2005 Volvo XC90 Service & Repair Manual Software

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Volvo Model: XC90 Year: 2005 Codes Platform: P2 Vin Character Position 1 8: YV1 Vin Character Position 10: 5 👋 Introduction Market Position Target Audience:...

20 people are viewing this right now

类型: Car

斯库: 551401

标签: 2005 Car Cars Featured Volvo XC90

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Volvo

Model:

Year:

Codes

Platform:

Vin Character Position 1 8:

Vin Character Position 10:

👋 Introduction

Market Position

Target Audience:

DIY enthusiasts, independent repair shops

Competitive Analysis

Advantage Over Print:

More convenient, cost-effective, instant access, searchable

Key Features

Convenience:

Instant online access, no shipping delays

Accuracy:

Factory-derived, licensed information

Value:

Cost savings through DIY repairs, renewable access

📋 Manual Details

Coverage Areas

Coverage Scope:

Comprehensive factory-derived service and repair information

Manual Type

Type:

Online Service and Repair Manual Software

Language

Language:

English

Format

Format:

Web-based software with one-year access

Access

Device Compatibility:

PC, Laptop, Smartphone, Tablet

Connection Requirement:

Internet connection and web browser

📖 Manual Coverage

Systems Covered

Powertrain:

Engine mechanical, engine electrical, fuel system, exhaust system, transmission (automatic)

Chassis:

Brakes, suspension, steering, wheels, tires

Electrical:

Body electrical systems, wiring diagrams, lighting, power accessories, climate control, instrumentation

Body And Frame:

Body panels, interior trim, doors, windows, glass, body hardware

Procedures Included

Maintenance:

Scheduled maintenance, fluid changes, filter replacements, inspections

Repair:

Component replacement, system diagnostics, troubleshooting, specific repair procedures

Technical Depth

Diagnostic Capabilities:

Detailed diagnostic procedures, symptom-to-cause charts, electrical troubleshooting diagrams

Repair Complexity:

Covers tasks from basic fluid checks to complex engine and transmission overhauls

📊 Manual Specifications

File Format

Format:

Digital, web-based

Print Quality

Printability:

Pages are typically printable for offline reference

Binding Type

Binding:

N/A (Online Access)

Paper Type

Paper Type:

N/A (Online Access)

Data Source

Licensing:

Officially licensed, derived from OE (Original Equipment) materials

Provider:

RepairSurge

⚙️ Engine Specifications

Primary Engine

Engine Code:

B6324S

Engine Type:

Naturally Aspirated V6 (Gasoline)

Displacement:

3.2 Liters (3192 cc)

Bore X Stroke:

84.0 mm x 96.0 mm

Compression Ratio:

10.0:1

Horsepower:

235 hp @ 6200 rpm

Torque:

236 lb-ft @ 3200 rpm

Fuel System

Fuel Delivery:

Electronic Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline, 91 octane (Octane Rating) recommended

Engine Cooling

Coolant Type:

Volvo VCS (Volvo Coolant System) or equivalent G48 (Ethylene Glycol based, blue color)

Coolant Capacity:

Approx. 9.5 liters (10.0 US quarts)

Lubrication

Oil Type:

SAE 0W-30 or SAE 5W-30 Synthetic Engine Oil

Oil Capacity:

Approx. 6.5 liters (6.9 US quarts) with filter change

Engine Management

ECU Model:

Bosch Motronic (specific variant for Volvo)

🔧 Transmission

Standard

Transmission Type:

AW55-50SN Geartronic (5-speed Automatic)

Features

Geartronic Functionality:

Manual shifting mode for driver control

Fluid Specification

Transmission Fluid Type:

JWS 3309 (ATF)

Fluid Capacity

Transmission Fluid Capacity:

Approx. 7.5 liters (7.9 US quarts) for a complete refill/flush

📐 Dimensions

Exterior

Length:

4797 mm (188.9 inches)

Width:

1899 mm (74.8 inches)

Height:

1745 mm (68.7 inches)

Wheelbase:

2815 mm (110.8 inches)

Weights

Curb Weight:

Approximately 1950-2050 kg (4300-4520 lbs) depending on configuration

Cargo

Cargo Volume:

705 liters (24.9 cubic feet) behind 3rd row (if equipped), 2045 liters (72.2 cubic feet) with 2nd and 3rd rows folded

🛡️ Safety Features

Ratings

NHTSA Front Impact Driver:

5 Stars

NHTSA Front Impact Passenger:

5 Stars

NHTSA Side Impact Front Passenger:

5 Stars

IIHS Top Safety Pick:

Passive Features

Airbags:

Driver, passenger, side curtain airbags

Rollover Protection:

ROPS (Roll Over Protection System) - WHIPS (Whiplash Protection System) in front seats

Active Features

Traction Control:

DSTC (Dynamic Stability Traction Control)

Braking System:

ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution)

💡 Technology Features

Infotainment

Audio System:

Premium sound systems available (e.g., Dynaudio), CD player, optional Dolby Surround Pro Logic II.

Navigation:

Optional GPS Navigation System

Driver Assistance

Parking Assistance:

Optional Rear Park Assist

Connectivity

Phone Integration:

Optional Bluetooth hands-free system

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 miles (12,000 km) or 12 months, whichever comes first (using synthetic oil)

Transmission Fluid Change:

Recommended every 30,000-50,000 miles (48,000-80,000 km) or per specific driving conditions.

Timing Belt Replacement:

N/A (The B6324S engine uses a timing chain, not a belt.)

Fluid Specifications

Brake Fluid Type:

DOT 4

Power Steering Fluid Type:

Volvo VEM (Hydraulic Fluid), equivalent to Pentosin CHF 11S

Washer Fluid:

Volvo Windshield Washer Fluid or equivalent, diluted with water (50/50 in freezing temperatures)

Known Issues

Common Issue 1:

Transmission control module (TCM) failure leading to shifting problems or limp mode.

Common Issue 2:

Vibration issues from driveshaft center bearing or propeller shaft.

Common Issue 3:

Water pump leaks, especially at the gasket.

Common Issue 4:

Electronic Module issues (CEM - Central Electronic Module), leading to various electrical gremlins.

Common Issue 5:

Rear differential bushings wear.

📚 Vehicle History

Brand Heritage

Brand Focus:

Safety, durability, Scandinavian design

Model Evolution

First Generation:

XC90 introduced in 2002 as a 2003 model year

Generation 1 Facelift:

Minor updates received throughout its lifecycle, including for the 2005 model year.

Production

Manufacturing Location:

Torslanda, Sweden

🏆 Awards & Recognition

Recognitions

Award 1:

Named MotorTrend's Sport/Utility of the Year for 2003

Award 2:

Recognized for its safety features and comfort.
