  • Bobcat 773 Skid Steer Loader /hydraulic/hydrostatic Electrical Wiring Diagrams PDF
1 2

Bobcat 773 Skid Steer Loader Wiring/Hydraulic/Hydrostatic Schematic

$16.99
$16.99
🏷️ Basic Information Identification Make: Bobcat Model: 773 Skid Steer Loader Model Variant: 773 (standard flow) Production Years Covered: 1993-2004 (approx.) 👋 Introduction Market Position Target Audience: Owners, technicians, and...
15 people are viewing this right now
Type: Skid Steer
Vendor:
Bobcat
Sku: 523148
Tags: 773 Bobcat Featured Skid Steer
Bobcat 773 Skid Steer Loader /hydraulic/hydrostatic Electrical Wiring Diagrams PDF
🏷️ Basic Information
Identification
Make:
Bobcat
Model:
773 Skid Steer Loader
Model Variant:
773 (standard flow)
Production Years Covered:
1993-2004 (approx.)
👋 Introduction
Market Position
Target Audience:
Owners, technicians, and restoration specialists
Competitive Advantage:
Comprehensive wiring, hydraulic, and hydrostatic schematics specific to the 773, enabling precise diagnostics.
Key Features
Key Feature:
Factory-level repair procedures
Key Feature:
Detailed electrical and hydraulic diagrams
Key Feature:
Instant digital download
📋 Manual Details
Specifications
Coverage Areas:
Wiring, hydraulic, hydrostatic systems
Page Count:
N/A - not specified in original catalog record
Manual Type:
Schematic and service manual
Language:
English
Format:
Digital PDF
📖 Manual Coverage
Systems Covered
System:
Electrical wiring diagrams
System:
Hydraulic schematics
System:
Hydrostatic drive schematics
Procedures Included
Procedure:
Service and maintenance procedures
Procedure:
Troubleshooting and diagnostics
Procedure:
Component removal and installation
Procedure:
Repair workshop reference
Technical Depth
Depth:
Factory-level repair procedures
Depth:
Comprehensive diagnostic information
Depth:
Technical specifications
Parts Information
Parts Info:
N/A - schematic manual focuses on diagrams, not parts lists
📊 Manual Specifications
Format
File Format:
PDF
Compatibility:
Works on computer, tablet, and phone
Requirements:
PDF reader software
Searchability:
Digitally searchable text
Print Quality
Print Quality:
High-resolution schematics
Binding Type
Binding:
Digital (no physical binding)
Paper Type
Paper Type:
N/A - digital format
⚙️ Engine Specifications
Engine Options
Primary Engine:
Gasoline or diesel (see below)
Engine Options:
1.6L gasoline (Kubota) / 1.5L diesel (Kubota) depending on year
Performance
Horsepower:
Approx. 30-40 HP depending on engine and year
Fuel System
Fuel Type:
Gasoline or diesel depending on engine
Injection:
Direct injection for diesel, carbureted for earlier gasoline engines
🔧 Transmission
Configuration
Standard Transmission:
Hydrostatic drive
Optional Transmission:
N/A - only hydrostatic available on 773
Features
Drive:
Dual-path hydrostatic with chain drive to wheels
Controls:
Hand levers for drive and loader functions
📐 Dimensions
Exterior
Wheelbase:
Approx. 1067 mm (42 in)
Length:
Approx. 2794 mm (110 in)
Weights
Curb Weight:
Approx. 2313 kg (5100 lb)
🛡️ Safety Features
Crash Test Information
Crash Test Rating:
N/A - skid steer loader, not road vehicle
Active Safety
ROPS:
Rollover protective structure (ROPS) standard
FOPS:
Falling object protective structure (FOPS) optional
Passive Safety
Seat Belt:
Seat belt standard
💡 Technology Features
Infotainment
Audio System:
N/A - not applicable to skid steer loader
Driver Assistance
Monitoring:
Basic instrument panel with warning lights
🔧 Maintenance
Service Intervals
Oil Change:
Engine oil change every 250 hours or annually
Hydraulic Fluid:
Check/replace per manual
Filters:
Replace fuel, hydraulic, and air filters as scheduled
Fluid Specifications
Engine Oil:
10W-30 (API SF/CD or higher)
Hydraulic Fluid:
Bobcat HY-GARD or equivalent (10W-30)
Known Issues & Wear Items
Common Issues:
Wiring harness chafing, hydrostatic pump seal leaks, cylinder drift
Wear Items:
Tires, drive chains, pivot pins, bushings
📚 Vehicle History
Brand Heritage
Manufacturer:
Bobcat Company (part of Doosan Bobcat)
Heritage:
Bobcat introduced the first skid steer loader in 1958 and has been a leader in compact equipment.
Model Evolution
Predecessor:
Bobcat 743
Successor:
Bobcat S175 (in same size class eventually)
Production Location
Manufacturing Plant:
Gwinner, North Dakota, USA (historical)
🏆 Awards & Recognition
Recognition
Awards:
N/A - specific awards not noted for this model
