Atv Segment:
High-performance utility/sport ATV
Target Audience:
Enthusiasts seeking robust off-road performance, recreational riders, and farm/ranch users.
Competitors 2005:
Yamaha Grizzly 660, Polaris Sportsman 700, Can-Am Outlander 800
King Quad Advantage:
Powerful 700cc engine, sophisticated independent rear suspension (IRS), advanced fuel injection.
Core Benefit:
Enables owners to perform factory-level repairs and maintenance, ensuring longevity and optimal performance of their valuable ATV.
Engine Systems:
Engine disassembly, assembly, inspection, performance tuning, lubrication systems, cooling system, fuel injection system, ignition system, emissions control.
Transmission Drivetrain Systems:
Transmission disassembly, assembly, inspection, gearshift mechanisms, final drive, driveshafts, CV joints.
Chassis Suspension Systems:
Front suspension (double A-arm), rear suspension (swingarm), shock absorbers, steering system, wheel alignment.
Braking Systems:
Front disc brakes, rear disc brakes, hydraulic system, brake pad replacement, caliper maintenance.
Electrical Systems:
Wiring diagrams, battery, charging system (stator, regulator/rectifier), starter motor, lighting, ignition switch, electrical connectors, fuses, sensors.
Fuel System:
Fuel tank, fuel pump, fuel filter, fuel injectors, throttle body, fuel pressure testing.
Bodywork Chassis:
Frame inspection, body panel removal and installation, seat, handlebars, fenders.
Cooling System:
Radiator, cooling fan, coolant hoses, thermostat, coolant type.
Maintenance Procedures:
Oil changes, filter replacements, spark plug replacement, air filter cleaning/replacement, lubrication points, brake fluid flush, coolant flush, valve clearance adjustment.
Repair Procedures:
Complete engine overhaul, transmission rebuild, carburetor/fuel injection system repair, suspension component replacement, brake system repair, electrical component diagnosis and repair.
Troubleshooting Guides:
Systematic diagnosis of common problems, error code interpretation (if applicable), fault finding based on symptoms.
Assembly Disassembly:
Detailed, step-by-step instructions for component removal and reinstallation, with exploded diagrams.
Depth Level:
Comprehensive: Covers everything from basic routine maintenance to complex internal component rebuilds and advanced diagnostics.
User Level:
Suitable for professional technicians and experienced DIY mechanics with basic mechanical knowledge.
Diagrams Illustrations:
Includes exploded diagrams, charts, and photos to guide disassembly, reassembly, and identification of parts.
Engine Type:
Liquid-cooled, 4-stroke, SOHC, V-twin
Displacement:
695 cc (42.4 cu in)
Bore X Stroke:
72.0 mm x 85.0 mm
Compression Ratio:
9.3:1 (Typical, refer to manual for exact specification)
Horsepower Estimate:
Approx. 50-55 HP (at crankshaft, refer to manual for precise figure)
Torque Estimate:
Approx. 45-50 lb-ft (at crankshaft, refer to manual for precise figure)
Fuel Delivery:
Electronic Fuel Injection (EFI) with twin throttle bodies
Recommended Fuel:
Unleaded gasoline, 87 octane (minimum)
Oil Type:
API SG, SF or SH or higher, SAE 10W-40 recommended (refer to manual for specific Suzuki recommendations)
Oil Capacity:
Approx. 2.5 liters (2.6 US qt) with filter change (refer to manual for exact capacity)
Ignition Type:
Electronic ignition (CDI)
Cooling Method:
Liquid-cooled
Coolant Type:
Permanent type antifreeze coolant (ethylene glycol-based) with distilled water (50:50 mix)
Overall Length:
Approx. 81.7 inches (2075 mm)
Overall Width:
Approx. 47.0 inches (1195 mm)
Overall Height:
Approx. 47.4 inches (1205 mm)
Dry Weight:
Approx. 617 lbs (280 kg)
Curb Weight:
Refer to manual (typically includes all necessary fluids)
Towing Capacity:
Refer to manual (often limited on ATVs for safety)
Front Rack Capacity:
Refer to manual (e.g., 110 lbs / 50 kg)
Rear Rack Capacity:
Refer to manual (e.g., 220 lbs / 100 kg)
Front Tire Size:
AT25x8-12
Rear Tire Size:
AT25x10-12
Wheel Type:
Aluminum alloy
Atv Safety Standards:
Complies with ANSI/SVIA standards (refer to manual for specific certification)
Selectable 4Wd:
Yes, with differential lock for enhanced traction
Engine Braking:
Built into CVT for downhill control
Lighting:
Dual 30W headlights, 8W taillight/brake light
Hand Guards:
Standard on handlebars for protection
Parking Brake:
Yes, typically a caliper-based system on the rear axle.
Infotainment System:
N/A (Basic ATV with focus on function over entertainment features)
Driver Assistance Features:
Selectable 4WD, engine braking.
Connectivity Features:
N/A
Engine Management System:
Electronic Control Unit (ECU) managing EFI, ignition timing, and potentially idle speed control.
Engine Oil Change:
Every 600 miles (1000 km) or 6 months (refer to manual for specific interval)
Air Filter Cleaning:
Every 100 miles (160 km) or 1 month, or more frequently in dusty conditions
Spark Plug Replacement:
Every 1800 miles (3000 km) or 12 months (refer to manual)
Valve Clearance Check:
Every 1800 miles (3000 km) or 12 months (critical for performance)
Engine Oil Grade:
SAE 10W-40, API SG or higher
Coolant Type:
50/50 mixture of permanent type antifreeze and distilled water
Common Wear Items:
CV joint boots, brake pads, drive belts (CVT), suspension bushings due to off-road use.
Potential Electrical Issues:
Degradation of connectors, stator failure (though less common on this model than earlier ones).
Engine Performance Notes:
Importance of maintaining proper valve clearance and clean air filter for optimal V-twin performance.
