Market Segment:
Cruiser, Custom Motorcycle
Target Audience:
Owners seeking to perform their own maintenance and repairs, independent repair shops
Key Differentiator:
Comprehensive factory-level repair information for a specific model range
Detail Level:
Hundreds of pages with detailed photos and diagrams
Instruction Style:
Step-by-step instructions for accuracy
Diagrams:
Highly detailed exploded diagrams
Engine:
Complete engine overhaul, diagnosis, tuning
Fuel System:
Fuel injection system, fuel pump, injectors, throttle body
Exhaust System:
Exhaust manifold, muffler, catalytic converter (if applicable)
Cooling System:
Radiator, fan, coolant, hoses, thermostat
Transmission:
Clutch, gearbox, internal components, adjustments
Chassis:
Frame, swingarm, linkages, bearings
Suspension:
Front forks, rear shock absorber, seals, adjustments
Braking System:
Front and rear brakes, calipers, discs, lines, fluid
Electrical System:
Wiring diagrams, battery, charging system, ignition, lighting, starter
Instrumentation:
Speedometer, tachometer, indicators, diagnostic codes
Bodywork:
Fenders, fuel tank, seat, covers, fairings (if applicable)
Controls:
Handlebars, levers, pedals, cables
Wheels And Tires:
Wheel removal/installation, tire changes, balancing
Maintenance:
Scheduled maintenance, oil changes, filter replacements, lubrication
Repair:
Component repair and replacement for all systems
Troubleshooting:
Diagnostic procedures for common and uncommon faults
Assembly Disassembly:
Step-by-step instructions with detailed diagrams
Specifications:
Torque values, clearances, fluid capacities, electrical specs
Depth:
Comprehensive: from basic maintenance to complete engine rebuilds and electrical diagnostics
Searchability:
Searchable text content for quick information retrieval
Printability:
Printable pages (single or full manual)
Image Quality:
High-resolution photos and detailed diagrams
Binding Type:
N/A (Digital Download)
Paper Type:
N/A (Digital Download)
Usage License:
Unlimited lifetime use on multiple devices/computers
Updates:
No renewal fees or expiry
Engine Type:
Air-cooled, 4-stroke, SOHC, V-twin
Displacement:
942 cc (57.5 cu. in.)
Bore X Stroke:
85.0 mm x 83.0 mm (3.35 in x 3.27 in)
Horsepower Estimated:
Approx. 50 hp @ 5,500 rpm (Varies by market and tuning)
Torque Estimated:
Approx. 59.7 lb-ft @ 3,000 rpm (Varies by market and tuning)
Fuel Delivery:
Fuel Injection
Carburetion Type:
N/A (Fuel Injected)
Fuel Type:
Unleaded gasoline
Oil Type Recommendation:
Yamalube 4 (or equivalent) SAE 20W-40 API SG or higher (Specific grade and spec detailed in manual)
Ignition System:
TCIS (Transistor Controlled Ignition)
Length:
Approx. 2,290 mm (89.7 in)
Width:
Approx. 795 mm (31.3 in)
Height:
Approx. 1,080 mm (42.5 in) / 1,105 mm (43.5 in) R-Spec
Wheelbase:
Approx. 1,570 mm (61.8 in)
Wet Weight:
Approx. 245 kg (540 lbs) / 248 kg (547 lbs) R-Spec
Fuel Capacity:
Approx. 12.2 L (3.2 US gal)
Ground Clearance:
Approx. 160 mm (6.3 in)
Seat Height:
Approx. 690 mm (27.2 in)
Display Type:
LCD instrument cluster with indicator lights
Features Included:
Speedometer, Odometer, Trip Meter, Fuel Gauge, Gear Position Indicator (on some models/years), Warning lights.
ABS Availability:
Optional ABS system for enhanced braking control.
Oil Change Interval:
Refer to manual (Typically 3,000-5,000 miles or 6-12 months)
Air Filter Check Interval:
Refer to manual (Often tied to mileage or annual inspection)
Spark Plug Replacement Interval:
Refer to manual (Typically 10,000-15,000 miles)
Engine Oil Capacity:
Approx. 3.7 L (3.9 US qt) with filter change (Refer to manual for exact capacity)
Brake Fluid Type:
DOT 4 hydraulic brake fluid (Refer to manual for specific Yamaha recommendations)
Coolant Type:
Yamaha's recommended coolant (Ethylene glycol based) with demineralized water (Refer to manual for mixture ratio)
Common Concerns:
Occasional reports of ECU calibration issues, minor electrical connector corrosion in exposed areas (addressable with proper maintenance as per manual).
