Suzuki DL 1000 V-Strom Complete Workshop Service Repair Manual 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Suzuki Model: DL1000 V-Strom Product Type: Complete Workshop Service Repair Manual 👋 Introduction Market Position Category: Adventure Touring Motorcycle Segment: Large-displacement sport-tourer with off-road capability...

25 people are viewing this right now

类型: Motorcycle

斯库: 451125

标签: 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 DL 1000 V-Strom Featured Misc Motorcycle Motorcycles Suzuki

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

DL1000 V-Strom

Product Type:

Complete Workshop Service Repair Manual

👋 Introduction

Market Position

Category:

Adventure Touring Motorcycle

Segment:

Large-displacement sport-tourer with off-road capability

Competitive Analysis

Competitors:

BMW R1150GS/R1200GS, Honda VFR/ST1300, Kawasaki Concours 14, Yamaha FJR1300.

Key Features

Versatility:

Designed for long-distance touring, commuting, and light off-road excursions.

Engine Configuration:

V-twin engine known for its torque and linear power delivery.

Chassis Design:

Aluminum twin-spar frame for rigidity and light weight.

Ergonomics:

Upright riding position, comfortable for extended periods.

📋 Manual Details

Coverage Areas

Applicable Years:

2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010

Page Count

Estimated Pages:

Approximately 500+

Manual Type

Type:

Workshop Service Repair Manual

Language

Language:

English

Format

Format:

Digital Download (PDF)

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Complete engine disassembly, inspection, repair, and reassembly. Includes cylinder head, pistons, crankshaft, camshafts, valve train, timing chain, oil pump.

Fuel System:

Fuel injection system (throttle body, injectors, fuel pump, pressure regulator), fuel tank, fuel lines.

Ignition System:

Ignition coils, spark plugs, ignition control module, wiring.

Cooling System:

Radiator, cooling fan, thermostat, water pump, coolant passages.

Exhaust System:

Exhaust pipes, mufflers, catalytic converter (if applicable).

Transmission Drivetrain:

Clutch operation, gearbox internals, shift mechanism, final drive (chain and sprockets).

Suspension System:

Front telescopic forks (adjustment, servicing, seal replacement), rear monoshock absorber (pre-load adjustment, linkage maintenance).

Braking System:

Front and rear disc brakes, brake calipers, master cylinders, brake lines, brake fluid replacement.

Electrical System:

Battery, charging system (alternator, rectifier/regulator), starter motor, lighting (headlight, taillight, turn signals), instrumentation, fuses, relays, wiring diagrams.

Frame Chassis:

Frame inspection, fairing removal and installation, seat, fuel tank mounting.

Wheels Tires:

Wheel bearing inspection and replacement, tire mounting and balancing.

Steering System:

Handlebar, steering stem bearings (adjustment, repacking).

Bodywork:

Removal and installation of fairings, body panels, seat, luggage rack components.

Procedures Included

Scheduled Maintenance:

Detailed procedures for oil changes, filter replacements, chain lubrication and adjustment, spark plug replacement, air filter cleaning/replacement, brake fluid flush, coolant flush.

Troubleshooting:

Systematic diagnostic procedures for common problems, error code interpretations (if applicable for the model generation), electrical system diagnostics.

Repair Procedures:

Step-by-step instructions for component removal, repair, and installation across all major systems.

Engine Overhaul:

Comprehensive guidance for complete engine rebuilds, including torque specifications for all critical fasteners.

Suspension Rebuild:

Detailed instructions for servicing and rebuilding front forks and rear shock absorbers.

Electrical Diagnostics:

Flowcharts and procedures for diagnosing electrical faults, including complete wiring diagrams.

Diagnostic Tools:

Guidance on using basic tools and diagnostic techniques, potential mention of Suzuki diagnostic connectors or service tools where applicable.

Technical Depth

Depth:

Comprehensive from basic maintenance to complete engine and chassis rebuilds. Suitable for both novice and experienced mechanics.

Wiring Diagrams:

Includes detailed, often color-coded, wiring diagrams for the entire motorcycle electrical system.

Torque Specifications:

Comprehensive list of all critical torque specifications for engine, chassis, and suspension fasteners.

Special Tools:

Lists required special tools for specific procedures, aiding in accurate repairs.

