Segment:
Subcompact car, known for fuel efficiency, affordability, and reliability.
Key Competitors:
Honda Fit, Nissan Versa, Ford Fiesta, Chevrolet Aveo, Mazda2.
Selling Points:
Compact exterior dimensions, spacious interior for its class, good fuel economy, Toyota's reputation for reliability and build quality.
Benefit To Owner:
Empowers DIY enthusiasts and cost-conscious owners with factory-level repair and maintenance information, saving significant money on dealership or independent shop labor costs. Provides confidence in performing tasks correctly.
Primary Coverage:
North American Market (2009 Model Year)
Secondary Coverage:
Global specifications generally aligned with North American models
Estimated Pages:
Varies based on software version; typically equivalent to 1000+ printed pages of technical data.
Type:
Official Licensed Service and Repair Manual Software
Format:
Digital Download (PDF within web-based access)
Powertrain:
Engine mechanical, fuel system, lubrication, cooling, ignition, exhaust, emissions control, engine management, automatic transmission, manual transmission, driveline (front-wheel drive).
Chassis:
Suspension (front and rear), steering system, brake system (hydraulic, parking brake), wheels, tires.
Body And Electrical:
Body structure, exterior components, interior trim, HVAC system (heating, ventilation, air conditioning), electrical system (wiring diagrams, fuses, relays, power distribution), lighting, instruments and controls, audio system, security system, airbags.
Maintenance:
Scheduled maintenance (oil changes, filter replacements, fluid checks/changes), inspections, lubrication points.
Diagnostics:
Troubleshooting guides based on symptoms, diagnostic trouble codes (DTCs) interpretation and clearing, component testing procedures.
Repair And Overhaul:
Detailed step-by-step repair procedures for all major systems, including engine disassembly/reassembly, transmission overhaul, brake caliper replacement, suspension component replacement, body panel repair, electrical component diagnosis and replacement.
Component Replacement:
Procedures for replacing common wear items and major components such as spark plugs, belts, hoses, water pump, alternator, starter, clutch, brake pads/rotors, shocks/struts, AC compressor.
Depth:
Comprehensive, factory-level detail suitable for DIY mechanics and professional technicians. Includes detailed specifications, torque values, diagnostic strategies, and special tool recommendations.
Engine Type:
Inline 4-cylinder, DOHC, 16-valve, VVT-i (Variable Valve Timing with intelligence)
Displacement:
1.5 Liters (1497 cc)
Horsepower:
Approx. 106 hp @ 6000 RPM
Torque:
Approx. 103 lb-ft @ 4400 RPM
Injection Type:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline (87 octane recommended)
Coolant Type:
Toyota Super Long Life Coolant (Pink) or equivalent, 50/50 mixture with distilled water.
Oil Type:
SAE 0W-20 (Recommended by Toyota for fuel efficiency and cold start performance)
Oil Capacity:
Approx. 3.5 US quarts (3.3 Liters) with filter change.
Type:
5-speed Manual Transmission
Type:
4-speed Electronically Controlled Automatic Transmission (ECT)
Automatic Features:
Lock-up torque converter for improved highway fuel economy, AI-Shift control.
Manual Transmission Fluid:
API GL-4, SAE 75W-90 (or as specified in owner's manual, consult manual for exact specification)
Automatic Transmission Fluid:
Toyota Genuine ATF WS (World Standard)
Automatic Transmission Capacity:
Approx. 6.0 US quarts (5.7 Liters) for total refill.
Overall Length:
Approx. 150.6 inches (3825 mm)
Overall Width:
Approx. 66.1 inches (1680 mm)
Overall Height:
Approx. 59.5 inches (1510 mm)
Wheelbase:
Approx. 94.5 inches (2400 mm)
Curb Weight:
Approx. 2315 lbs (1050 kg) for manual transmission models.
Gross Vehicle Weight Rating:
Typically around 3350 lbs (1520 kg).
NHTSA Front Impact:
5-Star Rating (Driver and Passenger) for 2009 models.
IIHS Side Impact:
Good Rating for 2009 models.
IIHS Roof Strength:
Good Rating for 2009 models.
ABS:
Standard Anti-lock Braking System (ABS) with Electronic Brake-force Distribution (EBD).
Traction Control:
Optional Traction Control System (TRAC) and Vehicle Stability Control (VSC) on some trims/options.
Airbags:
Driver and front passenger airbags. Optional front side-impact airbags and front and rear side curtain airbags available on certain trims.
Seatbelts:
Three-point seatbelts for all occupants, pretensioners and force limiters for front seats.
Child Seats:
LATCH (Lower Anchors and Tethers for CHildren) system for rear seats.
Audio System:
Standard AM/FM/CD player with auxiliary audio input. Higher trims may offer satellite radio capability and enhanced speaker systems.
Display:
Digital clock display. Higher trims may offer basic LCD information screens.
Cruise Control:
Optional on some trims.
Keyless Entry:
Available on higher trims, often with remote keyless entry.
Bluetooth:
Not standard on most 2009 Yaris models. May be an dealer-installed option or found on later/higher trims.
Oil And Filter Change:
Every 5,000 miles (8,000 km) or 6 months, whichever comes first, under normal driving conditions. Severe driving conditions may require more frequent changes.
Engine Air Filter:
Inspect every 15,000 miles (24,000 km), replace as needed or every 30,000 miles (48,000 km).
Cabin Air Filter:
Inspect every 15,000 miles (24,000 km), replace as needed or every 15,000-30,000 miles (24,000-48,000 km) depending on environment.
Spark Plugs:
Iridium-tipped spark plugs typically have a long service life, often recommended for replacement around 100,000-120,000 miles (160,000-190,000 km).
Coolant Replacement:
Toyota Super Long Life Coolant: Initial replacement at 100,000 miles (160,000 km) or 10 years, then every 50,000 miles (80,000 km) or 5 years thereafter.
Brake Fluid:
DOT 3 (or as specified on brake fluid reservoir cap). Flush and replace every 30,000 miles (48,000 km) or 2 years.
Power Steering Fluid:
Not applicable for models with Electric Power Steering (EPS), which is common for this generation.
Common Wear Items:
Brake pads and rotors, front sway bar links, struts/shocks, clutch assembly (manual transmission), O2 sensors, catalytic converter (less common but possible).
Engine Specific:
Occasional oil consumption due to piston ring wear in higher mileage engines, potential for EVAP system leaks (causing check engine light).
Electrical Common:
Headlight bulbs, interior light bulbs, occasional issues with power window regulators.
Toyota Reputation:
Toyota is globally recognized for its commitment to quality, durability, and reliability (QDR).
Yaris Lineage:
The Yaris is the successor to the Toyota Echo and is part of Toyota's global small car strategy, evolving from the Vitz platform.
Manufacturing Locations:
Primarily manufactured in Japan, with some assembly potentially occurring in other global locations depending on the market.
