2008-2014 Suzuki KING QUAD 400 (LT-A400/F LT-F400/F) Service Repair Manual (Highly Detailed FSM PDF Preview) Download

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

Owning a Suzuki KingQuad 400 means having a rugged, dependable ATV built for adventure—but even the toughest machines need expert care. This Factory Service Manual is your ultimate guide to...

22 people are viewing this right now

类型: Atv

斯库: 43725

标签: 2008 2009 2010 2011 2012 2013 2014 Atv Engines Featured King Air KING QUAD 400 LT-A400 LT-A400F LT-F400 LT-F400F Suzuki

产品多属性

Description

Owning a Suzuki KingQuad 400 means having a rugged, dependable ATV built for adventure—but even the toughest machines need expert care. This Factory Service Manual is your ultimate guide to maintaining, repairing, and optimizing your KingQuad 400 (2008–2014), ensuring it delivers peak performance for years to come.

Why this manual is indispensable:

Dealer-Level Expertise: Identical to the manuals used by Suzuki technicians, covering every system—from engine overhauls to electrical diagnostics.
Comprehensive Coverage: 516 pages of step-by-step instructions, torque specs, and wiring diagrams for all variants (LT-A400/F, LT-F400/F).
DIY Confidence: Tackle oil changes, brake servicing, or even a full transmission rebuild with precision—no guesswork.

Key features at a glance:

Searchable PDF: Instantly find what you need with bookmarks and a digital index.
Detailed Diagrams: Exploded views and part breakdowns for every component.
Troubleshooting Guides: Diagnose issues like a pro with symptom-based flowcharts.

Whether you’re a seasoned mechanic or a hands-on owner, this manual pays for itself with saved repair costs and extended ATV longevity. Don’t settle for shortcuts—equip yourself with the same knowledge Suzuki dealers rely on.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

KingQuad 400

Model Designations:

LT-A400, LT-A400F, LT-F400, LT-F400F

Model Variant As:

Automatic Transmission, 2WD

Model Variant As 4Wd:

Automatic Transmission, 4WD

Model Variant Fs:

Manual Transmission, 2WD

Model Variant Fs 4Wd:

Manual Transmission, 4WD

Codes

Chassis Code Prefix:

LT-A400, LT-F400

Generation

Generation Name:

Second Generation KingQuad 400

Covered Years:

2008-2014

👋 Introduction

Market Position

Product Type:

High-quality, comprehensive workshop service and repair manual

Target Audience:

Suzuki KingQuad 400 owners, DIY mechanics, independent repair shops

Competitive Analysis

Value Proposition:

Cost-effective alternative to dealer service, enabling self-sufficient maintenance and repair

Differentiation:

Improves upon standard manuals with enhanced PDF features (bookmarks, search, index) for better usability

Key Features

Dealer Equivalence:

Contains the same information used by authorized Suzuki dealerships

Completeness:

Covers all aspects from basic maintenance to complete rebuilds

Accessibility:

Instant download, printable pages for garage/workshop use

📋 Manual Details

Coverage Areas

Primary Focus:

2008-2009 Suzuki KingQuad 400 models (LT-A400/F, LT-F400/F)

Extended Applicability:

Minor changes through 2014 models

Page Count

Total Pages:

Manual Type

Type:

Factory Service Manual (FSM) / Workshop Repair Manual

Language

Language:

English

Format

Format:

PDF (Searchable Text, Bookmarks, Index)

📖 Manual Coverage

Systems Covered

Engine:

Engine overhaul, tuning, troubleshooting, specifications

Transmission:

Automatic (CVT) and Manual transmission repair, maintenance, fluid changes

Driveline:

Front and rear driveshaft, differentials, axle maintenance and repair

Suspension:

Front forks, rear shock absorber, linkages, adjustments, maintenance

Brakes:

Hydraulic brake system inspection, service, pad replacement, bleeding

Steering:

Steering system components, tie rods, bushings, alignment

Electrical:

Ignition system, charging system (stator, rectifier), starter motor, lighting, wiring diagrams

Body Accessories:

Body panels, fenders, seat, racks, trim, accessories installation and repair

Fuel System:

Carburetor (or EFI if applicable for later models covered by extension), fuel pump, fuel tank, lines

Cooling System:

Radiator, fan, coolant, hoses, thermostat (if applicable)

Procedures Included

Maintenance:

Scheduled maintenance, lubrication points, fluid changes, filter replacements

Troubleshooting:

Diagnostic procedures for common issues, error codes, symptom-based diagnosis

Repair:

Step-by-step repair instructions for all major components and systems

Rebuild:

Complete engine and transmission tear-down and rebuild procedures

Installation:

Instructions for installing aftermarket parts or accessories (implied by scope)

Calibration Adjustment:

Carburetor adjustment, valve clearance adjustment, clutch adjustment

Technical Depth

Depth:

Comprehensive, dealer-level service and repair information

Detail Level:

Detailed diagrams, part breakdowns, torque specifications, and procedures

Diagnostic Capability:

Advanced diagnostics for electrical and mechanical issues

📊 Manual Specifications

File Format

Format:

Readability Software:

Adobe PDF Reader

Print Quality

Printability:

Printable without restriction

Text Searchability:

Searchable text functionality

Binding Type

Binding Type:

Digital Download (N/A for physical binding)

Paper Type

Paper Type:

Digital (N/A for physical paper)

⚙️ Engine Specifications

Primary Engine

Engine Type:

4-stroke, SOHC, 2-valve

Engine Displacement:

376 cc (23.0 cu. in.)

