🏷️ Basic Information

Make:

Triumph

Model:

America

Year:

2006

Model Code:

LT01

👋 Introduction

Target Audience:

Professional motorcycle technicians and experienced DIY enthusiasts.

Value Proposition:

Provides comprehensive, dealership-level repair and maintenance information, saving costs compared to professional servicing.

Manual Type Comparison:

Distinguished from owner's manuals by its in-depth technical procedures and diagnostic data.

Instructional Style:

Numbered steps, critical notes, cautions, and warnings for clarity and safety.

Visual Aids:

Detailed illustrations, drawings, and photos with enlarged insets for precise part identification.

Organization:

Numbered table of contents for quick access to specific information.

Diagnostics Integration:

Troubleshooting and electrical service procedures are integrated with wiring diagrams.

📋 Manual Details

Primary Coverage:

Full Service Repair and Maintenance

Diagnostic Coverage:

Comprehensive Diagnostics and Troubleshooting

Electrical Coverage:

Detailed Wiring Diagrams and Electrical Service Procedures

Estimated Page Count:

Varies based on specific edition, typically 300-600 pages for comprehensive manuals.

Manual Type:

Full Service Repair Manual

Language:

English

File Format:

PDF

Delivery Method:

Instant Download

📖 Manual Coverage

Engine:

Engine disassembly, assembly, inspection, maintenance, and repair for the Triumph America 2006.

Fuel System:

Fuel injection system, fuel pump, fuel filter, and fuel lines maintenance and troubleshooting.

Ignition System:

Spark plugs, coils, ECU, and ignition timing diagnostics and repair.

Transmission:

Gearbox, clutch, and drive chain maintenance, adjustment, and repair.

Suspension:

Front fork, rear shock absorbers, and related components inspection, service, and replacement.

Brakes:

Front and rear brake systems, including hydraulic lines, calipers, master cylinders, and pads.

Electrical System:

Battery, charging system, lighting, starter motor, and all electrical components including detailed wiring diagrams.

Cooling System:

Radiator, coolant, and related components inspection and maintenance (if applicable).

Chassis And Frame:

Frame inspection, steering head bearings, and wheel bearings service.

Bodywork And Fittings:

Body panels, seat, fuel tank, and trim component removal, installation, and repair.

Routine Maintenance:

Oil changes, filter replacements, chain adjustments, brake pad inspections, and general lubrication.

Troubleshooting:

Step-by-step diagnostic procedures for common and complex issues.

Rebuilding:

Complete engine, gearbox, and component rebuilding procedures.

Adjustments:

Carburetor (if applicable for earlier models but the 2006 America typically uses EFI), clutch, throttle, and brake lever adjustments.

Calibration:

ECU calibration and sensor checks.

Depth Level:

Comprehensive, covering everything from basic maintenance to complete overhauls, suitable for professional technicians and advanced DIY mechanics.

📊 Manual Specifications

File Type:

PDF

Searchability:

Likely text-searchable PDF for efficient information retrieval.

Printable:

Full Printable

Print Recommendation:

Printable to hard copy for workshop use.

Binding Type:

Digital (PDF) - no physical binding.

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Type:

Parallel-twin, four-stroke

Engine Displacement:

800 cc (790 cc actual)

Bore X Stroke:

88 mm x 65.7 mm

Valve Train:

DOHC, 4 valves per cylinder

Fuel System:

Electronic Fuel Injection (EFI)

Cooling System:

Liquid-cooled

Compression Ratio:

9.9:1

Horsepower:

Approx. 60 PS (59 bhp; 44 kW) at 7,400 rpm (varies by market tuning)

Torque:

Approx. 68 Nm (50 lb-ft) at 5,500 rpm (varies by market tuning)

🔧 Transmission

Transmission Type:

5-speed constant mesh

Clutch Type:

Wet, multi-plate

Final Drive:

O-ring chain

📐 Dimensions

Length:

Approx. 2350 mm (92.5 in)

Width:

Approx. 800 mm (31.5 in)

Height:

Approx. 1160 mm (45.7 in)

Dry Weight:

Approx. 215 kg (474 lbs)

Wet Weight:

Approx. 230 kg (507 lbs)

Max Load:

Approx. 200 kg (441 lbs)

Front Tire Size:

100/90-18

Rear Tire Size:

170/80-15

Front Wheel:

3.50 x 18

Rear Wheel:

5.00 x 15

🛡️ Safety Features

Safety Features:

Standard braking system; ABS was optional on some markets/versions but not standard on all 2006 models.

Lighting:

Halogen headlight, LED taillight, incandescent turn signals.

💡 Technology Features

Infotainment System:

Basic, analogue instrumentation. No advanced infotainment systems.

Driver Assistance Features:

None (focus is on mechanical operation and rider experience).

Connectivity Features:

None.

🔧 Maintenance

Oil Change Interval:

Typically every 6,000 miles (10,000 km) or annually.

Valve Check Interval:

Typically every 12,000 miles (20,000 km).

Chain Lubrication Inspection:

Every 500 miles (800 km) or after riding in wet conditions.

Engine Oil Type:

JASO MA, API SG (or higher) synthetic or semi-synthetic 10W-40 or 10W-50 (refer to specific manual for exact viscosity).

Engine Oil Capacity:

Approx. 4.0 liters (4.2 US qt) with filter change.

Brake Fluid Type:

DOT 4

Coolant Type:

Ethylene glycol-based antifreeze coolant (refer to specific manual for concentration and type).

Common Wear Items:

Clutch plates, brake pads, drive chain and sprockets, wheel bearings.

Potential Electrical:

Wiring harness connections, regulator/rectifier issues on some older models (though less common on EFI models).

Fuel System:

Potential for fuel injector clogging if poor quality fuel is used or bike sits for extended periods without stabilizer.

📚 Vehicle History

Brand Origin:

United Kingdom, established in 1902.

America Introduction:

Introduced in 2002 as Triumph's interpretation of the classic American cruiser style, powered by the Hinckley twins.

2006 Updates:

The 2006 model typically featured the 800cc engine (introduced in earlier models) with EFI, refined styling, and chassis updates.

Manufacturing Location:

Hinckley, Leicestershire, England

🏆 Awards & Recognition

Awards Achieved:

Triumph motorcycles generally receive consistent praise for their engineering, build quality, and distinctive styling, though specific awards for the 2006 America model are not prominently documented as industry-shattering accolades.
