Atv Segment:
High-performance, utility-focused ATV, positioned for serious recreational and working use.
Key Competitors Era:
Yamaha Kodiak/Grizzly, Honda Foreman/Rancher, Polaris Sportsman.
Model Selling Points:
Powerful 700cc engine, independent rear suspension (IRS), electronic fuel injection (EFI), robust chassis for demanding terrain.
Target Audience:
DIY enthusiasts, home mechanics, and professional technicians seeking to service, repair, restore, or maintain the specified Suzuki King Quad models.
Engine Management:
Fuel Injection (FI) System Diagnosis, Fuel System, Throttle Body
Powertrain:
Engine Overhaul, Drive Train (including differentials, driveshafts, CV joints)
Chassis And Suspension:
Chassis Components, Suspension System, Steering System
Electrical And Electronics:
Electrical System, Wiring Diagrams, Ignition System, Lighting System, Starting and Charging Systems
General Information And Servicing:
Includes general information, safety precautions, servicing information, and vehicle identification (VIN) details.
Body And Frame:
Body panels, fenders, racks, frame inspection and repair.
Maintenance Tasks:
Periodic Maintenance, Oil Changes, Filter Replacements, Lubrication Schedules
Diagnostic Procedures:
Troubleshooting Guides, Symptom-Based Diagnostics, Error Code Interpretation (for FI system)
Repair And Rebuild:
Complete Engine Rebuild, Transmission Overhaul, Component Replacement, Body Panel Repair
Diagnostic Tools And Techniques:
Covers diagnostic procedures for the fuel injection system, including troubleshooting charts and potential fault codes.
Depth Of Coverage:
A-Z (from basic maintenance to full restoration and rebuilding), including factory specifications and procedures.
Repair Level:
Covers everything from routine maintenance and adjustments to complete engine and transmission overhauls, including suspension and electrical system repairs.
Engine Type:
4-stroke, SOHC, 4-valve, Liquid-cooled V-twin
Engine Displacement:
695 cc
Estimated Horsepower:
Approximately 45-50 HP (varies slightly by year and region)
Estimated Torque:
Approximately 45-50 lb-ft (varies slightly by year and region)
Fuel Delivery:
Electronic Fuel Injection (EFI)
Throttle Body Diameter:
Typically 42mm
Fuel Requirement:
Unleaded gasoline, minimum octane rating of 87.
Oil Type Specification:
SAE 10W-40 API SG or higher (Specific Suzuki recommendation should be verified in manual)
Coolant Type Specification:
Suzuki Long Life Coolant or equivalent (50/50 mix with distilled water)
Transmission Type:
Automatic (CVT - Continuously Variable Transmission)
Gear Selection:
H (High), L (Low), N (Neutral), R (Reverse), P (Park)
Drive Modes:
2WD/4WD selector, Electric front differential lock
Cvt Fluid Type:
Suzuki's specific CVT fluid or equivalent (e.g., Suzuki recommends SUZUKI SUPER GEAR OIL API GL-4 SAE 75W-90 for final gearcase, but CVT fluid type is specific and crucial)
Overall Length:
Approx. 83.7 inches (2,125 mm)
Overall Width:
Approx. 47.0 inches (1,195 mm)
Overall Height:
Approx. 46.7 inches (1,185 mm)
Front Rack Capacity:
Approx. 110 lbs (50 kg)
Rear Rack Capacity:
Approx. 200 lbs (90 kg)
Dry Weight:
Approx. 580 lbs (263 kg)
Towing Capacity:
Approx. 1,320 lbs (600 kg)
Tongue Weight Capacity:
Approx. 132 lbs (60 kg)
Front Tire Size:
AT25x8-12
Rear Tire Size:
AT25x10-12
Wheel Bolt Pattern:
4x110
Instrumentation:
Digital LCD display including speedometer, odometer, trip meter, fuel gauge, clock, 4WD/2WD indicator, high beam indicator, engine warning lamp.
Electronic Features:
Electric Power Steering (EPS) available on some models/trims, Engine Management System (EMS) with FI.
Diagnostic Ports:
On-board diagnostics (OBD) port for FI system troubleshooting.
Engine Oil Change Interval:
Every 1,000 km (600 miles) or 6 months, whichever comes first (refer to manual for precise interval).
Spark Plug Check Interval:
Check every 1,000 km (600 miles) or 6 months; replace as needed.
Air Filter Cleaning Interval:
Inspect every 500 km (300 miles) or monthly; clean/replace as needed based on operating conditions.
Cvt Belt Inspection Interval:
Inspect at 1,000 km (600 miles) and every subsequent 1,000 km (600 miles) or annually.
Brake Fluid Change Interval:
Recommended every 2 years or as per manual recommendations.
Final Gear Oil Specification:
Suzuki Gear Oil GL-5 SAE 80W-90 (or equivalent)
Common Wear Items:
CVT belt, wheel bearings, brake pads, suspension bushings.
Potential Electrical Concerns:
EFI sensor failures, stator issues (less common but possible).
Suzuki Atv Legacy:
Suzuki has a long history in ATV manufacturing, known for durable and capable machines. The King Quad line is a flagship model.
King Quad Lineage:
The LT-A700 marked a significant advancement with its V-twin engine and advanced features, setting a benchmark for Suzuki's flagship ATV.
Manufacturing Location:
Typically Japan (specific plant may vary).
