CASE I.H. 5130 Tractor Service Manual
- Regular price
- $16.99
- Sale price
- $16.99
- Regular price
-
- Unit price
- / per
🏷️ Basic Information Identification Make: Case IH Model: 5130 Model Variant: 5130 (agricultural tractor) Production Years Covered: 1994-1998 (approximate) 👋 Introduction Market Position Target Audience: Farmers, ranchers, and agricultural equipment...
19 people are viewing this right now
Type: Tractor
Vendor:
Sku: 176962
Couldn't load pickup availability
Share
🏷️ Basic Information
Identification
Make:
Case IH
Model:
5130
Model Variant:
5130 (agricultural tractor)
Production Years Covered:
1994-1998 (approximate)
👋 Introduction
Market Position
Target Audience:
Farmers, ranchers, and agricultural equipment owners needing reliable mid-horsepower tractor for fieldwork and utility tasks.
Segment:
Row-crop and utility tractor segment (approx. 80-100 PTO hp)
Competitive Analysis
Advantage over Competitors:
Proven Case IH heritage with strong hydraulic capacity and dependable mechanical design, offering excellent resale value in the used market.
Key Features
Engine:
Case IH 4-cylinder diesel, turbocharged. Displacement approx. 4.0 L (239 cu in).
Transmission:
Full power shift or synchromesh options depending on configuration.
Hydraulics:
Closed-centre hydraulic system with up to 3 remotes on some models.
Cab:
Optional quiet cab with air conditioning on luxury models.
📋 Manual Details
Coverage Areas
Coverage:
Complete service, repair, and maintenance information for all major systems and components.
Physical Specification
Page Count:
Approximately 800-1200 pages (exact count not specified)
Manual Type:
Service and repair manual
Language:
English
Format
File Format:
PDF
Delivery Method:
Instant download
📖 Manual Coverage
Systems Covered
General Information:
Safety notices, identification numbers, special tools, and standard service practices.
Engine Mechanical:
Complete overhaul, disassembly, inspection, and reassembly of the diesel engine.
Cooling System:
Radiator, fan, thermostat, water pump, flushing and coolant specifications.
Lubrication System:
Oil pump, filter, pressure checks, oil specification and capacity.
Fuel System:
Injection pump, injectors, fuel lines, filters, bleeding and low-pressure fuel system.
Air Intake and Exhaust:
Turbocharger, intercooler, exhaust manifold, muffler and air cleaner.
Electrical System:
Battery, alternator, starter, wiring schematics, sensors, and switches.
Power Train:
Clutch, gearbox (transmission), final drives, differential lock and axles.
Hydraulic System:
Hydraulic pump, control valves, lift arms, draft control, and auxiliary remote valves.
Steering System:
Power steering gear, pump, linkage and adjustments.
Brakes:
Service brakes, parking brake, hydraulic brake valves and lining replacement.
Cab and Climate:
Heater and air conditioning components, cab pressurization, and air filters.
Procedures Included
Service:
Scheduled maintenance, fluid checks, and filter replacements.
Repair:
Component disassembly, inspection, and reconditioning with torque specifications.
Troubleshooting:
Diagnostic guides to isolate mechanical and electrical faults.
Specifications:
Tightening torques, clearances, capacities, and adjustment data.
Technical Depth
Level:
Comprehensive workshop manual suitable for experienced technicians and well-equipped DIY mechanics.
Parts Information
Parts Numbers:
Original Case IH part numbers are referenced where applicable.
📊 Manual Specifications
Digital File
File Format:
PDF
Compatibility:
Works on any device with a PDF viewer (Windows, Mac, Linux, Android, iOS).
Requirements:
No special software needed. High-speed internet recommended for download.
Searchability:
Text-searchable PDF allows quick lookup of terms and keywords.
Print Quality
Resolution:
High-resolution pages ensuring clear diagrams and text when printed.
Diagram Clarity:
Detailed line drawings and schematics are sharp and legible.
Binding
Binding Type:
Digital binding (no physical binding)
Paper Type
Paper Type:
Not applicable - digital download only.
