Vehicle Segment:
Compact MPV / Leisure Activity Vehicle (LAV)
Key Selling Points:
Practicality, versatility, compact dimensions for urban use, spacious interior for its size, range of engine options.
Key Competitors:
Citroën Berlingo, Peugeot Partner, Fiat Doblò, Ford Transit Connect.
Manual Benefit 1:
Empowers owners to perform their own maintenance and repairs, saving significant costs.
Manual Benefit 2:
Provides clear, step-by-step instructions and visual aids (pictures, diagrams) for easy comprehension.
Manual Benefit 3:
Covers a comprehensive range of mechanical and electrical systems for complete vehicle care.
Manual Benefit 4:
Downloadable format ensures instant access on various devices (PC, Mac, Tablet, Smartphone).
Covered Years:
2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010
Covered Engine Variants:
1.0L Petrol, 1.2L Petrol, 1.4L Petrol, 1.6L Petrol, Diesel variants (specific displacements not listed but implied by broad coverage)
Covered Models:
All Renault Kangoo X76 models within the specified year range
Estimated Page Count:
Likely extensive, typical for comprehensive workshop manuals (estimated 1000+ pages)
Manual Type:
Service Repair Shop Manual
Delivery Method:
Digital Download
Engine Systems:
Engine mechanical (including cylinder head, block, crankshaft, pistons, valves), engine management (fuel injection, ignition), cooling system, lubrication system, exhaust system, emission control systems.
Transmission Systems:
Manual and potentially automatic transmission service, clutch system, driveshafts, differentials.
Electrical Systems:
Wiring diagrams, charging system (alternator, battery), starting system, lighting, instrumentation, body electronics, power windows, central locking, audio system, fuse and relay locations.
Chassis Systems:
Suspension (front and rear), steering system, braking system (discs, drums, ABS, hydraulic components), wheels, tires.
Body And Interior:
Body panels, doors, hinges, locks, glass, interior trim, seating, HVAC (heating, ventilation, and air conditioning) system.
Maintenance Procedures:
Routine maintenance (oil changes, filter replacements, fluid checks), tune-ups, scheduled servicing.
Repair Procedures:
Detailed step-by-step repair instructions for all major vehicle components and systems, including engine rebuilds, transmission overhauls, brake caliper replacement, suspension component renewal.
Troubleshooting:
Diagnostic procedures for common faults, symptom-based troubleshooting guides, fault code interpretation (if applicable).
Wiring Diagrams:
Comprehensive electrical wiring schematics for all vehicle systems.
Technical Depth:
In-depth, professional quality, covering basic maintenance to complex mechanical and electrical repairs. Suitable for DIY enthusiasts and professional technicians alike.
PDF Quality:
High quality, enabling clear viewing and printing of text, diagrams, and images.
Searchability:
Likely text-searchable PDF for quick information retrieval.
Printable:
Yes, designed to be printed for hard copy reference.
Binding Type:
N/A (Digital Download)
Paper Type:
N/A (Digital Download)
Engine Family:
Various Renault petrol and diesel engines
Petrol Engine Options:
1.0L, 1.2L, 1.4L, 1.6L (specific engine codes like D4F, K4M would be detailed in the manual)
Diesel Engine Options:
Various diesel engine displacements, likely including 1.5L dCi, 1.9L dTi/dCi (specifics in manual)
Horsepower Range Petrol:
Approximately 60 PS (1.0L) to 110 PS (1.6L) depending on variant.
Horsepower Range Diesel:
Approximately 65 PS (1.5 dCi) to 100 PS (1.9 dCi) depending on variant.
Fuel Delivery Petrol:
Electronic Fuel Injection (MPI or similar)
Fuel Delivery Diesel:
Common Rail Direct Injection (dCi) or Turbocharged Direct Injection (dTi)
Body Styles:
Panel Van, Passenger versions (Combi)
Typical Length:
Approx. 4,021 mm
Typical Width:
Approx. 1,670 mm (excluding mirrors)
Typical Height:
Approx. 1,780 mm
Cargo Volume Van:
Varies by configuration, but typically around 3 cubic meters for the panel van version.
Gross Vehicle Weight:
Varies by model and engine, typically between 1,700 kg and 2,000 kg.
Euro Ncap Rating:
3 Stars (for Phase 1, tested 2001) - driver and front passenger airbags standard on most later models, ABS optional or standard depending on trim.
Active Safety Features:
Anti-lock Braking System (ABS) - optional/standard, Brake Assist (BA) - potentially.
Passive Safety Features:
Driver and front passenger airbags, ISOFIX child seat mounting points, seatbelt pretensioners.
Infotainment Features:
Basic CD player, radio, optional RDS, likely cassette player on earlier versions. Later models might have aux input or basic MP3 CD compatibility.
Driver Assistance Systems:
Limited by era. Primarily ABS and potentially cruise control on higher trims. No advanced driver-assistance systems (ADAS).
Connectivity Options:
Basic auxiliary input for audio devices on some later models.
Oil Change Interval:
Typically every 15,000 - 20,000 km or 1 year, whichever comes first (refer to manual for specific engine and oil type).
Diesel Oil Change Interval:
Similar to petrol, but often with slightly shorter intervals or specific DPF considerations for later models if applicable.
Engine Oil Specification:
Varies by engine, commonly Renault RN0700, RN0710, or specific SAE viscosity grades (e.g., 5W-40, 10W-40). Refer to manual for exact requirement.
Coolant Specification:
Ethylene glycol-based antifreeze, typically Renault Type D (blue) or specific concentration.
Brake Fluid Specification:
DOT 4
Transmission Fluid Manual:
GL-4 specification gear oil, viscosity typically 75W-80 or 75W-90.
Common Issues Engine:
Coil pack failure (petrol), injector issues (diesel), turbocharger problems (diesel), overheating due to cooling system issues.
Common Issues Chassis:
Worn suspension components (ball joints, bushes), brake wear, exhaust system rust, rear axle bearing issues (on some models).
Common Issues Electrical:
Faulty window regulators, central locking issues, minor electrical gremlins, sensor failures.
Manufacturer Origin:
France
Brand Specialization:
Known for mainstream passenger cars, light commercial vehicles, and innovative designs.
Model Introduction:
The Kangoo was first introduced in 1997, this X76 designation covers the facelifted Phase 1 (launched 2003) and Phase 2 (launched 2007) of the first generation.
Manufacturing Locations:
Primarily Renault's MCA (Maubeuge) plant in France, with potential production in other markets.
