2008 Toyota RAV4 Service & Repair Manual Software

常规价格
$17.99
促销价
$17.99
常规价格
🏷️ Basic Information Identification Make: Toyota Model: RAV4 Year: 2008 Codes Chassis Code: XG30 Engine Codes: 2AZ-FE (2.4L), 3MZ-FE (3.5L V6) 👋 Introduction Market Position Market Position: Compact crossover SUV,...
28 people are viewing this right now
类型: Car
厂商:
斯库: 47386
2008 Toyota RAV4 Service & Repair Manual Software2008 Toyota RAV4 Service & Repair Manual Software2008 Toyota RAV4 Service & Repair Manual Software2008 Toyota RAV4 Service & Repair Manual Software
🏷️ Basic Information
Identification
Make:
Toyota
Model:
RAV4
Year:
2008
Codes
Chassis Code:
XG30
Engine Codes:
2AZ-FE (2.4L), 3MZ-FE (3.5L V6)
👋 Introduction
Market Position
Market Position:
Compact crossover SUV, popular for its practicality, reliability, and versatility
Competitive Analysis
Competitive Analysis:
Competed against vehicles like the Honda CR-V, Nissan Rogue, Ford Escape, and Subaru Forester
Key Features
Key Features:
Available in front-wheel drive (FWD) and all-wheel drive (AWD), comfortable ride, spacious interior for its class, good fuel economy
Manual Value
Manual Value:
Provides factory-level diagnostic and repair procedures, empowering DIY mechanics and saving on labor costs
Software Benefit
Software Benefit:
Instant access, searchable content, cross-device compatibility, licensed OE material ensures accuracy
📋 Manual Details
Coverage Areas
Coverage Areas:
All mechanical, electrical, body, and maintenance aspects
Page Count
Page Count:
Estimated 3000+ pages (typical for OE service manuals)
Manual Type
Manual Type:
Factory Service Manual / Repair Manual
Language
Language:
English
Format
Format:
PDF Download (Software Interface)
📖 Manual Coverage
Systems Covered
Engine Systems:
Engine mechanical, lubrication, cooling, fuel delivery, ignition, emissions control, starting and charging
Drivetrain Systems:
Manual transmission, automatic transmission, clutch, transfer case, drive shafts, differentials, axles
Chassis Systems:
Suspension (front and rear), steering, brakes (hydraulic, ABS, EBD, VSC), wheels and tires
Electrical Systems:
Body electrical systems, multiplex communication systems, instrument cluster, lighting, power accessories, audio, navigation, security
HVAC Systems:
Heating, Ventilation, and Air Conditioning (HVAC) system operation and diagnosis
Body And Trim:
Exterior body panels, interior trim, doors, windows, seats, body sealing
Procedures Included
Maintenance Procedures:
Scheduled maintenance, oil changes, fluid checks and replacements, filter replacements, tune-ups, inspections
Repair Procedures:
Component removal, installation, overhaul, adjustment, diagnostic troubleshooting steps
Diagnostic Procedures:
Troubleshooting flowcharts, symptom-based diagnosis, diagnostic trouble code (DTC) explanations and resolution
Wiring Diagrams:
Comprehensive electrical wiring diagrams for all systems
Special Tools:
Identification and usage of specialized tools required for specific repair procedures
Technical Depth
Technical Depth:
Comprehensive: from basic maintenance to complete engine rebuilds and complex electronic diagnostics
📊 Manual Specifications
File Format
File Format:
PDF with searchable text and interactive elements
Print Quality
Print Quality:
High-resolution images, diagrams, and text suitable for printing
Binding Type
Binding Type:
N/A (Digital Download)
Paper Type
Paper Type:
N/A (Digital Download)
⚙️ Engine Specifications
