Vehicle Segment:
Side-by-Side (SxS) Utility Vehicle
Target Audience:
Off-road enthusiasts, farmers, hunters, recreational users requiring a durable and capable utility vehicle.
Key Competitors:
Polaris Ranger, Can-Am Commander, Kawasaki Mule
Vehicle Strengths:
Reliability, robust construction, powerful engine, capable 4x4 system, comfortable seating for two.
Manual Value Proposition:
Provides comprehensive technical data to empower owners for DIY maintenance and repairs, saving time and money.
Powertrain:
Engine, Transmission, Drivetrain (4x4 System)
Chassis:
Suspension, Steering, Brakes, Frame
Electrical:
Ignition, Lighting, Starting System, Charging System, Wiring Diagrams, Instruments
Body And Trim:
Body Panels, Seats, Controls, Plastics
Fuel And Exhaust:
Fuel Injection System, Fuel Tank, Exhaust System
Cooling System:
Radiator, Fan, Coolant Flow
Lubrication System:
Engine Oil, Transmission Oil, Drivetrain Oil
Maintenance:
Scheduled Maintenance, Fluid Changes, Filter Replacements, Adjustments
Troubleshooting:
Diagnostic Procedures, Symptom-Based Troubleshooting Guides
Repair And Overhaul:
Engine Rebuild, Transmission Overhaul, Component Replacement
Disassembly Assembly:
Detailed step-by-step instructions with exploded views and diagrams for all major components.
Technical Specifications:
Torque values, clearances, measurements, tolerances
Depth:
Comprehensive (from basic adjustments to complete engine and transmission rebuilds)
Detail Level:
Detailed step-by-step instructions, illustrations, diagrams, and specifications.
Engine Type:
4-stroke, DOHC, 4-valve, liquid-cooled single cylinder
Displacement:
686 cc (41.86 cu. in.)
Bore X Stroke:
100.0 mm x 83.0 mm (3.94 in x 3.27 in)
Horsepower:
Approximately 45 hp @ 5500 rpm (Specific factory rating may vary slightly)
Torque:
Approximately 48.1 lb-ft @ 4500 rpm (Specific factory rating may vary slightly)
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded gasoline (87 octane or higher recommended)
Throttle Control:
Electronic Throttle Control (ETC) with drive-by-wire
Oil Type:
Yamalube 4 (10W-40) or equivalent (check manual for exact specifications)
Oil Capacity With Filter:
Approx. 3.70 US qt (3.5 L / 3.3 Imp qt) (Refer to manual for exact capacity)
Cooling Method:
Liquid Cooled
Coolant Type:
Yamaha Superlong Life Coolant (Blue) or equivalent ethylene glycol based coolant with demineralized water (50:50 mixture)
Type:
Automatic (Yamaha Ultramatic® Transmission)
Drive System:
Enclosed, O-ring sealed chain, 2WD/4WD with differential lock
Gear Selection:
H (High), L (Low), N (Neutral), R (Reverse), P (Park)
Engine Braking:
Integrated with Ultramatic® system for strong engine braking on descents.
Transmission Fluid Type:
Yamaha Hi-Performance Gear Oil or equivalent SAE 80 hypoid gear oil (Check manual for specific viscosity and API GL-4/GL-5 rating)
Gearcase Oil Capacity:
Approx. 0.75 US qt (0.7 L / 0.66 Imp qt) (Refer to manual for exact capacity)
Length:
Approx. 105.1 inches (2670 mm)
Width:
Approx. 55.7 inches (1415 mm)
Height:
Approx. 72.1 inches (1830 mm)
Wheelbase:
Approx. 79.5 inches (2020 mm)
Ground Clearance:
Approx. 11.4 inches (290 mm)
Dry Weight:
Approx. 649 lbs (294 kg)
Curb Weight:
Approx. 688 lbs (312 kg) (with standard equipment)
Cargo Bed Capacity:
Approx. 330 lbs (150 kg)
Towing Capacity:
Approx. 1,500 lbs (680 kg)
Payload Capacity:
Approx. 948 lbs (430 kg) (including rider and cargo)
Front Tire Size:
AT25x8-12
Rear Tire Size:
AT25x10-12
Wheel Offset:
Check manual for specific offset values
Rollover Protection:
ROPS (Roll-Over Protective Structure) compliant
Braking System:
Hydraulic disc brakes, front and rear
Parking Brake:
Mechanical, rear wheel
Seatbelts:
3-point seatbelts
Seat Design:
High-back bucket seats for driver and passenger
Hand Holds:
Assist grips for passenger safety
Instrumentation:
Digital LCD meter displaying speedometer, odometer, trip meter, clock, fuel gauge, 4WD indicator, and oil pressure warning.
Throttle System:
Electronic Throttle Control (ETC) provides smooth and precise throttle response.
Lighting:
Dual 30W halogen headlights, 8W brake/taillight
First Service:
Typically 10 hours or 1 month (Refer to manual for exact break-in service)
Engine Oil Change:
Every 100 hours or 6 months (whichever comes first, depending on operating conditions)
Air Filter Cleaning:
Every 50 hours or 3 months, or more frequently in dusty conditions
Spark Plug Inspection:
Every 100 hours or 6 months
Transmission Oil Change:
Every 200 hours or 12 months
Drive Belt Inspection:
Every 100 hours or 6 months
Engine Oil Grade:
SAE 10W-40 (Yamalube 4 or equivalent)
Coolant Type:
50/50 mixture of Yamaha Superlong Life Coolant (Blue) and demineralized water
Brake Fluid Type:
DOT 3 or DOT 4 (Refer to manual for specific type and SAE viscosity)
Common Wear Items:
Drive belt, wheel bearings, ball joints, tie rod ends, and bushings due to off-road usage.
Potential Electrical Gremlins:
Some owners have reported minor electrical issues, often related to connections or sensors, particularly with aftermarket accessories.
Engine Performance Tips:
Regular cleaning of the throttle body and ensuring proper air filter maintenance are crucial for optimal EFI performance.
Manufacturer Origin:
Japan
Yamaha Offroad Legacy:
Yamaha has a long-standing reputation for producing durable and high-performance off-road vehicles, including motorcycles and ATVs.
Rhino Introduction:
The Yamaha Rhino line was introduced to compete in the growing SxS market, offering a more utility-focused alternative to sportier models.
700Cc Engine Update:
The 700cc model represented a significant upgrade in power and performance over earlier Rhino models, featuring the fuel-injected engine.
Manufacturing Locations:
Primarily manufactured in Japan, with potential assembly in other regions depending on market.
