1995 to 2004 Yamaha YFM 350 EX WOLVERINE ATV Service Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Yamaha Model: YFM 350 EX Wolverine Year: 1995-2004 Generation: 1st Generation (1995-2004) 📋 Manual Details Document Info Manual Type: Factory Service Repair Manual Language: English...

28 people are viewing this right now

类型: Atv

斯库: 26597

标签: 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 ATV Powersports Wolverine Models Yamaha YFM 350 EX WOLVERINE

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

YFM 350 EX Wolverine

Year:

1995-2004

Generation:

1st Generation (1995-2004)

📋 Manual Details

Document Info

Manual Type:

Factory Service Repair Manual

Language:

English

Format:

PDF Download

Coverage

Included Models:

YFM-350EX, YFM-350FXM(C), YFM-350FXLC, YFM-35FXG, YFM-35FXH

Content

Wiring Diagrams Included:

⚙️ Engine Specifications

Engine Information

Engine Type:

Air-cooled, 4-stroke, SOHC, 2-valve

Displacement:

348cc

Bore X Stroke:

83 x 64.5 mm

Compression Ratio:

9.2:1

Carburetion:

Mikuni VM32SS

Ignition:

C.D.I.

🔧 Transmission

Drivetrain

Transmission Type:

5-speed constant mesh with reverse

Final Drive:

Chain drive

Clutch Type:

Wet, multiple disc

🔧 Maintenance

Lubrication

Oil Capacity W Filter:

2.0L (2.1 qt)

Recommended Oil:

Yamalube 4 (or equivalent) 10W-40 SE

Ignition System

Spark Plug Type:

NGK CR6HSA

Spark Plug Gap:

0.6-0.7 mm (0.024-0.028 in)

Fuel System

Fuel Tank Capacity:

11.0 L (2.9 gal)

📄 Chassis

Suspension

Front Suspension Type:

Independent double wishbone with adjustable spring preload

Front Wheel Travel:

135 mm (5.3 in)

Rear Suspension Type:

Swing arm with adjustable spring preload

Rear Wheel Travel:

140 mm (5.5 in)

Brakes

Front Brake Type:

Dual hydraulic disc

Rear Brake Type:

Dual hydraulic disc

Wheels And Tires

Front Tire Size:

AT22x8-12

Rear Tire Size:

AT22x10-10

Dimensions

Length:

1830 mm (72.0 in)

Width:

1095 mm (43.1 in)

Height:

1120 mm (44.1 in)

Wheelbase:

1255 mm (49.4 in)

Ground Clearance:

160 mm (6.3 in)

Dry Weight:

234 kg (516 lbs)
