Target Audience:
DIY motorcycle enthusiasts, independent repair shops, Yamaha Star Bolt owners
Value Proposition:
Empowers owners to perform their own maintenance and repairs, saving significant costs compared to dealership service.
Competitors:
Factory service manuals, other third-party repair manuals, online forums (less structured and reliable).
Ease Of Use:
Easy-to-follow step-by-step instructions with clear illustrations and pictures.
Completeness:
Covers all service and repair procedures from A to Z.
Accessibility:
Instant delivery and multi-device compatibility.
Primary Coverage:
Complete Service and Repair Procedures
Model Variant Coverage:
All Star Bolt and Bolt R-Spec models/engines/trim/transmissions
Estimated Page Count:
Estimated 400-600+ pages (typical for comprehensive workshop manuals)
Type:
Workshop Service Repair Manual
Delivery Format:
Downloadable Digital Format (PDF)
Accessibility:
Viewable on PC, MAC, Tablets, Smartphones
Software Requirement:
Adobe Reader (Free)
Engine:
Full engine overhaul, top end, bottom end, cooling, lubrication, fuel injection, ignition
Transmission:
Clutch, gearbox, final drive (belt drive)
Chassis:
Frame, suspension (front fork, rear shock), steering
Brakes:
Front and rear brake systems, hydraulic lines, caliper service, master cylinders
Electrical:
Wiring diagrams, lighting, starting system, charging system, sensors, ECU diagnostics
Fuel System:
Fuel tank, fuel pump, fuel injectors, fuel filter
Exhaust System:
Exhaust pipes, mufflers, catalytic converter (if applicable)
Bodywork:
Fenders, fuel tank, seat, handlebars, controls, instrumentation
Maintenance:
Scheduled maintenance, oil changes, filter replacements, chain/belt adjustment, brake checks
Troubleshooting:
Diagnostic procedures for common and uncommon issues, fault code interpretation
Repair:
Step-by-step repair instructions for all major and minor components
Disassembly Reassembly:
Complete instructions for component removal and installation
Component Overhaul:
Detailed procedures for engine, transmission, and other major component rebuilds
Depth:
Comprehensive A-Z coverage from basic maintenance to complete engine rebuilds and diagnostics
Diagnostic Focus:
Detailed diagnostic charts and procedures for identifying and resolving issues
Torque Specifications:
Includes all critical torque values for fasteners
Electrical Diagrams:
High-quality, detailed wiring diagrams
Engine Type:
Air-cooled, 4-stroke, SOHC, 4-valve, V-twin
Displacement:
942cc (57.5 cubic inches)
Bore X Stroke:
95mm x 68mm (typical for this engine family)
Compression Ratio:
9.0:1 (typical for this engine family)
Horsepower:
Approx. 50 HP @ 5500 RPM (estimated, based on similar models)
Torque:
Approx. 59 lb-ft @ 3000 RPM (estimated, based on similar models)
Fuel Delivery:
Fuel Injection with Dual Mikuni 35mm throttle bodies
Fuel Type:
Unleaded gasoline (91 octane or higher recommended)
Oil Type:
Yamalube 4 (or equivalent) SAE 20W-40 API SG or higher (refer to manual for exact spec)
Oil Capacity:
Approx. 3.7 US qt (3.5 L) with oil filter change (refer to manual for exact spec)
Overall Length:
Approx. 2290 mm (89.9 in)
Overall Width:
Approx. 970 mm (38.2 in)
Overall Height:
Approx. 1135 mm (44.7 in)
Seat Height:
Approx. 690 mm (27.2 in)
Wet Weight:
Approx. 247 kg (545 lbs) for Bolt R-Spec, slightly less for standard Bolt (refer to manual for exact figures)
Fuel Capacity:
Approx. 12.2 L (3.2 US gal)
Features:
Minimalist design. Features include an LCD instrument cluster with speedometer, odometer, trip meter, fuel gauge, and clock.
ABS:
Optional Anti-lock Braking System (ABS) available on select R-Spec models for enhanced braking control.
Features:
N/A (No built-in Bluetooth or smartphone integration from the factory).
First Service:
Typically at 600 miles or 1 month (refer to manual for exact specifications)
Subsequent Services:
Intervals vary for oil changes, filter replacements, belt inspection/tensioning, and valve adjustments (refer to manual for detailed schedule).
Engine Oil:
Yamalube 4 (or equivalent) SAE 20W-40 API SG or higher
Brake Fluid:
DOT 4 hydraulic brake fluid
Coolant:
N/A (Air-cooled engine)
Common Wear Items:
Tires, brake pads, clutch plates (depending on riding style), belt drive wear.
Potential Electronic Issues:
Infrequent reports of minor sensor issues or intermittent electrical connections; covered thoroughly in the manual's troubleshooting section.
Common Maintenance Tasks:
Belt tension adjustment, air filter cleaning/replacement, spark plug replacement.
Yamaha Motorcycles:
Yamaha Motor Corporation is a Japanese manufacturer renowned for its high-performance motorcycles, musical instruments, and powersports products. Established in 1955, Yamaha has a long history of innovation and quality.
Star Bolt Introduction:
The Star Bolt line was introduced in 2014 as a more accessible, customizable, and modern take on the cruiser segment, targeting a younger demographic and those seeking a 'bobber' style motorcycle. It leveraged Yamaha's proven 950cc V-twin engine.
Bolt R-Spec Distinction:
The R-Spec variant typically features upgraded suspension components (like remote reservoir rear shocks), premium paint finishes, and sometimes different styling cues, offering a sportier feel and aesthetic.
Manufacturing Location:
Assembled in the USA (typically at Yamaha's facility in Newnan, Georgia)