Bore X Stroke:

81.0 mm x 72.0 mm (3.19 in x 2.83 in)

Compression Ratio:

9.3 : 1

Performance

Horsepower:

Approximately 25-27 HP (Estimate based on similar models)

Torque:

Not explicitly stated in product info, but significant low-end torque for off-road application.

Fuel System

Fuel Delivery:

Fuel injection (EFI) for 400F models, Carbureted for 400 models (earlier spec, though product mentions EFI in tags, this manual likely covers carbureted primarily with later models being similar).

Fuel Type:

Unleaded gasoline

Fuel Tank Capacity:

4.6 L (1.2 US gal) - Standard for this generation.

🔧 Transmission

Standard

Type:

Automatic (CVT with V-belt) for LT-A models, 5-speed manual with reverse for LT-F models

Optional

Optional Transmission:

N/A - Variants are based on transmission and drive type.

Features

Cvts Features:

Engine braking, high/low range selection (typical for KingQuad)

Manual Features:

Standard clutch operation, reverse gear

Fluid Specifications

Transmission Fluid:

Refer to manual for specific Suzuki transmission fluid or equivalent SAE 10W-40 API SG or higher (common for this era).

📐 Dimensions

Exterior

Overall Length:

Approx. 1970 mm (77.6 in)

Overall Width:

Approx. 1165 mm (45.9 in)

Overall Height:

Approx. 1160 mm (45.7 in)

Weights

Curb Weight:

Approx. 260-270 kg (573-595 lbs) depending on 2WD/4WD

Ground Clearance:

Approx. 260 mm (10.2 in)

🛡️ Safety Features

Ratings

Safety Standards:

As per ATV safety regulations of the time.

Active Features

Braking System:

Hydraulic disc brakes (front and rear)

Drive Modes:

2WD/4WD selectable (on 4WD models)

Passive Features

Frame Construction:

Steel frame for durability and rigidity

💡 Technology Features

Infotainment

Infotainment System:

N/A - Basic instrumentation focused on function and durability.

Driver Assistance

Driver Assistance Features:

Engine braking (CVT models), selectable 2WD/4WD.

Connectivity

Connectivity:

N/A - No electronic connectivity features.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Refer to manual; typically every 1000 km or 6 months.

Air Filter Cleaning:

Regular inspection and cleaning, especially in dusty conditions.

Spark Plug Check:

Intervals for checking and replacing as per manual recommendations.

Valve Clearance Adjustment:

Refer to manual for mileage/time intervals, typically around 2000-4000 km.

Fluid Specifications

Engine Oil Type:

SAE 10W-40 API SG or higher (e.g., Suzuki Performance Oil 4T or equivalent).

Engine Oil Capacity:

Approx. 2.2 L (2.3 US qt) without filter, 2.4 L (2.5 US qt) with filter change.

Coolant Type:

Ethylene glycol-based antifreeze coolant, 50/50 mix with distilled water.

Brake Fluid Type:

DOT 3 or DOT 4 hydraulic brake fluid.

Known Issues

Common Wear Items:

Brake pads, tires, drive belts (CVT), suspension bushings, wheel bearings.

Potential Electrical:

Stator or rectifier failures can occur over time, as with many ATVs. Charging system checks are important.

Carburetor Issues:

Clogged jets or pilot circuits can affect performance, especially with ethanol fuels or infrequent use.

📚 Vehicle History

Brand Heritage

Manufacturer:

Suzuki Motor Corporation, known for reliable and capable off-road vehicles.

Model Evolution

Kingquad Lineage:

The KingQuad 400 is a descendant of Suzuki's long-standing ATV development, offering a balance of performance and utility.

Second Gen Updates:

The 2008 update brought revised styling and potential minor mechanical refinements over earlier generations.

Production

Production Period:

Continuously produced with updates across multiple generations, with this manual covering a key period.

🏆 Awards & Recognition

Recognitions

Industry Recognition:

While specific awards for this exact model year aren't detailed, Suzuki KingQuads have consistently been recognized for their ruggedness and capability in the ATV market.

Ratings

Consumer Perception:

Generally regarded as a reliable and hardworking utility ATV.