⚙️ Engine Specifications
Engine Overview
Engine Make:
Case IH
Engine Type:
4.0 L (239 cu in) 4-cylinder turbocharged diesel
Power Output:
Approximately 92 PTO horsepower (68 kW)
Torque:
Approximately 350 Nm (258 lb-ft) at rated speed (typical)
Displacement:
4.0 liters (239 cubic inches)
Cylinders:
4 in-line
Aspiration:
Turbocharged
Compression Ratio:
Typically 16.5:1 - verify in manual
Fuel System
Injection:
Direct injection
Fuel Type:
Diesel
Injection Pump:
Bosch or Stanadyne (verify exact model in manual)
🔧 Transmission
Transmission Options
Standard Transmission:
Synchromesh, 8F/4R (typical) or 12F/4R
Optional Transmission:
Full power shift, e.g., 24F/12R (case options)
Clutch:
Dry single disc or wet multi-disc depending on transmission option.
Features
Shift Mechanism:
Synchromesh or power shift with electro-hydraulic solenoids.
Range:
Several ranges to optimize speed for field and transport.
Differential Lock:
Rear differential lock engaged via foot pedal.
📐 Dimensions
Exterior
Wheelbase:
Approx. 2.6 m (102 in)
Length:
Approx. 4.3 m (169 in) with 3-point hitch
Width:
Varies with tire settings; typically 2.0-2.4 m
Height:
Approx. 2.8 m (110 in) to top of cab
Weights
Curb Weight:
Approx. 4,500-5,000 kg (9,900-11,000 lb)
Ballast:
Addable front weights and wheel weights to optimize traction.
🛡️ Safety Features
Ratings and Tests
Crash Test Rating:
Not applicable - off-road agricultural tractor.
Safety Certification:
Meets applicable standards for stability, rollover protection (ROPS), and lighting.
Active Safety
Brakes:
Hydraulically actuated disc brakes on the rear wheels.
Steering:
Hydrostatic power steering for responsive control.
Passive Safety
ROPS:
Rollover protective structure or cab is standard.
Seat Belt:
Operator seat belt provided.
Cab Safety:
Cab and controls designed to protect operator in case of overturn.
💡 Technology Features
Infotainment
Audio System:
Optional AM/FM radio with cab.
Driver Assistance
Hydraulic Controls:
Draft and position control for the 3-point hitch for consistent implement depth.
Monitoring:
Gauges for temperature, oil pressure, fuel, and tachometer.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 200 hours or 12 months, whichever comes first.
Transmission Oil:
Check every 500 hours; replace per maintenance schedule.
Hydraulic Oil:
Check level daily; replace filter per schedule, usually 1000 hours.
Coolant:
Replace every 3 years or 3000 hours.
Air Filter:
Service or replace as per maintenance indicator; typically every 500 hours.
Fluid Specifications
Engine Oil:
SAE 15W-40 API CI-4 or newer, specified amount.
Transmission/Hydraulic Oil:
Case IH Hy-Tran Ultra or equivalent as specified.
Coolant:
Ethylene glycol-based, with SCA extenders as per Case IH specs.
Known Issues
Common Wear Items:
Injector nozzles, water pump seals, and kingpin bushings may wear with high hours.
Common Repairs:
Engine overhaul, clutch replacement, and hydraulic valve leaking are reported.
📚 Vehicle History
Brand Heritage
Manufacturer:
Case IH, formed by merger of Case and International Harvester (IH) in 1985.
Heritage:
Case roots go to 1842; IH roots to 1831. Strong reputation for durability.
Model Evolution
Model Series:
5130 belongs to the Case IH 5100/5200 series produced in the 1990s.
Predecessor:
Replaced the earlier 1055 and 1355 models (in some markets).
Successor:
Replaced by the Case IH MX Magnum series (in some markets) or later models like the JX series.
Production Location
Assembly Plant:
Manufactured in Racine, Wisconsin, USA or in Doncaster, UK (depending on market).
🏆 Awards & Recognition
Recognition
Awards:
N/A - no specific awards listed for this model in official records.
Industry Reception:
Well-regarded among farmers for reliability and dealer support within the Case IH network.
