🏷️ Basic Information

Make:

Volkswagen

Model:

Jetta

Year:

2011

Model Code:

A5 (Mk6)

👋 Introduction

Target Audience:

Automotive technicians, DIY enthusiasts, electrical diagnosticians, repair shops specializing in Volkswagen vehicles.

Differentiation:

This manual is highly specialized, focusing on the often-complex electrical system wiring. It provides a level of granular detail on wire colors and their specific functions that is critical for accurate diagnosis and repair, differentiating it from general service manuals.

Core Functionality:

Provides an organized and authoritative reference for all vehicle wiring, enabling efficient troubleshooting of electrical faults without needing to decipher complex schematic diagrams for basic wire identification.

📋 Manual Details

Primary Coverage:

Electrical System Wiring Information

Secondary Coverage:

Wire colors, wire functions, connector pin assignments

Estimated Pages:

Varies based on specific wiring guide, typically 150-300 pages for this type of specialized manual

Type:

Wiring Information Guide / Electrical Troubleshooting Manual Supplement

Language:

English

Format:

Digital (PDF)

📖 Manual Coverage

Electrical Systems:

Engine Control Module (ECM), Transmission Control Module (TCM), Anti-lock Braking System (ABS), Electronic Stability Control (ESC), Body Control Module (BCM), Instrument Cluster, Lighting (headlights, taillights, interior), Audio System, Power Windows, Power Locks, Climate Control, Airbag System, Infotainment System

Diagnostic Assistance:

Pinpointing electrical faults through wire identification, understanding circuit functions, guiding component testing

Level:

Detailed; focuses on specific wire identification and function, crucial for advanced diagnostics and repair, complements full service manuals.

📊 Manual Specifications

Digital Format:

Searchable PDF with high-resolution text and graphics

Printability:

High; designed for clear printing of wire colors and connector diagrams

Binding:

N/A (Digital Format)

Paper Quality:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Options 2011 Jetta:

2.0L TSI (Turbocharged Direct Injection) Inline-4, 2.5L (150 CID) Inline-5, 1.9L TDI (Turbocharged Direct Injection) Diesel Inline-4 (market dependent)

Tsi Power:

170 hp @ 5200-6200 rpm; 200 lb-ft @ 1700-5000 rpm

2.5L Power:

170 hp @ 5700 rpm; 177 lb-ft @ 4250 rpm

Tsi Fuel Delivery:

Direct Fuel Injection (DFI)

2.5L Fuel Delivery:

Multi-Point Fuel Injection (MPFI)

🔧 Transmission

Standard Transmission Tsi:

6-speed Manual

Standard Transmission 2.5L:

5-speed Manual

Optional Transmission Tsi:

6-speed DSG (Direct-Shift Gearbox) Automatic

Optional Transmission 2.5L:

6-speed Automatic (Tiptronic)

Dsg Features:

Dual-clutch technology for rapid gear changes, available paddle shifters

📐 Dimensions

Wheelbase:

101.5 inches (2578 mm)

Length:

179.7 inches (4565 mm)

Width:

70.1 inches (1780 mm)

Height:

58.4 inches (1483 mm)

Trunk Capacity:

15.5 cu ft (439 L)

Curb Weight Tsi:

3,000 - 3,150 lbs (1361 - 1429 kg) depending on configuration

Curb Weight 2.5L:

3,050 - 3,230 lbs (1383 - 1465 kg) depending on configuration

🛡️ Safety Features

NHTSA Front Crash Test:

★★★★★ (5-Star)

IIHS Top Safety Pick:

Yes (for models equipped with optional side airbags)

Standard Active Safety:

Anti-lock Braking System (ABS), Traction Control System (TCS), Electronic Stability Control (ESC), Brake Assist

Standard Passive Safety:

Front airbags, front side-impact airbags, Side Curtain Protection® airbags (front and rear)

Optional Passive Safety:

Rear side-impact airbags

💡 Technology Features

Infotainment System Options:

RCD 310 (basic audio), RNS 315 (navigation with touchscreen), Premium 8 (touchscreen with Bluetooth and satellite radio)

Connectivity Options:

Auxiliary audio input, USB input (optional), Bluetooth connectivity (optional)

Driver Assistance Features:

Cruise control, rear parking sensors (optional), rearview camera (optional on select trims)

🔧 Maintenance

Oil Change Interval:

Typically every 10,000 miles (16,000 km) or 12 months with synthetic oil, or as indicated by the vehicle's flexible service reminder system.

Major Service Intervals:

Spark plugs at 40,000-60,000 miles (TSI), timing belt (if applicable) based on engine variant and mileage, coolant flush as per schedule.

Engine Oil Tsi:

SAE 5W-40 (VW 502 00 specification) or SAE 0W-30 (VW 504 00 specification)

Engine Oil 2.5L:

SAE 5W-40 (VW 502 00 specification)

Coolant Type:

G13 (Purple) coolant, pre-mixed or concentrate

Brake Fluid:

DOT 4 (VW TL 766-Z)

Common Electrical Issues:

HVAC blower motor resistor failure, ABS sensor failures, infotainment system glitches, lighting issues (e.g., trunk light staying on).

Common Mechanical Issues:

Carbon buildup on intake valves (TSI engine), oil consumption (TSI engine), DSG transmission mechatronic unit issues, catalytic converter failure (diesel models).

📚 Vehicle History

Volkswagen Legacy:

Established in 1937, Volkswagen is one of the world's largest and oldest automotive manufacturers, known for reliable and well-engineered vehicles like the Beetle and Golf.

Jetta Mk6 Introduction:

The Mk6 Jetta (A5 platform) was introduced for the 2011 model year. It featured a redesign focused on a more spacious interior and a more distinct North American market appeal, moving away from the more European styling of previous generations.

Assembly Locations 2011:

Mainly Wolfsburg, Germany, and Puebla, Mexico

🏆 Awards & Recognition

IIHS Awards 2011:

Insurance Institute for Highway Safety (IIHS) Top Safety Pick

Kbb Awards 2011:

Kelley Blue Book's (KBB) 'Best Resale Value' award for Compact Car segment (certain trims)
