🏷️ Basic Information

Make:

Toyota

Model:

Echo

Year:

2004

Chassis Code:

NCP10 / NCP12 (depending on market and body style)

👋 Introduction

Vehicle Segment:

Subcompact car

Target Audience:

Budget-conscious commuters, first-time car buyers, small families.

Key Competitors:

Honda Civic, Nissan Sentra, Ford Focus, Chevrolet Cavalier, Hyundai Accent.

Vehicle Selling Points:

Excellent fuel economy, Toyota reliability, practical interior for its size, affordable price point.

Advantage Over Print:

Instant access, searchable content, cost-effectiveness, portability across devices, always up-to-date.

Target User Benefit:

Empowers owners to perform maintenance and repairs, saving money and understanding their vehicle better.

📋 Manual Details

Manual Type:

Service and Repair Manual Software

Language:

English

Format:

PDF Download (online access)

Access Duration:

1 Year (with renewal options)

📖 Manual Coverage

Engine:

Detailed diagnostics, repair procedures, component specifications, timing belt replacement, cooling system, lubrication system, fuel system, emission control systems.

Drivetrain:

Manual and automatic transmission repair, clutch system, drive axles, differential, propeller shaft (if applicable).

Brakes:

Front and rear brake systems (disc/drum), ABS system diagnostics and repair, brake fluid specifications, bleeding procedures, parking brake.

Suspension Steering:

Front and rear suspension component replacement (struts, shocks, control arms, ball joints), steering rack and pinion, power steering system, wheel alignment specifications.

Electrical:

Complete wiring diagrams, fuse box locations, relay functions, charging system (alternator, battery), starting system, lighting system, instrument cluster, body control modules, power accessories.

HVAC:

Air conditioning system diagnosis, refrigerant recharge, heater core replacement, climate control unit repair, blower motor replacement.

Body Exterior:

Body panel replacement, door and trunk latches, glass replacement, trim removal and installation, bumper repair.

Body Interior:

Dashboard removal, seat removal, interior trim panel installation, airbag system precautions and removal.

Emission Controls:

EVAP system, EGR system, PCV system diagnostics and repair, catalytic converter information.

Exhaust System:

Muffler, catalytic converter, exhaust manifold removal and installation, gasket specifications.

Maintenance:

Oil and filter changes, coolant flushes, spark plug replacement, air filter replacement, tire rotation, brake pad replacement, belt replacement, fluid level checks.

Diagnostics:

Troubleshooting guides based on symptoms, DTC (Diagnostic Trouble Code) interpretation and resolution, component testing procedures.

Repair:

Step-by-step instructions for major component overhauls and replacements, including engine, transmission, suspension, and brake systems.

Wiring Diagrams:

Comprehensive, component-level wiring diagrams for all electrical systems.

Troubleshooting Codes:

Detailed listing of OBD-II diagnostic trouble codes (DTCs) with specific diagnostic steps and potential causes.

Depth:

Factory-level detail, suitable for both DIY enthusiasts and professional technicians. Covers basic maintenance to complex component overhauls and diagnostic procedures.

Torque Specifications:

Comprehensive torque specifications for all critical fasteners throughout the vehicle.

Diagnostic Tools:

Information on required special tools and diagnostic equipment for specific repairs.

📊 Manual Specifications

File Type:

PDF

Searchability:

Searchable text content for quick information retrieval.

Resolution:

High-resolution for clear diagrams and text.

Binding:

N/A (Digital Download)

Paper:

N/A (Digital Download)

Body Styles Covered:

Sedan (4-door), Hatchback (3-door/5-door depending on market).

⚙️ Engine Specifications

Engine Code:

1NZ-FE

Engine Type:

1.5L DOHC Inline 4-cylinder with VVT-i (Variable Valve Timing with intelligence)

Horsepower:

108 hp @ 6000 rpm

Torque:

105 lb-ft @ 4200 rpm

Fuel Delivery:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded gasoline

Recommended Octane:

87 Octane

Timing Belt Replacement Interval:

90,000 miles or 72 months (check manual for specific conditions)

Spark Plug Type:

Iridium Long Life (e.g., NGK IFR5T11 or equivalent)

🔧 Transmission

Transmission Type:

5-speed manual transmission

Transmission Type:

4-speed automatic transmission (Super ECT)

Automatic Transmission Fluid Type:

Toyota ATF WS (World Standard) or equivalent DEXRON III (verify specific fill)

📐 Dimensions

Length:

Approximately 161.0 - 164.4 inches (depending on body style)

Width:

Approximately 66.1 - 66.3 inches

Height:

Approximately 58.3 - 58.7 inches

Wheelbase:

Approximately 94.5 inches

Curb Weight:

Approximately 2,150 - 2,250 lbs (depending on transmission and trim)

🛡️ Safety Features

NHTSA Front Crash Test Rating:

4 Stars (Driver) / 4 Stars (Passenger)

IIHS Small Overlap Front Crash Test:

Not rated (vehicle predates widespread testing of this specific standard)

ABS:

Available Anti-lock Braking System (ABS) on some trims.

Traction Control:

Not commonly available.

Airbags:

Driver and front passenger airbags standard. Side airbags available on select models.

Seatbelts:

Three-point seatbelts with pretensioners for front occupants.

💡 Technology Features

Audio System:

Factory installed AM/FM stereo with CD player, 4 speakers. Optional cassette player.

Display:

Basic digital clock display, simple radio controls.

Cruise Control:

Available on some higher trim levels.

Keyless Entry:

Available on some trims.

Bluetooth:

Not available from factory.

Aux Input:

Not typically available from factory.

🔧 Maintenance

Oil Change Interval:

Every 5,000 miles or 6 months (whichever comes first), using synthetic oil recommended for longer intervals.

Engine Coolant Flush Interval:

Every 30,000 miles or 36 months.

Transmission Fluid Change Interval Auto:

Every 60,000 miles or 72 months (under normal driving conditions).

Engine Oil Type:

0W-20 or 5W-30 (verify owner's manual for seasonal recommendations)

Engine Oil Capacity:

3.7 US quarts (3.5 liters) with filter change

Coolant Type:

Toyota Super Long Life Coolant (Pink) or equivalent HOAT coolant

Coolant Capacity:

Approximately 4.6 US quarts (4.3 liters)

Common Problems:

Oil consumption on high-mileage engines, occasional transmission issues (sluggish shifts), A/C system refrigerant leaks, front suspension wear (bushings, tie rods), catalytic converter failure.

Recall Information:

Check for potential recalls related to airbags or other safety systems; specific recalls should be verified via VIN lookup on NHTSA or Toyota's official site.

📚 Vehicle History

Toyota Reputation:

Renowned for reliability, durability, and fuel efficiency.

Generation:

First Generation (XP10 platform)

Production Years:

1999-2006 (globally), 2003-2006 (North America)

Manufacturing Location:

Japan

🏆 Awards & Recognition

Consumer Reports Reliability:

Consistently rated as 'Above Average' or 'Excellent' for reliability by Consumer Reports during its production run.

Kbb Value:

Recognized for strong resale value due to Toyota's reputation.
