2007-2010 Suzuki LT-A450X KingQuad Service Manual Repair Manuals

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

27 people are viewing this right now

类型: Atv

斯库: 51771

标签: 2007 2008 2009 2010 ATV King Quad Models LT-A450X KingQuad Powersports Suzuki

产品多属性

Description

This manual covers the LT-A450X KingQuad All-Terrain Vehicle (ATV) for the model years 2007 through 2010. Engineered for robust performance and reliability, the LT-A450X features a 4-stroke, liquid-cooled, 448 cc engine with Fuel Injection, providing efficient power delivery. Its advanced suspension system, including independent double wishbones with adjustable shock absorbers, ensures excellent handling and comfort across varied terrain. The KingQuad's robust chassis, selectable 2WD/4WD system with a locking front differential, and substantial rack capacities make it a versatile machine for both work and recreational trail riding, embodying a commitment to durable and capable powersports vehicles. This comprehensive guide serves as both a Service Manual and Owner's Manual, offering detailed information to ensure the optimal performance and longevity of your 2007-2010 LT-A450X KingQuad. It provides step-by-step procedures for all maintenance tasks, from routine oil changes and filter replacements to complex engine overhauls and electrical system diagnostics. Key areas covered include engine, transmission, suspension, brakes, fuel system, and electrical components, complete with troubleshooting guides, exploded parts diagrams, and technical specifications. This manual is an essential resource for owners and technicians, enabling effective maintenance, repair, and a deeper understanding of the vehicle's systems.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

LT-A450X KingQuad

Model Years Covered:

2007, 2008, 2009, 2010

Vehicle Type:

All-Terrain Vehicle (ATV)

Product Type:

Service Manual & Owner's Manual Bundle

Codes

Internal Model Code Prefix:

LT-A450X

👋 Introduction

Market Position

Positioning:

Positioned as the 'BEST ATV Service Manual' for the specified model years, offering comprehensive coverage.

Competitive Analysis

Differentiation:

Claims to be a meticulously matched, collected, and confirmed set, differentiating from generic multi-year manuals. Emphasizes quality and accuracy over quantity of years covered if no changes exist.

Key Features

Feature 1:

Bundled Service and Owner's Manuals.

Feature 2:

Detailed procedures with pictures.

Feature 3:

Exploded parts diagrams.

Feature 4:

Comprehensive troubleshooting and electrical diagnostics.

Feature 5:

Searchable and printable PDF format.

📋 Manual Details

Coverage Areas

Primary Coverage:

2007-2010 Suzuki LT-A450X KingQuad Service and Owner's Manuals

Supplementary Coverage Confirmation:

Verified inclusion of any supplementary manuals needed for model year variations.

Page Count

Estimated Total Pages:

Approximately 700 pages (combined)

Manual Type

Service Manual:

Owner'S Manual:

Repair Manual:

Shop Manual:

Workshop Guide:

Language

Primary Language:

English

Format

Delivery Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine:

Complete overhaul, disassembly, assembly, valve jobs, tuning.

Transmission:

Clutch, gearbox, final drive, maintenance, and repair.

Suspension:

Front and rear suspension, shock absorbers, control arms, adjustment procedures.

Brakes:

Hydraulic system, caliper, master cylinder, pad replacement, bleeding procedures.

Electrical System:

Wiring diagrams, troubleshooting, ignition system, lighting, charging system, starter.

Fuel System:

Fuel injection system, fuel pump, injectors, fuel filter replacement.

Cooling System:

Radiator, fan, thermostat, coolant flush and fill procedures.

Chassis And Frame:

Frame inspection, component mounting, basic structural checks.

Bodywork And Plastics:

Panel removal, installation, care, and minor repair.

Wheels And Tires:

Tire pressure, wear inspection, wheel bearing maintenance, tire replacement.

Procedures Included

Basic Maintenance:

Oil changes, filter replacements, lubrication, inspections.

Troubleshooting:

Diagnostic charts, symptom-based problem solving, electrical issue diagnosis.

Engine Rebuild:

Complete engine disassembly, inspection, parts replacement, and reassembly.

Valve Adjustment:

Detailed procedure for checking and adjusting valve clearances.

Transmission Service:

Gearbox disassembly, clutch inspection, fluid changes.

Suspension Repair:

Replacement of wear items, shock absorber servicing.

Brake Maintenance:

Brake pad replacement, rotor inspection, hydraulic system bleeding.

Electrical Diagnostics:

Use of wiring diagrams, testing components, identifying shorts and opens.

Technical Depth

Depth Of Coverage:

Comprehensive, from basic maintenance to full engine rebuilds and complex electrical troubleshooting.

Detail Level:

Detailed procedures with accompanying pictures and step-by-step instructions.

