicians, structured format, high-quality content, focuses on core mechanical and electrical systems.
Engine Systems:
Engine mechanicals, fuel system, ignition system, cooling system, lubrication system, exhaust system, engine management system (ECU).
Transmission Systems:
Manual and Automatic transmission (depending on variant availability), clutch system, gearbox overhaul, gear shift mechanisms.
Electrical Systems:
Wiring diagrams for engine control, ignition, fuel injection, lighting, power distribution, sensors, actuators, and associated ECUs.
Maintenance Procedures:
Scheduled maintenance, fluid changes (oil, coolant, brake, transmission), filter replacements, spark plug replacement, belt inspection/replacement.
Repair Procedures:
Engine component repair and replacement (pistons, rings, bearings, valves, camshafts, crankshaft), gearbox disassembly and reassembly, electrical component diagnosis and repair.
Troubleshooting Procedures:
Diagnostic flowcharts, fault code interpretation, symptom-based troubleshooting for engine, gearbox, and electrical issues.
Depth Of Coverage:
Comprehensive, suitable for professional technicians and experienced DIY mechanics. Covers from basic maintenance to in-depth diagnostics and repairs.
Engine Type:
Inline 4-cylinder, naturally aspirated petrol engine.
Engine Displacement:
1.2 Liters (1149 cc).
Engine Code Variant:
D4F (shared with Renault Clio, Modus, Twingo).
Horsepower:
Typically around 75-80 PS (55-59 kW) at 5500-6000 rpm (specific figures for Savvy may vary, consult manual for exact spec).
Torque:
Typically around 105-110 Nm (77-81 lb-ft) at 4250-4500 rpm (specific figures for Savvy may vary, consult manual for exact spec).
Fuel Delivery:
Multi-point fuel injection (MPI).
Fuel Type:
Unleaded Petrol (Gasoline).
Cylinder Block Material:
Likely cast iron or aluminum alloy.
Cylinder Head Material:
Likely aluminum alloy.
Cylinder Head Design:
DOHC (Double Overhead Camshaft), 16 valves (4 valves per cylinder).
Transmission Type Offered:
Manual transmission likely standard, with automatic transmission potentially available as an option depending on market and trim.
Transmission Type Optional:
Likely a 4-speed automatic transmission.
Gearbox Description:
The manual covers the overhaul and repair procedures for both manual and automatic transmissions used in the Proton Savvy.
Crash Test Information:
Specific crash test ratings are not provided in the product information. Consult independent safety review sites for detailed results.
Braking System:
Front ventilated disc brakes, rear drum brakes are common for this segment. ABS may be available on higher trims.
Airbags:
Driver and passenger airbags are standard in many markets. Side airbags may be optional.
Seatbelts:
Pre-tensioning seatbelts, particularly for front occupants.
Infotainment System:
Basic infotainment system, typically featuring a radio with CD player and auxiliary input. Advanced connectivity features are unlikely.
Driver Assistance Features:
Limited driver assistance systems. ABS and EBD might be available on higher trim levels. Parking sensors are unlikely to be standard.
Connectivity Options:
Basic connectivity via auxiliary input for audio playback. Bluetooth integration or smartphone mirroring is not expected.
Engine Oil Change Interval:
Typically every 10,000 km or 12 months, whichever comes first. Always refer to the manual for exact specifications.
Transmission Fluid Change Interval:
Manual transmission: typically every 60,000 km. Automatic transmission: typically every 40,000 km. Consult manual for specific fluid type and intervals.
Timing Belt Replacement:
The D4F engine uses a timing belt, typically requiring replacement every 90,000-120,000 km or 5-6 years. This is a critical item for this engine.
Engine Oil Specification:
Likely API SL/SM or higher, viscosity 5W-30 or 5W-40. Specific ACEA or Renault approval may be required. Consult manual for exact grade.
Coolant Specification:
Ethylene glycol-based antifreeze/coolant. Type-A or Type-B as per Renault specifications, often orange or pink color. Mix ratio 50/50 with distilled water.
Manual Transmission Fluid:
GL-4 specification gear oil, 75W-80 or 75W-90 viscosity. Capacity usually around 2.0-2.5 liters.
Automatic Transmission Fluid:
Typically DEXRON III or equivalent. Consult manual for exact specification and capacity.
Engine Common Problems:
Potential issues may include oil leaks, minor electrical faults related to sensors, and wear on components like engine mounts. Timing belt integrity is crucial.
Transmission Common Problems:
Manual transmissions can experience clutch wear. Automatic transmissions might show issues with gear shifting or solenoid operation if not properly maintained.
Electrical Common Problems:
Wiring harness integrity, particularly in high-vibration areas, can be a concern. Sensor failures (e.g., crankshaft position sensor) are not uncommon in vehicles of this age.
Proton History:
Proton is Malaysia's national automotive manufacturer, established in 1983. It has a history of producing licensed models from other manufacturers as well as developing its own designs.
Savvy Development:
The Proton Savvy was developed in-house by Proton, marking a step towards independent design. It was launched in 2005.
Engine Collaboration Significance:
The adoption of the Renault D4F engine signifies Proton's strategy to leverage reliable and modern components from established global manufacturers.
Production Period:
2005 - 2011.
Manufacturing Location:
Malaysia.
