Target Audience:
Do-it-yourself mechanics, owners seeking to save on dealer labor costs, and motorcycle enthusiasts.
Cost Savings:
Enables owners to perform routine maintenance and repairs, potentially saving hundreds or thousands in dealership labor costs ($70+ per hour).
Visual Aids:
Detailed diagrams, illustrations, photos, and exploded views enhance understanding and ease of repair.
Accessibility:
Instant download provides immediate access to repair information without shipping delays.
Product Name:
2014-2016 Yamaha Star Bolt & Bolt R-Spec XVS950 Factory Service Repair Manual
Manual Identifier:
LIT-11616-27-30
Coverage Areas:
All repair topics including general information, periodic maintenance, fuel system, cooling system, engine top end, engine lubrication system, engine removal/installation, crankshaft/crankcase, transmission, wheels/tires, final drive, brakes, suspension, steering, frame, and electrical system.
Manual Type:
Factory Service Repair Manual
File Format:
PDF Download
Engine Systems:
Engine top end, lubrication system, removal/installation, crankshaft, crankcase.
Fuel System:
Comprehensive coverage of fuel delivery, injection, and related components.
Cooling System:
Details on cooling system operation, maintenance, and repair.
Drivetrain:
Transmission, final drive (belt drive system), wheels, and tires.
Braking System:
Service procedures for hydraulic brake systems.
Suspension Steering:
Front and rear suspension components, steering system.
Frame Bodywork:
Frame structure, body components, and mounting procedures.
Electrical System:
Wiring diagrams, ignition, lighting, starting system, battery, and electronic components.
Maintenance:
Periodic maintenance schedules, fluid changes, filter replacements, adjustments.
Diagnostics:
Troubleshooting guides, diagnostic charts, symptom-to-cause identification.
Repair:
Step-by-step repair instructions for all major vehicle systems.
Disassembly Assembly:
Detailed procedures for component removal and reinstallation.
Technical Depth:
Comprehensive, covering from basic maintenance to in-depth engine and transmission overhauls, electrical troubleshooting, and component diagnostics.
Resolution:
High Resolution
Navigation:
Easy-to-use clickable menu, bookmarks, keyword searchable.
Searchability:
Fully keyword searchable text.
Print Options:
Print one page, one chapter, or the entire manual.
Operating Systems:
Compatible with all versions of Windows & Mac.
Reader Requirement:
Adobe PDF Reader required.
Engine Type:
Air-cooled, 4-stroke, SOHC, 4-valve, V-twin
Displacement:
942 cc (57.4 cu. in.)
Bore X Stroke:
85 mm x 83 mm
Fuel Delivery:
Fuel injection with twin-spray injectors
Ignition System:
TCI (Transistor Controlled Ignition)
Lubrication Type:
Wet sump with oil cooler
Horsepower Approx:
58 hp @ 5,500 rpm (estimated, for reference; manual provides detailed performance specs)
Torque Approx:
59.9 lb-ft @ 3,000 rpm (estimated, for reference; manual provides detailed performance specs)
Valve Train:
SOHC (Single Overhead Camshaft) with 4 valves per cylinder, optimized for smooth power delivery and efficiency.
Fuel Injection:
Advanced fuel injection system with dual injectors per cylinder for precise fuel atomization and optimal combustion.
Style:
Minimalist 'Salt Flat Racer' aesthetic with a focus on clean lines and accessible customization.
Initial Service:
Typically around 1,000 km (600 miles) for first service, covering oil change, filter check, and basic adjustments.
Periodic Maintenance:
Detailed schedule provided in the manual, usually every 5,000-10,000 km (3,000-6,000 miles) for major checks, fluid changes, and component inspections.
Engine Oil Type:
Yamalube 20W-40 API SG, SJ, SL, SM or higher, SE recommended. Manual will specify exact grade and API classification.
Engine Oil Capacity:
Approx. 3.70 L (3.91 US qt) without filter change, 3.90 L (4.12 US qt) with filter change. Manual provides precise capacity.
Brake Fluid Type:
DOT 4 SAE J1703 or FMVSS 116.
Coolant Type:
Yamaha-specific liquid-cooled engine coolant or equivalent ethylene glycol-based coolant with deionized water.
Final Drive Oil:
Not applicable, uses belt drive.
Common Wear Items:
Belt drive components (tension, alignment, replacement), brake pads, tires, and battery are typical wear items that require regular inspection and replacement as detailed in the manual.
Electrical Maintenance:
Checking battery terminals, ensuring proper grounding, and inspecting wiring harnesses for damage are crucial for reliable electrical system operation.
Brand Focus:
Yamaha's reputation for reliable, performance-oriented motorcycles with a strong emphasis on engineering and rider experience.
Model Lineage:
The Star Bolt series draws inspiration from classic American V-twin cruisers, reinterpreted with modern technology and minimalist styling.
Manufacturing Origin:
Likely manufactured in Japan or through Yamaha's global manufacturing network.
