Saturn SC2 Complete Workshop Service Repair Manual

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Saturn Model: SC2 👋 Introduction Market Position Segment: Compact Sports Coupe Target Audience: DIY enthusiasts, independent repair shops, Saturn owners seeking detailed repair information Competitive...

20 people are viewing this right now

类型: Car

斯库: 201681

标签: Car Cars Featured S Series Saturn SC2

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Saturn

Model:

👋 Introduction

Market Position

Segment:

Compact Sports Coupe

Target Audience:

DIY enthusiasts, independent repair shops, Saturn owners seeking detailed repair information

Competitive Analysis

Competitors:

Dodge Neon, Honda Civic Coupe, Toyota Celica, Ford Escort ZX2

Key Features

Unique Selling Points:

Saturn's dent-resistant polymer body panels, unique automotive design, affordable performance, comprehensive manual coverage

Manual Benefit:

Empowers owners to perform maintenance and repairs, saving money and extending vehicle life.

📋 Manual Details

Coverage Areas

Primary Coverage:

Complete Service, Repair, Maintenance, Diagnostics, Troubleshooting, Electrical Schematics, Bodywork

Model Variants Covered:

All Saturn SC2 models and trim levels

Engine Variants Covered:

All engine options for the Saturn SC2 (typically the DOHC 1.9L L4)

Transmission Variants Covered:

All transmission types for the Saturn SC2 (Manual and Automatic)

Page Count

Estimated Page Count:

1000+ (typical for a comprehensive workshop manual)

Manual Type

Type:

Workshop Service Repair Manual

Language

Language:

English

Format

Format:

Downloadable Digital Format (PDF)

📖 Manual Coverage

Systems Covered

Engine:

Engine mechanical (assembly, disassembly, diagnosis, overhaul), lubrication system, cooling system, fuel system (injection, sensors), emission control systems, ignition system

Transmission:

Manual transmission (clutch, gearbox, linkages), Automatic transmission (hydraulic control, valve body, torque converter, diagnosis)

Drivetrain:

Front-wheel drive system, CV joints, axles, differentials

Suspension:

Front and rear suspension components, shock absorbers, struts, springs, bushings, alignment specifications

Steering:

Power steering system (pump, rack and pinion, hoses), manual steering components

Brakes:

Front and rear brake systems (discs, pads, calipers, drums, shoes), hydraulic system, ABS (if equipped), parking brake

Electrical:

Battery, charging system (alternator), starting system, lighting, wipers, horn, power windows, power locks, instrument cluster, warning lights, fuses, relays, wiring diagrams

Body And Interior:

Body panels, doors, hood, trunk, bumpers, glass, interior trim, seats, dashboard, climate control system (HVAC), SRS (airbag) system

Chassis:

Frame, subframes, exhaust system

Procedures Included

Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, tune-ups, spark plug replacement, belt replacement, brake inspections, tire rotation

Repair:

Component replacement (engine, transmission, brakes, suspension, steering, electrical), gasket and seal replacement, minor engine adjustments, fuel injector replacement, sensor replacement

Diagnostics:

Troubleshooting guides, diagnostic trouble codes (DTCs) explanation, symptom-based diagnostics, component testing procedures

Rebuild And Overhaul:

Engine overhaul procedures, transmission rebuild instructions

Electrical Schematics:

Detailed wiring diagrams for all major systems

Technical Depth

Depth:

Comprehensive: Covers everything from basic preventive maintenance to complex engine and transmission rebuilds and advanced electrical diagnostics.

📊 Manual Specifications

File Format

File Type:

Searchability:

Searchable text (OCR layer)

Print Quality

Print Readability:

High-resolution images and text for clear printing

Binding Type

Binding:

Not applicable (digital download)

Paper Type

Paper Type:

Not applicable (digital download)

⚙️ Engine Specifications

Primary Engine

Engine Code:

L44 (2.0L DOHC), L43 (2.0L SOHC - less common in SC2, more in SL/SC1)

Engine Type:

Inline 4-cylinder, DOHC (Double Overhead Camshaft)

Displacement:

1898 cc (1.9 Liters)

Performance

Horsepower:

124 hp @ 5600 rpm (DOHC)

Torque:

122 lb-ft @ 4400 rpm (DOHC)

Fuel System

Fuel Delivery:

Multi-port Electronic Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline (87 octane recommended)

Maintenance Items

Spark Plugs:

ACDelco 41-905 or equivalent (e.g., NGK TR5)

Oil Filter Part Number:

ACDelco PF2057 or equivalent

Engine Oil Capacity:

4.0 US quarts (3.8 L) with filter

Engine Oil Specification:

SAE 5W-30 Synthetic Blend or Full Synthetic

Coolant Type:

