Segment:
High-performance Sport/Utility Side-by-Side (SxS) Utility Vehicle
Key Competitors:
Polaris RZR, Can-Am Commander, Kawasaki Teryx
Vehicle Selling Points:
Fuel Injection, Robust Drivetrain, Comfortable Seating for Two, Long-travel Suspension, Locking Front Differential
Covered Model Years:
2008, 2009, 2010, 2011, 2012, 2013
Covered Regions:
Global (assuming factory specifications)
Estimated Page Count:
Hundreds (specific number not provided but described as extensive)
Type:
Factory Service Repair Workshop Manual
Primary Language:
English
Digital Format:
PDF (Downloadable)
Mechanical Systems:
Engine, Drivetrain (Transmission, Differentials, Axles), Suspension, Steering, Brakes, Fuel System, Exhaust System, Cooling System
Electrical Systems:
Ignition System, Charging System, Lighting, Instruments, Wiring Diagrams, ECU (Engine Control Unit), Fuel Injection System Components
Chassis And Body:
Frame, Body Panels, Seats, Controls, Storage
Maintenance Procedures:
Routine Inspections, Oil Changes, Filter Replacements, Lubrication, Spark Plug Service, Air Filter Cleaning/Replacement
Diagnostic Procedures:
Troubleshooting Guides, Symptom-Based Diagnostics, Fault Code Interpretation (for FI systems)
Repair Procedures:
Component Overhaul and Reassembly, Component Replacement, Engine Tuning, Suspension Adjustments, Brake System Repairs, Electrical Component Diagnosis and Replacement
Special Procedures:
Fuel Injection System Servicing, ECU Initialization/Calibration (if applicable), Drive Belt Replacement, Differential Service
Diagnostic Capabilities:
Advanced Diagnostics, including Fuel Injection System analysis and potential ECU parameter checks (if diagnostic tools are compatible)
Rebuild Scope:
Full Engine Rebuilds, Transmission Overhauls, Differential Rebuilds
Information Detail:
Step-by-step instructions, Detailed exploded diagrams, High-quality photographs
Compatibility:
Windows and macOS compatible
Printability:
Printable (single pages or entire manual)
Digital Binding:
N/A (Digital Download)
Digital Quality:
High-resolution, suitable for on-screen viewing and printing
Licensing:
Lifetime use, unlimited installations
Engine Type:
Liquid-cooled, 4-stroke, DOHC, 4-valve, Parallel-twin
Bore X Stroke:
100.0 mm x 83.9 mm (approximate)
Compression Ratio:
8.1:1 (typical for this engine)
Horsepower Rating:
Approximately 45-50 HP (manufacturer data varies, official spec often withheld for ATVs)
Torque Rating:
Data not readily available in public domain, but strong low-end torque characteristic
Fuel Delivery:
Electronic Fuel Injection (EFI) with Twin Mikuni 33mm throttle bodies (or similar)
Fuel Type:
Unleaded Gasoline (87 octane or higher recommended)
Ignition System:
TCI (Transistor Controlled Ignition)
Cooling System:
Liquid-cooled
Transmission Type:
Automatic (CVT - Continuously Variable Transmission) with constant-mesh, 2-speed (High/Low range) and Reverse
Optional Transmission:
N/A (CVT is standard)
Drive Selection:
On-Demand 4WD with locking front differential, 2WD
Clutch Type:
Wet, centrifugal, automatic
Cvt Fluid Type:
Yamalube CVT Fluid or equivalent SAE 10W-30 API SG or higher
Length:
Approximately 113.4 inches (2880 mm)
Width:
Approximately 58.1 inches (1475 mm)
Height:
Approximately 74.1 inches (1882 mm)
Wheelbase:
Approximately 79.9 inches (2030 mm)
Dry Weight:
Approximately 1,034 lbs (469 kg)
Curb Weight:
Approximately 1,100 lbs (500 kg) (with fluids)
Cargo Bed Capacity:
Approximately 400 lbs (181 kg)
Towing Capacity:
Approximately 1,500 lbs (680 kg)
Front Tire Size:
AT25x8-12
Rear Tire Size:
AT25x10-12
Wheel Bolt Pattern:
5x114.3 mm (4.5 inch PCD)
Atv Safety Standards:
Adheres to ANSI standards for recreational off-highway vehicles.
Braking System:
Hydraulic disc brakes, front and rear
Parking Brake:
Mechanical caliper type
Rollover Protection:
Integrated Roll Over Protection Structure (ROPS) with seat belts
Seat Belts:
Standard 3-point seat belts
Infotainment System:
Basic analog/digital instrument cluster (Speedometer, Odometer, Fuel Gauge, EFI Warning Light)
Traction Control:
No electronic traction control, relies on mechanical differential locking
Connectivity Features:
N/A (No integrated Bluetooth, USB, or advanced electronic connectivity)
Engine Oil Change Interval:
Every 1,000 km or 100 hours of operation, or 6 months (whichever comes first)
Air Filter Service:
Every 500 km or 50 hours, or clean/inspect monthly
Spark Plug Replacement:
Every 4,000 km or 400 hours
Cvt Belt Inspection:
Inspect every 2,000 km or 200 hours
Engine Oil Type:
Yamalube 4 (or equivalent) SAE 10W-40 API SG or higher, JASO MA certified
Engine Oil Capacity:
Approximately 2.20 US qt (2.1 L) without filter change, 2.30 US qt (2.2 L) with filter change
Coolant Type:
High-quality ethylene glycol-based antifreeze coolant, 50/50 mix with distilled water
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid
Common Wear Items:
CVT belt wear, suspension bushings, wheel bearings, brake pads due to operating conditions
Fuel System Considerations:
Keeping fuel fresh and clean is crucial for EFI systems; occasional injector cleaning may be beneficial
Manufacturer History:
Yamaha Motor Company is a Japanese manufacturer with a long history in motorcycles, marine products, and powersports vehicles, known for its engineering and reliability.
Rhino Lineage:
The Rhino line, introduced in 2004, was Yamaha's pioneering entry into the Side-by-Side (SxS) market, evolving from a more utility-focused design to incorporate sportier elements.
Manufacturing Location:
Primarily manufactured in Japan (though specific model assembly locations can vary by market).
