🏷️ Basic Information

Make:

SsangYong

Model:

Korando

Model Designation:

Korando C (C200)

Year:

2010

Engine Code:

D20DTF

👋 Introduction

Segment:

Compact SUV / Crossover.

Target Audience:

Owners seeking to perform maintenance and repairs, and professional automotive technicians.

Competitors 2010:

SsangYong Korando C competed against vehicles like the Hyundai ix35, Kia Sportage, Nissan Qashqai, and Ford Kuga in its segment.

Manual Benefit 1:

Enables DIY repairs, saving on labor costs.

Manual Benefit 2:

Provides factory-level accuracy for all procedures.

Manual Benefit 3:

Includes detailed diagrams for clarity and accuracy.

Manual Benefit 4:

Covers a wide range of systems for complete vehicle servicing.

Manual Benefit 5:

Facilitates efficient troubleshooting and repair.

📋 Manual Details

Primary Coverage:

Complete factory service repair workshop manual

Specific Topics:

Vehicle general, Engine (D20DTF), Turbocharger, Fuel System, Lubrication, Cooling, Starting, Cruise Control, EGR, CDP (Catalytic Diesel Particulate Filter), Engine Control, Electrical Systems, Fuses & Relays, BCM (Body Control Module), Instrument Cluster, Switches, Lamps, Wiper/Washer, Parking Aid, Audio, Chassis, DSI 6-speed Automatic Transaxle, 6-speed Manual Transmission, Clutch, Propeller Shaft, Drive Shafts/Axles, AWD, Suspension, Brakes, ABS (Anti-lock Braking System), ESP (Electronic Stability Program), Power Steering, Electric Power Steering, Subframe, Body, Air Conditioning, Airbag System, Seats, Sunroof, Interior, Exterior, Body Repair, Electrical Wiring Diagrams

Estimated Pages:

Comprehensive (exact count not specified, but content suggests extensive detail)

Type:

Service Repair Workshop Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Powertrain:

Engine D20DTF, Turbocharger, Fuel System, Lubrication System, Cooling System, Charge System, Pre-heating, Starting System, Transmission (DSI 6-speed Auto, 6-speed Manual), Clutch, Drivetrain (Propeller Shaft, Drive Shafts, Axles, AWD).

Chassis And Suspension:

Suspension System, Brakes System, Anti-lock Brake System (ABS), Electronic Stability Program (ESP), Power Steering System, Electric Power Steering, Subframe Assembly, Wheels & Tires.

Body And Interior:

Air Conditioning System, Airbag System, Seats, Sunroof System, Body Interior, Body Exterior, Body Repair.

Electrical And Electronics:

Electrical General Information, Fuses and Relays, Body Control Module (BCM), Instrument Cluster, Switches, Lamps, Wiper Washer System, Parking Aid System (PAS), Audio System, Electrical Wiring Diagrams (General Information, Connectors, Ground Points, Power Distribution, Circuits).

Diagnostics And Troubleshooting:

Comprehensive diagnostic procedures, troubleshooting guides for all covered systems, fault code interpretation (likely implied).

Repair And Rebuild:

Step-by-step instructions for disassembly, repair, and reassembly of all major vehicle components, including engine, transmission, suspension, brakes, and body systems.

Maintenance And Servicing:

Routine maintenance procedures, fluid changes, filter replacements, tune-ups, and component inspections.

Electrical System Repair:

Wiring diagram interpretation, component testing, repair of electrical circuits, and troubleshooting of electronic modules.

Body Repair:

Procedures for body panel repair, dent removal, and potential structural repair guidance.

Depth:

Full factory-level repair and diagnostic information suitable for both DIY enthusiasts and professional mechanics, covering complete disassembly and assembly.

📊 Manual Specifications

Format:

PDF

Compatibility:

All versions of Windows & Mac

Requirements:

Adobe PDF Reader & WinZip

Quality:

High-quality diagrams and easy-to-read text sections.

Printability:

All pages are printable.

Type:

Digital Download (No physical binding)

Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Type:

Diesel, Turbocharged Direct Injection

Engine Code:

D20DTF

Displacement:

2.0 Liters (1998 cc)

Horsepower Approx:

170-175 PS (125-129 kW)

Torque Approx:

360-370 Nm (265-273 lb-ft)

Fuel Type:

Diesel

Injection System:

Common Rail Direct Injection (CRDi)

Turbocharger:

Yes, variable geometry turbocharger (VGT) is likely.

