Yamaha RHINO 700 YXR70FX FUEL INJECTED Complete Workshop Repair Manual 2008-2014

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

The Yamaha Rhino 700, model code YXR70FX, is a robust Side-by-Side (SxS) utility vehicle produced from 2008 to 2014. Engineered for demanding off-road and work applications, it features a powerful...

16 people are viewing this right now

类型: Atv

斯库: 59088

标签: 2008 2009 2010 2011 2012 2013 2014 Atv Powersports RHINO 700 YXR70FX Rhino Models UTV Yamaha

产品多属性

Description

The Yamaha Rhino 700, model code YXR70FX, is a robust Side-by-Side (SxS) utility vehicle produced from 2008 to 2014. Engineered for demanding off-road and work applications, it features a powerful 686cc fuel-injected, liquid-cooled engine, an on-demand 4WD system with a locking front differential, and an independent double-wishbone suspension for superior comfort and control. Known for its premium utility, the Rhino 700 offers a high towing capacity, a substantial cargo bed, and comfortable two-passenger seating, establishing it as a reliable and durable choice in its class. This comprehensive workshop repair manual covers all YXR70FX variants from 2008 through 2014. It provides in-depth, professional-quality guidance for all aspects of vehicle service, repair, and maintenance, presented with step-by-step instructions, detailed diagrams, and wiring schematics. Key areas include complete engine overhaul, fuel injection system diagnosis, transmission service, drivetrain repair, brake system maintenance, suspension and steering adjustments, and electrical system troubleshooting. The manual is designed to empower owners, mechanics, and technicians in effectively maintaining and repairing the Yamaha Rhino 700.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

Rhino 700

Model Code:

YXR70FX

Vehicle Type:

Side-by-Side (SxS) / Utility Vehicle

Generation

Production Years Covered:

2008-2014

Codes

Engine Variant Identifier:

Fuel Injected

👋 Introduction

Market Position

Positioning:

Premium utility vehicle offering robust performance and durability for off-road and work applications.

Competitive Analysis

Key Competitors:

Polaris Ranger, Kawasaki Mule, Arctic Cat Prowler

Key Features

Engine Type:

Fuel Injected, Liquid-Cooled, DOHC, 4-stroke, 3-valve

Drivetrain Type:

On-Demand 4WD with 2WD and locking front differential

Suspension Type:

Independent double-wishbone suspension on all four wheels

Utility:

High towing capacity, large cargo bed, comfortable seating for two

📋 Manual Details

Coverage Areas

Vehicle Years:

2008, 2009, 2010, 2011, 2012, 2013, 2014

Models Covered:

All YXR70FX variants

Page Count

Estimated Page Count:

Comprehensive (typically 500+ pages for full workshop manuals)

Manual Type

Type:

Complete Workshop Repair Manual / Service Manual

Language

Primary Language:

English

Format

File Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine:

Complete engine overhaul, diagnosis, tuning, components (pistons, cylinders, valves, crankshaft, camshaft, timing system)

Fuel System:

Fuel injection system (EFI), fuel pump, injectors, throttle body, fuel tank, fuel lines, troubleshooting

Cooling System:

Radiator, fan, coolant, thermostat, water pump, hoses, diagnosis and repair

Transmission:

Automatic transmission (CVT), clutch assembly, drive belts, torque converter, gearbox overhaul, lubrication

Drivetrain:

Front and rear differentials, drive shafts, CV joints, U-joints, hub assembly, 4WD system operation and repair

Brakes:

Hydraulic brake system, brake pads, rotors, calipers, master cylinder, brake lines, bleeding procedures, parking brake

Suspension:

Front and rear suspension components (shocks, springs, control arms, bushings), alignment, steering knuckles

Steering:

Steering column, rack and pinion, tie rods, power steering system (if applicable), troubleshooting

Electrical System:

Battery, charging system (stator, regulator/rectifier), starting system (starter motor, solenoid), ignition system, lighting, fuses, relays, sensors

Wiring Diagrams:

Complete and detailed wiring schematics for all electrical systems, including diagnostic color coding

Chassis And Body:

Frame inspection, body panels, seats, rollover protection structure (ROPS), bodywork repair, plastics

Maintenance:

Routine checks, fluid changes, filter replacements, lubrication points, general servicing procedures

Troubleshooting:

Diagnostic charts, symptom-based troubleshooting guides for common and uncommon issues

Procedures Included

Engine Repair:

Engine rebuilds, top-end and bottom-end repairs, valve adjustments, timing chain replacement

Fuel Injection Diagnosis:

Injector cleaning/testing, sensor diagnosis (TPS, MAP, IAT), ECU troubleshooting

Transmission Service:

Fluid and filter changes, belt inspection and replacement, clutch adjustments

Brake Maintenance:

Pad and rotor replacement, caliper rebuilding, brake fluid flushing and bleeding

Suspension And Steering Repair:

Replacement of bushings, ball joints, tie rod ends, steering rack service

Electrical Diagnostics:

Component testing, wiring harness repair, circuit troubleshooting using multimeter and diagrams

Routine Maintenance:

Oil changes, filter replacements, spark plug checks, air filter service, lubrication

