🏷️ Basic Information

Make:

Suzuki

Model:

SX4

Year:

2009

Generation:

First Generation (YA/YB Series, RC1/2)

Chassis Codes:

YA11S, YB11S (FWD), YA41S, YB41S (AWD)

Engine Codes:

M15A (1.5L), M16A (1.6L), J20A (2.0L)

👋 Introduction

Segment:

Subcompact/Compact Crossover SUV

Target Audience:

Budget-conscious buyers, first-time car owners, young families, individuals seeking a versatile and fuel-efficient vehicle.

Key Competitors:

Honda Fit, Toyota Yaris, Ford Fiesta, Chevrolet Aveo, Nissan Versa, Kia Rio, Hyundai Accent.

Distinguishing Features:

Available All-Wheel Drive (AWD) in its class, sporty styling, practical hatchback design, affordable pricing.

Convenience:

Instant online access, eliminates the need for bulky physical manuals, easily accessible on multiple devices.

Cost Savings:

Empowers DIY repairs and maintenance, significantly reducing dealership or independent mechanic labor costs.

Licensing Status:

Officially Licensed, derived from OE (Original Equipment) materials.

📋 Manual Details

Primary Coverage:

2009 Suzuki SX4 (All Trims, Engine Variants, and Drivetrain Options)

Secondary Coverage:

General Suzuki SX4 service and repair applicable to the first generation.

Estimated Pages:

Extensive, equivalent to a full factory service manual (precise page count not specified, but implied by 'comprehensive' and 'all service and repair information').

Type:

Official Service and Repair Manual Software

Language:

English

Format:

Online Software (Web-based access)

📖 Manual Coverage

Powertrain:

Engine Mechanical (1.5L M15A, 1.6L M16A, 2.0L J20A), Fuel System, Ignition System, Exhaust System, Engine Control System (ECU), Automatic Transmission (4-speed FWD/AWD), Manual Transmission (5-speed FWD/AWD), Drivetrain (Driveshafts, Differentials, AWD Coupling).

Chassis:

Suspension (Front MacPherson Strut, Rear Torsion Beam), Steering System (Power Steering - Hydraulic), Brakes (Front Ventilated Discs, Rear Solid Discs/Drums), Wheels and Tires, Body and Frame.

Electrical:

Electrical System Overview, Battery, Charging System (Alternator), Starting System, Ignition System, Lighting (Headlights, Taillights, Interior), Instrumentation, Power Windows, Power Locks, Wiper and Washer System, Horn, Audio System, HVAC Controls, SRS Airbag System, ABS/ESC Systems, Body Control Modules (BCM).

Comfort And Convenience:

Heating, Ventilation, and Air Conditioning (HVAC) System, Interior Trim, Seats, Power Accessories, Keyless Entry System.

Maintenance:

Oil and Filter Change, Air Filter Replacement, Spark Plug Replacement, Coolant Flush, Brake Fluid Flush, Transmission Fluid Change, Differential Fluid Change (AWD), Fuel Filter Replacement, Drive Belt Inspection and Replacement.

Repair:

Engine Rebuild (Minor/Major), Transmission Overhaul, Clutch Replacement, Brake Pad/Rotor Replacement, Suspension Component Replacement (Struts, Ball Joints, Bushings), Steering Rack Replacement, Wheel Bearing Replacement, Alternator Replacement, Starter Replacement, Radiator Replacement, HVAC Component Replacement, SRS System Diagnosis and Repair, ABS/ESC System Diagnosis and Repair.

Diagnostics:

Troubleshooting charts for common symptoms, Diagnostic Trouble Codes (DTCs) interpretation, Scan Tool Usage, Electrical Circuit Diagnosis, Fuel System Pressure Testing, Ignition System Testing.

Depth:

Comprehensive, covering basic maintenance to advanced repairs and diagnostics. Includes detailed specifications, wiring diagrams, component locations, removal and installation procedures, torque specifications, and troubleshooting guides.

📊 Manual Specifications

Access Method:

Web Browser Accessible Software

Printability:

Likely printable, allowing users to print specific sections or procedures.

Binding:

N/A (Software-based, not a physical book)

Paper Quality:

N/A (Digital format)

Searchability:

Searchable text for quick information retrieval.

Compatibility:

Compatible with PC, Laptop, Smartphone, Tablet via web browser.

