🏷️ Basic Information

Make:

Toyota

Model:

Prius

Model Year:

2010

Chassis Code:

XW30

👋 Introduction

Target Audience:

Do-it-yourselfers and experienced mechanics seeking a comprehensive resource for repair and maintenance.

Vehicle Segment:

Compact Hybrid Car

Value Proposition:

Inexpensive way to keep the vehicle working properly, empowering users to perform their own repairs and save money.

Content Style:

Detailed illustrations, diagrams, wiring schematics, step-by-step instructions, hundreds of photos.

📋 Manual Details

Covered Models:

All 2010 Toyota Prius models and engines

Total Pages:

3000+

Type:

Service and Repair Manual

Language:

English

File Format:

PDF

📖 Manual Coverage

Powertrain:

Engine Overhaul and Rebuilding, Timing Belt Replacement, Engine Performance, Transmission Removal and Installation, Transmission In-Car Servicing, Firing Orders, Serpentine Belt Routings with Diagrams, Timing Belt Service Procedures, U-Joint and CV-Joint Service Procedures

Braking System:

Brakes, Brake Servicing Procedures

Chassis And Suspension:

Sunroof, Front End and Alignment Procedures and Specifications, Suspension

Electrical And Diagnostics:

Trouble Codes, Wiring Diagrams, Troubleshooting and Diagnostics, Computer Diagnostic Trouble Tree Charts, Computer Diagnostic Codes, Vacuum Diagrams, Complete Wiring Diagrams

HVAC:

Air Conditioning Service and Capacities

Body And Interior:

Covers sunroof, doors, windows, seats, dashboard, interior trim, and related components.

Repair Procedures:

All diagnostic and repair procedures, step-by-step instructions based on complete disassembly

Maintenance Procedures:

Factory Maintenance Schedules and Charts

Diagnostic Procedures:

Trouble codes, troubleshooting charts, diagnostic trouble trees, computer diagnostics.

Depth:

Comprehensive, suitable for DIY enthusiasts and experienced mechanics, covering detailed illustrations, diagrams, wiring schematics, and specifications.

Specifications:

Includes detailed specifications on every model covered, complete torque specifications.

📊 Manual Specifications

Requirements:

Adobe PDF Reader & WinZip

File Size Consideration:

Large file size due to extensive detail and graphics (over 3000 pages).

Digital Delivery:

Instant download upon completion of payment.

Os Compatibility:

All Versions of Windows & Mac, Linux OS, iPhone, iPad, Android etc.

Printability:

Printable

Search Features:

Bookmarked and Searchable

Integrity:

100% Complete and Intact, no missing/corrupt pages/sections

⚙️ Engine Specifications

Engine Type:

Hybrid Synergy Drive (HSD) - 1.8L 4-cylinder DOHC 16-valve VVT-i Atkinson cycle engine coupled with electric motor

Engine Code:

1ZR-FXE (Internal designation for the hybrid system's gasoline engine)

Combined Horsepower:

134 hp (net)

Engine Horsepower:

98 hp @ 5200 rpm

Electric Motor Horsepower:

80 hp

Torque Engine:

101 lb-ft (137 Nm) @ 4,000 rpm

Fuel Type:

Unleaded Gasoline

Fuel Delivery:

Electronic Fuel Injection (EFI)

🔧 Transmission

Transmission Type:

Electronically Controlled Continuously Variable Transmission (ECVT)

Optional Transmissions:

N/A (ECVT is standard)

Transmission Features:

Power split device, regenerative braking, electric-only drive mode, EV mode

📐 Dimensions

Length:

174.4 inches (4428 mm)

Width:

68.7 inches (1745 mm)

Height:

57.9 inches (1470 mm)

Curb Weight:

Approx. 3,042 - 3,130 lbs (1379 - 1420 kg)

Gross Weight Rating:

Approx. 4,120 lbs (1869 kg)

🛡️ Safety Features

NHTSA Overall Safety Rating:

5-Star (for 2010 model year)

Active Safety Features:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Vehicle Stability Control (VSC), Traction Control (TRAC), Electronic Power Steering (EPS)

Passive Safety Features:

Advanced front airbags, front-seat mounted side airbags, front and rear side curtain airbags, driver knee airbag

💡 Technology Features

Infotainment System:

Touchscreen display with navigation (optional), AM/FM/CD/MP3 player, auxiliary audio input, Bluetooth connectivity (optional).

Driver Assistance Features:

Smart Key System with Push Button Start, Cruise Control, Backup Camera (standard on some trims).

Connectivity Options:

Bluetooth hands-free calling and audio streaming, USB input (optional).

🔧 Maintenance

Oil Change Interval:

Typically every 5,000-10,000 miles or 6-12 months, depending on driving conditions and oil type used (refer to manual for exact specifications).

Engine Air Filter:

Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles under normal driving conditions.

Cabin Air Filter:

Replace every 15,000-30,000 miles depending on environment.

Spark Plug Replacement:

Inspect at 60,000 miles, replace at 100,000 miles (using Iridium-tipped spark plugs).

Engine Oil Type:

SAE 0W-20 Synthetic (API SN, SN PLUS, SP certified)

Engine Oil Capacity:

4.4 US qt (4.2 L) with filter change

Coolant Type:

Toyota Super Long Life Coolant (SLLC) - Pink

Transmission Fluid Type:

Toyota Genuine ATF WS (World Standard)

Brake Fluid Type:

SAE J1703 or FMVSS No. 116 DOT 3

Common Problems:

Water pump leaks (specifically the hybrid system water pump), exhaust manifold cracks, brake actuator failure, potential for oil consumption in some cases, dashboard screen issues.

📚 Vehicle History

Manufacturer Origin:

Japan

Generation:

Third Generation (XW30, 2009-2015)

Production Years:

2009-2015

Manufacturing Location:

Toyota City, Aichi Prefecture, Japan; Takaoka Plant, Toyota City, Aichi Prefecture, Japan; Georgetown, Kentucky, USA (for North American market)

🏆 Awards & Recognition

Green Car Awards:

Consistently ranked highly for fuel efficiency and environmental impact, often recognized by organizations like the EPA and Kelley Blue Book.

Safety Awards:

Earned top safety ratings from IIHS and NHTSA for its generation.