Primary Engine
Primary Engine 2Az Fe:
2.4L DOHC 16-Valve Inline-4
2Az Fe Horsepower:
166 hp @ 6000 rpm
2Az Fe Torque:
163 lb-ft @ 4000 rpm
Optional Engine
Optional Engine 3Mz Fe:
3.5L DOHC 24-Valve V6
3Mz Fe Horsepower:
269 hp @ 6200 rpm
3Mz Fe Torque:
246 lb-ft @ 4700 rpm
Fuel System
Fuel System:
Electronic Fuel Injection (EFI) with Electronic Throttle Control System (ETCS-i)
Fuel Type
Fuel Type:
Unleaded gasoline
🔧 Transmission
Standard
Standard Transmission:
4-speed automatic transmission (for 2.4L engine)
Optional
Optional Transmission:
6-speed manual transmission (available on some 2.4L models)
V6 Transmission:
5-speed automatic transmission (for 3.5L V6 engine)
Features
AWD System:
Electronically controlled Active Torque Split All-Wheel Drive (AWD)
📐 Dimensions
Exterior
Length:
173.8 inches (4415 mm)
Width:
71.5 inches (1815 mm)
Height:
65.2 inches (1655 mm)
Wheelbase:
103.1 inches (2615 mm)
Weights
Curb Weight 2 4L FWD:
Approximately 3460 lbs (1569 kg)
Curb Weight 2 4L AWD:
Approximately 3595 lbs (1630 kg)
Curb Weight 3 5L AWD:
Approximately 3890 lbs (1765 kg)
🛡️ Safety Features
Ratings
NHTSA Front Driver:
5 Stars
NHTSA Front Passenger:
5 Stars
NHTSA Side Driver:
5 Stars
NHTSA Side Passenger:
5 Stars
NHTSA Rollover:
4 Stars
Active Features
Active Features:
Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Vehicle Stability Control (VSC), Traction Control (TRAC)
Passive Features
Passive Features:
Dual front airbags, front side-impact airbags, side curtain airbags, active front headrests
💡 Technology Features
Infotainment
Infotainment Options:
Optional touch-screen DVD navigation system, JBL premium audio system
Driver Assistance
Driver Assistance:
Vehicle Stability Control (VSC), Traction Control (TRAC), ABS with EBD and Brake Assist
Connectivity
Connectivity:
Auxiliary audio input jack
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months, or 10,000 miles (16,000 km) / 12 months with synthetic oil (refer to manual for specific conditions)
Engine Air Filter:
Inspect every 15,000 miles (24,000 km), replace as needed
Cabin Air Filter:
Replace every 15,000 miles (24,000 km) or 12 months
Spark Plugs:
Iridium-tipped: 120,000 miles (192,000 km)
Fluid Specifications
Engine Oil:
SAE 5W-30 (API Certified SN, SN Plus, or SP); use synthetic for extended intervals
Engine Oil Capacity:
Approx. 4.5 US quarts (4.3 L) with filter for 2.4L; 6.4 US quarts (6.1 L) for 3.5L V6
Transmission Fluid Auto:
Toyota Genuine ATF WS (World Standard)
Transmission Fluid Manual:
GL-4 75W-90 gear oil
Coolant:
Toyota Super Long Life Coolant (Pink)
Brake Fluid:
DOT 3
Known Issues
Known Issues:
Potential for oil consumption in higher mileage 2.4L engines, potential catalytic converter issues, occasional electronic component failures (e.g., window regulators, power locks), rear differential whine on AWD models.
📚 Vehicle History
Brand Heritage
Brand Heritage:
Toyota is renowned for its engineering, reliability, and quality. The RAV4, launched in 1994, pioneered the compact SUV segment.
Model Evolution
Model Evolution:
The 2008 model represents the second generation (XG30) of the RAV4, significantly redesigned with a longer wheelbase and available V6 engine.
Production
Production Plant:
Tahara Plant, Aichi, Japan; Toyota Motor Manufacturing Canada (TMMC), Woodstock, Ontario, Canada
🏆 Awards & Recognition
Recognitions
Recognitions:
Often cited for reliability by J.D. Power and Associates, Consumer Reports.