Subscription Period:

1 Year (with discounts for renewal)

⚙️ Engine Specifications

Engine 1 Code:

M16A

Engine 1 Displacement:

1.6 Liters (1586 cc)

Engine 1 Configuration:

Inline 4-Cylinder

Engine 1 Valvetrain:

DOHC, 16 Valves, VVT (Variable Valve Timing)

Engine 1 Fuel Delivery:

Multi-point Fuel Injection (MPI)

Engine 1 Horsepower:

Approx. 120 HP @ 6000 RPM

Engine 1 Torque:

Approx. 112 lb-ft @ 4000 RPM

Engine 2 Code:

J20A

Engine 2 Displacement:

2.0 Liters (1995 cc)

Engine 2 Configuration:

Inline 4-Cylinder

Engine 2 Valvetrain:

DOHC, 16 Valves, VVT

Engine 2 Horsepower:

Approx. 143 HP @ 6000 RPM

Engine 2 Torque:

Approx. 137 lb-ft @ 4000 RPM

Fuel Type:

Unleaded Gasoline

🔧 Transmission

Transmission Type:

5-Speed Manual (FWD)

Transmission Type 1:

4-Speed Automatic (FWD)

Transmission Type AWD:

4-Speed Automatic (AWD)

AWD System:

Intelligent All-Wheel Drive (i-AWD) system with driver-selectable modes (2WD, 4WD Auto, 4WD Lock).

Manual Transmission Fluid:

API GL-4, SAE 75W-90 (Check manual for specific Suzuki part number).

Automatic Transmission Fluid:

Suzuki ATF 3317 or equivalent Dexron III/Mercon (Check manual for specific Suzuki part number).

📐 Dimensions

Length:

Approx. 162.0 inches (4115 mm)

Width:

Approx. 67.7 inches (1720 mm)

Height:

Approx. 61.4 inches (1560 mm) for FWD / 62.4 inches (1585 mm) for AWD

Wheelbase:

Approx. 98.4 inches (2500 mm)

Curb Weight:

Approx. 2600 - 2900 lbs (1180 - 1315 kg) depending on drivetrain and options.

Cargo Volume:

Approx. 17.0 cu ft (481 Liters) with rear seats up.

🛡️ Safety Features

NHTSA Front Impact Driver:

5 Stars

NHTSA Front Impact Passenger:

5 Stars

IIHS Front Offset Small Overlap:

Good

IIHS Side Impact:

Good

ABS:

Standard Anti-lock Braking System

Esc:

Available Electronic Stability Control (ESC) / Vehicle Stability Control System (VSCS)

Airbags:

Front Airbags, Side Airbags, Curtain Airbags (available on some trims).

Seatbelts:

Three-point front and rear seatbelts with pretensioners and load limiters.

💡 Technology Features

Audio System:

AM/FM/CD player with MP3 capability, auxiliary input jack. Higher trims may feature upgraded audio systems and satellite radio.

Traction Control:

Included with ESC on equipped models.

Cruise Control:

Available on higher trim levels.

Usb Port:

Rarely standard, but possible on upgraded audio systems.

Keyless Entry:

Available on higher trim levels.

🔧 Maintenance

Oil Change:

Every 5,000 - 7,500 miles (8,000 - 12,000 km) or 6-12 months, whichever comes first, depending on driving conditions.

Air Filter Replacement:

Every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on inspection.

Spark Plug Replacement:

Iridium spark plugs: Approx. 100,000 miles (160,000 km). Standard plugs: Approx. 30,000 miles (48,000 km).

Coolant Replacement:

Every 30,000 - 60,000 miles (48,000 - 96,000 km) or 2-4 years.

Brake Fluid Replacement:

Every 2-3 years or 30,000 miles (48,000 km).

Engine Oil Specification:

0W-20 or 5W-30 Synthetic (API SN or higher).

Engine Oil Capacity:

Approx. 4.0 - 4.5 Quarts (3.8 - 4.3 Liters) with filter, depending on engine.

Coolant Type:

Suzuki Super Long Life Coolant (or equivalent HOAT - Hybrid Organic Acid Technology)

Common Problems:

Occasional issues with catalytic converters, front sway bar links, and automatic transmission control modules. Some reports of premature clutch wear in manual transmissions under heavy use.

Electrical Quirks:

Infrequent electrical gremlins, sometimes related to door lock actuators or window regulators.

📚 Vehicle History

Manufacturer:

Suzuki Motor Corporation (Japan)

Introduction Year:

2006 (globally), 2007 (North America)

Generation 1 Years:

2006-2013

Design Philosophy:

A blend of hatchback practicality and crossover SUV styling, often marketed as a 'Sport Crossover'.

Manufacturing Locations:

Japan (Sagara Plant), Hungary (Magyar Suzuki), Egypt (Arab American Vehicles).

🏆 Awards & Recognition

Safety Awards:

Top safety pick awards from NHTSA and IIHS for the generation.
