Segment:
Compact Hatchback / Wagon
Target Audience:
DIY enthusiasts, independent repair shops, Toyota owners seeking comprehensive repair information.
Competitors:
Honda Civic Hatchback, Ford Focus, Mazda3, Subaru Impreza.
Licensing:
Officially licensed, derived from OE (Original Equipment) materials.
Access Duration:
1-Year access with discounts for extensions.
Accessibility:
Accessible on PC, laptop, smartphone, tablet via web browser.
Engine Mechanical:
Complete engine disassembly, assembly, diagnostics, and repair for all variants.
Engine Management:
Fuel injection, ignition system, emissions control, sensors, actuators, diagnostic trouble codes (DTCs).
Transmission:
Manual and automatic transmission overhaul, repair, fluid specifications, and diagnostics.
Drivetrain:
Front-wheel drive (FWD) and all-wheel drive (AWD) systems, CV axles, differentials, propeller shaft (AWD).
Suspension:
Front and rear suspension components, springs, shock absorbers, control arms, alignment specifications.
Steering:
Power steering system, steering rack, tie rods, column, linkage, diagnosis.
Brakes:
Disc brake systems (front and rear), ABS, brake fluid specifications, bleeding procedures, caliper and rotor replacement.
Electrical System:
Battery, charging system, starter, lighting, power windows, mirrors, locks, wipers, horns.
HVAC:
Air conditioning system, heater core, blower motor, climate control, refrigerant specifications.
Body And Frame:
Body panel removal and installation, interior trim, exterior trim, glass replacement, structural repair information.
Diagnostics:
Comprehensive diagnostic procedures for all major systems, including troubleshooting flowcharts and symptom-based diagnosis.
Wiring Diagrams:
Detailed electrical wiring schematics for all vehicle systems.
Maintenance:
Scheduled maintenance tasks, fluid changes, filter replacements, spark plug replacement, belt inspection/replacement.
Repair:
Step-by-step repair instructions for a vast array of components and systems.
Troubleshooting:
Identification and resolution of common and uncommon vehicle issues.
Disassembly Assembly:
Detailed instructions for removing and reinstalling virtually every component.
Specifications:
Torque specifications, clearances, fluid capacities, pressures, electrical values.
Depth:
Comprehensive (from basic maintenance to complete engine and transmission rebuilds, advanced diagnostics).
Engine Type 1:
1.8L DOHC 16-valve inline-4 VVT-i (Variable Valve Timing with intelligence)
Bore X Stroke 1:
79.0 mm x 91.5 mm
Compression Ratio 1:
10.0:1
Horsepower 1:
130 hp @ 6000 rpm
Torque 1:
125 lb-ft @ 4200 rpm
Fuel System 1:
Electronic Fuel Injection (EFI)
Fuel Type 1:
Unleaded Gasoline (87 octane recommended)
Engine Type 2:
1.8L DOHC 16-valve inline-4 VVTL-i (Variable Valve Timing and Lift intelligent)
Compression Ratio 2:
11.5:1
Horsepower 2:
180 hp @ 7800 rpm
Torque 2:
135 lb-ft @ 6800 rpm
Fuel System 2:
Electronic Fuel Injection (EFI)
Fuel Type 2:
Unleaded Gasoline (91 octane recommended for optimal performance)
Length:
Approx. 168.1 inches (4270 mm)
Width:
Approx. 66.7 inches (1695 mm)
Height:
Approx. 59.3 inches (1505 mm)
Wheelbase:
Approx. 102.4 inches (2600 mm)
Curb Weight Min:
Approx. 2730 lbs (1238 kg)
Curb Weight Max:
Approx. 2930 lbs (1330 kg)
NHTSA Front Impact Driver:
Good
NHTSA Front Impact Passenger:
Good
NHTSA Side Impact Front Seat:
Good
NHTSA Side Impact Rear Seat:
Good
IIHS Front Offset Crash:
Good
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Available Traction Control System (TRAC) on some models.
Airbags Front:
Dual front SRS (Supplemental Restraint System) airbags.
Airbags Side:
Optional front side-impact airbags and side curtain airbags on some trims.
Seatbelts:
3-point seatbelts with pretensioners and force limiters in all seating positions.
Oil Change:
Every 5,000 miles or 6 months, whichever comes first (or 10,000 miles / 12 months with synthetic oil, consult manual for details).
Air Filter Replacement:
Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles if driving in dusty conditions.
Cabin Air Filter Replacement:
Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles or annually.
Spark Plug Replacement 1Zz:
Replace every 100,000 miles with Iridium-tipped spark plugs (e.g., Denso PK20TT or NGK Iridium).
Spark Plug Replacement 2Zz:
Replace every 60,000 miles with Iridium-tipped spark plugs (e.g., Denso PK20PR11 or NGK Iridium).
Engine Oil:
SAE 5W-30, API Certified (ILSAC GF-4 or API SM recommended).
Engine Oil Capacity:
4.4 US quarts (4.2 liters) with filter for 1ZZ-FE; 4.5 US quarts (4.3 liters) with filter for 2ZZ-GE.
Coolant:
Toyota Super Long Life Coolant (SLLC) - Pink, or equivalent pre-mixed 50/50 ethylene glycol coolant.
Coolant Capacity:
Approx. 6.0 US quarts (5.7 liters) for 1ZZ-FE; Approx. 7.0 US quarts (6.6 liters) for 2ZZ-GE (including reservoir).
Transmission Fluid Manual:
API GL-4, SAE 75W-90 Gear Oil (Toyota Genuine Gear Oil or equivalent).
Transmission Fluid Automatic:
Toyota Genuine ATF WS (World Standard) or equivalent Dexron III/VI compatible fluid.
Brake Fluid:
DOT 3 or DOT 4.
Power Steering Fluid:
Toyota Genuine Power Steering Fluid or equivalent Dexron II/III ATF.
Oil Consumption 1Zz:
Some 1ZZ-FE engines are known for oil consumption due to piston ring issues. Regular oil level checks are crucial.
Clutch Wear:
Clutch wear can be accelerated by aggressive driving or frequent stop-and-go traffic.
Evaporative Emission Control System:
Faulty EVAP canister purge valve or vent solenoid can trigger check engine lights.
Rear Wheel Bearings:
Rear wheel bearings can develop noise and require replacement over time, particularly on AWD models.
Manufacturer:
Toyota Motor Corporation
Reputation:
Renowned for reliability, quality, and value.
Introduction Year:
2000 (globally), 2003 (North America)
Platform Sharing:
Shared platform with the Toyota Corolla (E130).
Design Philosophy:
Compact, versatile hatchback/wagon aimed at younger buyers and those seeking utility.
Manufacturing Location:
Canada (Toyota Motor Manufacturing Canada Inc. - TMMC)