Diagrams:

Includes exploded parts diagrams for component identification and assembly.

Scope:

Covers servicing 'Wheel to Wheel'.

📊 Manual Specifications

File Format

Format:

Searchability:

Keyword searchable (Ctrl+F functionality enabled).

Printability:

Printable

Organization:

Bookmarked for easy navigation.

Print Quality

Quality Description:

High quality, straight to the point.

Binding Type

Binding Type:

N/A (Digital PDF)

Paper Type

Paper Type:

N/A (Digital PDF)

⚙️ Engine Specifications

Primary Engine

Engine Type:

4-stroke, Single Cylinder, DOHC, 4-valve, Liquid-cooled

Displacement:

448 cc (27.3 cu. in.)

Bore X Stroke:

94.0 mm x 82.0 mm (3.70 in. x 3.23 in.)

Performance

Compression Ratio:

9.3 : 1

Fuel System

Fuel Delivery:

Suzuki Fuel Injection (SDTV - Suzuki Dual Throttle Valve)

Recommended Fuel:

Unleaded gasoline

Lubrication

Oil Type:

SAE 10W-40 API SG or higher, JASO MA certified

Oil Capacity With Filter Change:

3.2 L (3.3 US qt)

Ignition

Ignition System:

Electronic ignition (CDI)

Cooling

Cooling Method:

Liquid-cooled

🔧 Transmission

Standard

Transmission Type:

Automatic transmission with torque converter and belt-drive system.

Drive System:

Automatic, shaft drive with 2WD/4WD selection and locking front differential.

Features

Gear Selection:

High/Low range with Reverse.

Fluid Specifications

Transmission Fluid Type:

Suzuki Gear Oil API GL-5, SAE 80W-90 (for front and rear differentials)

📐 Dimensions

Exterior

Overall Length:

2130 mm (83.9 in)

Overall Width:

1150 mm (45.3 in)

Overall Height:

1160 mm (45.7 in)

Weights

Curb Weight:

279 kg (615 lbs)

Fuel Tank Capacity:

17.5 L (4.6 US gal)

Cargo

Front Rack Capacity:

20 kg (44 lbs)

Rear Rack Capacity:

40 kg (88 lbs)

Wheels And Tires

Front Tire Size:

AT25 x 8-12

Rear Tire Size:

AT25 x 10-12

Wheelbase:

1285 mm (50.6 in)

Suspension

Front Suspension Type:

Independent, double wishbone, gas-charged shock absorbers with adjustable spring pre-load.

Rear Suspension Type:

Independent, double wishbone, gas-charged shock absorbers with adjustable spring pre-load and rebound damping.

Ground Clearance:

275 mm (10.8 in)

💡 Technology Features

Infotainment

Infotainment System:

Not applicable for this model year ATV. Focus is on mechanical and electrical operation.

Driver Assistance

Driver Assistance Features:

Limited to the functional aspects of the 2WD/4WD system and differential lock, which aids in traction and control.

Connectivity

Connectivity Features:

Not applicable for this model year ATV.

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 1,000 km (600 miles) or 6 months, whichever comes first.

Air Filter Cleaning:

Every 1,000 km (600 miles) or 6 months (more frequently in dusty conditions).

Spark Plug Replacement:

Refer to manual for specific interval, typically around 6,000 km (3,700 miles) or annually.

Valve Clearance Check:

Every 2,000 km (1,200 miles) or 12 months.

Fluid Specifications

Engine Oil Grade:

SAE 10W-40 API SG or higher, JASO MA certified

Coolant Type:

Suzuki Super Long Life Coolant or equivalent (50/50 mix of ethylene glycol and de-ionized water).

Brake Fluid Type:

DOT 4 brake fluid.

Known Issues

Common Wear Items:

Common ATV wear items include brake pads, tires, suspension bushings, and drive belts. The manual will provide specific wear limits and replacement procedures.

Common Issues

Drive Belt Maintenance:

The CVT drive belt is a critical component; the manual will detail inspection and replacement procedures, as well as potential issues related to belt slippage or breakage.

Electrical Connections:

Corrosion on electrical connectors, especially in off-road environments, can lead to intermittent issues. The manual's electrical troubleshooting section is vital.

📚 Vehicle History

Brand Heritage

Manufacturer:

Suzuki Motor Corporation

Industry Segment:

Powersports, ATV manufacturing.

Model Evolution

Kingquad Lineage:

The KingQuad line has a reputation for performance and ruggedness in the ATV market. The LT-A450X represents Suzuki's focus on utility and trail riding capabilities within this series.

Production

Manufacturing Location:

Likely manufactured in Japan or potentially other Suzuki global facilities.