Seasonal Storage:

Procedures for preparing the vehicle for long-term storage

Safety Checks:

Pre-ride inspections, safety feature verification

Technical Depth

Depth:

In-depth, professional quality, covering all areas of service, repair, and maintenance

Detail Level:

Step-by-step instructions with pictures and wiring diagrams

📊 Manual Specifications

File Format

Format:

PDF Download

Compatibility:

PC, MAC, Tablets, Smartphones, Linux

Print Quality

Clarity:

High resolution, suitable for printing individual pages or the entire manual

Binding Type

Digital Format:

N/A (Digital Download)

Paper Type

Digital Format:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

686cc liquid-cooled, SOHC, 4-stroke, 4-valve, fuel-injected engine

Bore X Stroke:

100.0 mm x 83.0 mm

Compression Ratio:

9.2:1

Fuel Induction:

Electronic Fuel Injection (EFI) with 44mm throttle body

Performance

Estimated Horsepower:

Approx. 45-50 hp (actual figures may vary slightly by year/tuning)

Estimated Torque:

Approx. 42-45 lb-ft (actual figures may vary slightly by year/tuning)

Fuel System

Fuel Type:

Unleaded gasoline

Fuel Capacity:

7.9 gallons (30 Liters)

Lubrication

Oil Type:

Yamalube 4 (or equivalent) SAE 10W-40 API SG or higher

Oil Capacity:

2.16 US qt (2.05 L) without filter change; 2.31 US qt (2.19 L) with filter change

🔧 Transmission

Standard

Type:

Yamaha's Ultramatic® V-belt automatic transmission with engine braking

Features

Gear Selection:

H (High), L (Low), N (Neutral), R (Reverse), P (Park)

Drive System:

On-Command® 4WD with driver-selectable 2WD or 4WD and locking front differential

Drive Shafts:

CV shafts with protective boots

📐 Dimensions

Exterior

Length:

Approx. 115.6 inches (2935 mm)

Width:

Approx. 62.0 inches (1575 mm)

Height:

Approx. 75.2 inches (1910 mm)

Weights

Dry Weight:

Approx. 1,102 lbs (500 kg)

Curb Weight:

Approx. 1,157 lbs (525 kg)

Cargo

Cargo Bed Capacity:

Approx. 400 lbs (181 kg)

Towing Capacity:

Approx. 1,322 lbs (600 kg)

Wheels And Tires

Front Tire Size:

25 x 8-12

Rear Tire Size:

25 x 10-12

Wheelbase:

Approx. 79.9 inches (2030 mm)

Ground Clearance:

Approx. 11.2 inches (285 mm)

🛡️ Safety Features

Ratings

Rollover Protection:

Standard ROPS (Rollover Protection Structure)

Active Features

Braking System:

Hydraulic disc brakes front and rear

Parking Brake:

Mechanical parking brake

Passive Features

Seatbelts:

Standard seatbelts

Seating:

Two-passenger seating with supportive seats

💡 Technology Features

Infotainment

Audio System:

Generally not equipped with a factory-installed audio system; designed for utility and off-road performance.

Driver Assistance

Traction Control:

Limited slip differential in front for enhanced traction, coupled with the On-Command® 4WD system.

Connectivity

Diagnostic Ports:

Diagnostic port for EFI system diagnostics (OBD-style access may be present).

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 3,000 miles (5,000 km) or 6 months, whichever comes first; or every 100 hours of operation.

Air Filter Cleaning:

Inspect every 500 miles (800 km) or 100 hours; clean or replace as needed.

Spark Plug Replacement:

Replace every 6,000 miles (10,000 km) or 1 year.

Transmission Oil Change:

Every 6,000 miles (10,000 km) or 1 year.

Brake Fluid Flush:

Every 2 years or as needed based on condition.

Fluid Specifications

Engine Oil:

Yamalube 4 (or equivalent) SAE 10W-40 API SG or higher

Gear Oil:

Yamalube Gear Oil (or equivalent) SAE 80W-90 API GL-4

Coolant:

High-quality ethylene glycol based coolant, 50/50 mix with distilled water

Brake Fluid:

DOT 3 or DOT 4 hydraulic brake fluid

Known Issues

Drive Belt Wear:

CVT drive belt can wear over time, especially under heavy use. Regular inspection and replacement are recommended.

Cv Joint Boots:

CV joint boots are susceptible to damage from debris and can lead to premature joint wear if not maintained.

Efi System Maintenance:

Periodic cleaning of the throttle body and checking of fuel injectors can prevent performance issues.

📚 Vehicle History

Brand Heritage

Manufacturer:

Yamaha Motor Corporation, known for its long history in powersports, motorcycles, and marine engines.

Model Evolution

Rhino Lineage:

The Rhino line was a pioneering force in the modern side-by-side market, emphasizing utility, durability, and off-road capability. The 700 EFI model represented an advancement with improved fuel efficiency and performance.

Production

Manufacturing Origin:

Primarily manufactured in Japan and the USA.

🏆 Awards & Recognition

Recognitions

Market Reputation:

Highly regarded for its reliability, durability, and strong performance in the utility SxS segment.