Emissions Control:

EGR (Exhaust Gas Recirculation), CDP (Catalytic Diesel Particulate Filter) system included in manual coverage.

🔧 Transmission

Type:

DSI 6-speed Automatic Transaxle

Type:

6-speed Manual Transmission

Automatic Modes:

Likely includes sequential shift or driver-selectable modes (Sport/Economy).

Automatic Fluid Type:

Refer to manual for specific DSI fluid specifications (e.g., ATF Dexron-VI compatible or specific DSI fluid).

Manual Fluid Type:

Refer to manual for specific manual transmission fluid (MTF) specifications.

📐 Dimensions

Body Style:

Compact SUV

Length Approx:

4410 mm (173.6 inches)

Width Approx:

1810 mm (71.3 inches)

Height Approx:

1675 mm (66.0 inches)

Wheelbase Approx:

2650 mm (104.3 inches)

Curb Weight Approx:

1600-1700 kg (3527-3748 lbs) depending on configuration

Towing Capacity Approx:

Refer to vehicle documentation, typically around 1500 kg (3307 lbs) braked.

Standard Wheel Size:

Likely 17-inch or 18-inch alloy wheels.

Standard Tire Size:

Common sizes include 225/60 R17 or 235/55 R18. Refer to manual for exact specifications.

🛡️ Safety Features

Euroncap Rating:

4 Stars (for the Korando C model, generally)

Braking Systems:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA).

Stability Control:

Electronic Stability Program (ESP) / Electronic Stability Control (ESC).

Parking Aid:

Parking Aid System (PAS) covered in manual.

Airbags:

Front airbags, side airbags, curtain airbags (coverage of the Air Bag System).

Seat Belts:

Pre-tensioning seatbelts are standard for this era.

Body Construction:

Reinforced safety cage construction.

💡 Technology Features

Audio System Features:

Likely includes AM/FM radio, CD player, possibly MP3/USB/Aux input, and speaker systems. Manual covers Audio System details.

Parking Assist:

Parking Aid System (PAS) with potential sensors and alerts.

Bluetooth:

Optional Bluetooth connectivity for hands-free calling and audio streaming may be present, refer to Audio System section.

🔧 Maintenance

Oil Change Interval:

Typically 10,000-15,000 km (6,000-9,000 miles) or 12 months, whichever comes first. Refer to manual for exact D20DTF recommendation.

Air Filter Replacement:

Generally every 30,000-45,000 km (18,000-28,000 miles) or as needed based on operating conditions.

Fuel Filter Replacement:

Typically 40,000-60,000 km (25,000-37,000 miles) for diesel engines.

Engine Oil Type:

API SN/CF or ACEA C3 rated synthetic oil, 5W-30 viscosity is common for diesel engines of this era. Refer to manual for exact D20DTF specification.

Coolant Type:

Ethylene Glycol based coolant with silicate inhibitors (e.g., G11/G12 equivalent). Refer to manual for precise SsangYong specification.

Brake Fluid Type:

DOT 4

Diesel Particulate Filter:

Potential for DPF clogging if regeneration cycles are not completed due to frequent short trips, especially relevant with CDP system.

Turbocharger Reliability:

While generally robust, turbocharger issues can arise from lack of maintenance or oil starvation, covered in engine section.

Transmission Software:

Some early DSI automatic transmissions could benefit from software updates for improved shift quality; the manual may detail diagnostic procedures.

Engine Head Bolts:

Detailed torque sequence and values for cylinder head bolts are critical and found within the manual's engine assembly section.

📚 Vehicle History

Origin:

SsangYong Motor Company is a South Korean manufacturer.

Specialization:

Historically known for SUVs and off-road vehicles.

First Generation Start:

The Korando nameplate dates back to 1983, initially a licensed version of the Jeep CJ-7.

Third Generation Introduction:

The Korando C (C200) represented a significant modernization and styling shift for the model, moving to a more contemporary unibody crossover design.

Manufacturing Location:

South Korea

🏆 Awards & Recognition

Crash Safety Award:

Euro NCAP 4-star rating indicates good performance in safety tests for the period.