GM Dex-Cool Long-Life Coolant (Orange) or equivalent silicate-free, ethylene glycol based coolant

🔧 Transmission

Standard

Type:

5-speed Manual Transmission

Optional

Type:

4-speed Automatic Transmission (M30)

Features

Manual Transmission Fluid Spec:

GM Synchromesh Transmission Fluid (or equivalent API GL-4 rated gear oil)

Automatic Transmission Fluid Spec:

Dexron III (or Dexron VI as a compatible replacement)

Automatic Transmission Fluid Capacity:

6.0 US quarts (5.7 L) (dry fill)

📐 Dimensions

Exterior

Wheelbase:

102.4 inches (2601 mm)

Length:

170.1 inches (4320 mm)

Width:

66.9 inches (1700 mm)

Height:

50.6 inches (1285 mm)

Weights

Curb Weight:

Approx. 2750 lbs (1247 kg)

Gross Vehicle Weight Rating:

Approx. 3600 lbs (1633 kg)

Cargo

Trunk Volume:

Approx. 8.0 cu ft (227 L)

🛡️ Safety Features

Ratings

NHTSA Front Impact:

4-star driver, 4-star passenger (for earlier models)

IIHS Side Impact:

Acceptable (depending on year and specific equipment)

Active Features

Optional Anti-lock Braking System (ABS)

Traction Control:

Rarely standard, might be available on later models

Passive Features

Airbags:

Driver and passenger front airbags standard, optional side airbags on some later models

Seatbelts:

3-point front and rear seatbelts

Body Construction:

Spaceframe construction with polymer exterior panels

💡 Technology Features

Infotainment

Audio System:

AM/FM stereo with cassette player, optional CD player. Basic speaker configuration.

Climate Control:

Manual or optional automatic climate control (HVAC system with AC and heater).

Driver Assistance

Cruise Control:

Standard on most SC2 models.

Keyless Entry:

Optional keyless entry system.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 3,000-5,000 miles (4,800-8,000 km) or 6 months, depending on driving conditions and oil used.

Tire Rotation Interval:

Every 6,000-7,500 miles (9,600-12,000 km)

Coolant Flush Interval:

Every 30,000 miles (48,000 km) or 2 years

Transmission Fluid Change Interval Auto:

Every 30,000-60,000 miles (48,000-96,000 km) or as per manual recommendations, especially if towing.

Transmission Fluid Change Interval Manual:

Every 60,000-100,000 miles (96,000-160,000 km) or as per manual recommendations.

Timing Belt Replacement:

Not applicable - the 1.9L Saturn engines use a timing *chain* which is designed to last the life of the engine but requires inspection for wear and tensioner issues.

Known Issues

Engine Issues:

Oil leaks (valve cover gasket, oil pan gasket), PCV valve clogging, radiator hose failure, potential for piston skirt slap on high mileage engines, EGR valve issues.

Transmission Issues:

Automatic transmission solenoid failures, occasional clutch wear in manual transmissions, engine mount degradation.

Suspension Issues:

Worn strut mounts, ball joints, and tie rod ends are common due to age and mileage.

Electrical Issues:

Window motor failures, power lock actuator failures, dashboard warning light issues, alternator bearing noise.

Body Issues:

While polymer panels resist dents, they can be prone to fading or cracking from UV exposure, and mounting points can degrade.

Fluid Specifications

Brake Fluid Type:

DOT 3

Power Steering Fluid Type:

Dexron III (or compatible)

Clutch Fluid Type:

DOT 3 (if hydraulic clutch, common for manual)

📚 Vehicle History

Brand Heritage

Brand Origins:

Saturn was an American automobile division of General Motors (GM), established in 1985 as a separate brand to compete with Japanese manufacturers.

Model Evolution

First Generation:

SC (coupe) was introduced in 1990, based on the S-Series platform.

Second Generation:

The SC2 model was part of the second generation, which launched in 1997. It featured a redesigned exterior and interior, and received a more powerful engine option.

Facelifts:

The SC2 received minor styling updates throughout its production life, including revised front and rear fascias.

Production

Production Years:

1991-2002 (SC and SC1/SC2 nomenclature evolved)

Manufacturing Location:

Spring Hill, Tennessee, USA

Discontinuation

Brand Discontinuation:

GM announced the discontinuation of the Saturn brand in 2009, with final vehicle production ceasing in 2010.

🏆 Awards & Recognition

Recognitions

Past Awards:

Saturn vehicles, including the S-Series, were often praised for their innovative design and value proposition, though specific awards for the SC2 model are less prominent than general brand recognition.

Ratings

Car And Driver:

Often featured in '10 Best' lists for its class and price point during its production run.