📊 Manual Specifications

File Format

File Type:

Portable Document Format (PDF)

Print Quality

Resolution:

High-resolution scans for clear text and images, suitable for printing.

Binding Type

Binding Type:

N/A (Digital)

Paper Type

Paper Type:

N/A (Digital)

Searchability

Text Search:

Searchable text for quick information retrieval.

⚙️ Engine Specifications

Primary Engine

Engine Type:

Liquid-cooled, four-stroke, DOHC, 90-degree V-twin

Displacement:

996 cc

Bore X Stroke:

98.0 mm x 66.0 mm

Compression Ratio:

11.3:1

Performance

Horsepower:

Approx. 98 hp @ 7600 rpm (for early models)

Torque:

Approx. 74 lb-ft @ 6400 rpm (for early models)

Fuel System

Fuel Delivery:

Digital Fuel Injection (SDTV - Suzuki Dual Throttle Valve)

Fuel Type:

Unleaded gasoline, 91 octane (AKI) or higher

Lubrication

Oil Type:

Suzuki recommends API SG, SH, SJ, or SL, JASO MA certified 10W-40 motorcycle oil.

🔧 Transmission

Standard

Type:

6-speed constant mesh

Features

Clutch Type:

Wet, multi-plate

Final Drive:

O-ring sealed chain

Fluid Requirements

Transmission Oil Type:

Suzuki recommends Suzuki Gear Oil SAE 80W API GL-5 or equivalent for the final drive.

📐 Dimensions

Exterior

Length:

Approx. 2285 mm (89.9 in)

Width:

Approx. 870 mm (34.3 in)

Height:

Approx. 1370 mm (53.9 in)

Wheelbase:

Approx. 1530 mm (60.2 in)

Weights

Dry Weight:

Approx. 207 kg (456 lbs)

Wet Weight:

Approx. 230 kg (507 lbs)

Fuel Capacity:

22.0 L (5.8 US gal)

🛡️ Safety Features

Ratings

Crash Test Ratings:

N/A (Motorcycle safety is not rated by traditional bodies like NHTSA/Euro NCAP)

Active Features

Braking System:

Optional Anti-lock Braking System (ABS) available on many models.

Passive Features

Lighting:

Multi-reflector halogen headlight, LED taillight.

💡 Technology Features

Infotainment

Instrumentation:

Analog tachometer, digital speedometer, LCD multi-information display including fuel gauge, odometer, trip meters, clock, engine temperature, gear position indicator (on later models).

Driver Assistance

Available as an optional feature on most model years within this range.

Connectivity

Charging Port:

No integrated USB or 12V power outlet as standard, though aftermarket installation is common.

Engine Management

Engine Control Unit (ECU) with fuel injection mapping.

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 6,000 km (3,700 miles) or 6 months, whichever comes first.

Oil Filter Replacement:

At every engine oil change.

Spark Plug Replacement:

Every 24,000 km (15,000 miles).

Valve Clearance Check:

Every 24,000 km (15,000 miles).

Chain Lubrication Adjustment:

Every 1,000 km (600 miles) and after washing or riding in rain.

Fluid Specifications

Coolant Type:

Suzuki recommends a mixture of 50% permanent type antifreeze and 50% distilled water.

Brake Fluid Type:

DOT 4

Known Issues

Common Wear Item:

Clutch wear, fork seal leaks, rear shock absorber degradation over time.

Electrical Concern:

Stator/R/R issues reported on some early models, though improvements were made.

Engine Characteristic:

Some models experienced a snatchy throttle response at low RPMs, partially addressed by ECU re-mapping and other modifications.

📚 Vehicle History

Brand Heritage

Manufacturer:

Suzuki Motor Corporation, a Japanese multinational corporation known for automobiles, motorcycles, and marine engines.

Model Evolution

Introduction Year:

2002 model year (for the DL1000 V-Strom)

Generation 1 Period:

2002-2009 (with minor updates, including ABS introduction and chassis enhancements).

Engine Source:

Derived from the TL1000 sportbike series, adapted for torque and touring.

Production

Manufacturing Location:

Primarily Japan.

🏆 Awards & Recognition

Recognitions

Industry Accolades:

Consistently praised by motorcycle publications for its value, performance, and versatility in the adventure touring segment.

Ratings

Value For Money:

Often cited as a strong contender offering a significant portion of the performance and features of more expensive European rivals.
