🏷️ Basic Information

Make:

Mazda

Model:

CX-5

Year:

2017

Generation:

KF

👋 Introduction

Positioning:

The 2017 Mazda CX-5 represents the second generation (KF) of Mazda's popular compact crossover SUV. It aimed to offer a premium driving experience with its 'Kodo' design language and 'Skyactiv' technology, competing against established players like the Honda CR-V, Toyota RAV4, and Nissan Rogue.

Key Differentiators:

Key selling points included its engaging driving dynamics, refined interior, and advanced safety features, distinguishing it from some competitors that prioritized pure utility or fuel economy.

Manual Value Proposition:

This manual provides dealership-level technical information, enabling owners and independent mechanics to perform maintenance, diagnostics, and repairs with accuracy and efficiency, thereby saving time and money compared to relying solely on dealerships or less detailed guides.

Manual Format Advantage:

The single PDF format eliminates the need to flip through multiple physical books, offering a streamlined and efficient user experience. Users can bookmark pages and create their own digital index.

📋 Manual Details

Model Variants Covered:

All CX-5 models for the 2017 model year, including all engine options, drivetrain configurations (FWD/AWD), and trim levels.

Estimated Page Count:

Likely over 2000 pages based on typical comprehensive service manuals for this class of vehicle, though specific count not provided.

Type:

Complete Workshop Service Repair Manual

Language:

English

Digital Format:

PDF

Software Requirements:

Requires Adobe PDF Reader and WinZip (or equivalent extraction utility), both freely available online.

📖 Manual Coverage

Powertrain:

Engine mechanical, engine control system, fuel service, emission control, intake, exhaust, cooling, lubrication, ignition, starting, charging, automatic transmission, manual transmission, transfer case, propeller shaft, drive shafts, differential, axles.

Chassis:

Suspension (front and rear), steering column, power steering, wheels, tires, brake control, brake system (front and rear), parking brake.

Electrical And Body:

Air conditioning, supplemental restraint system (SRS), seat belts, engine immobilizer, cruise control, wiper and washer systems, door locks, meter/audio/visual systems, horn, windshield/glass/mirrors, instrument panel, seats, engine hood/doors, exterior and interior trim, general electrical systems, multiplex communication (CAN bus).

Body And Exterior:

Body construction, exterior trim, doors, hood, liftgate, bumpers, glass, mirrors, lighting systems.

Interior And Comfort:

Seats, seat belts, airbags, interior trim, climate control system (HVAC), dashboard, instrument panel, steering wheel, pedals.

Repair And Diagnostics:

Step-by-step repair instructions, detailed diagnostic procedures, troubleshooting guides for various systems, wiring schematics, diagnostic trouble code (DTC) explanations.

Maintenance And Adjustment:

Preventive maintenance schedules, fluid specifications and capacities, lubrication points, adjustments for various components, filter replacement procedures.

Electrical Diagnostics:

Detailed wiring diagrams for all electrical systems, diagnostic procedures for circuits, component testing, and troubleshooting of common electrical faults.

Engine Rebuild:

Complete engine overhaul procedures, including disassembly, inspection, component replacement, torque specifications for critical fasteners, and reassembly.

Body Repair:

Procedures for dent repair, panel replacement, alignment, and repair of structural components.

Depth:

Comprehensive factory-level detail, suitable for professional technicians and advanced DIYers. Covers everything from routine maintenance to complex component overhauls and electrical diagnostics.

Diagnostics Tools:

References and guidance on using diagnostic scan tools, understanding generic OBD-II codes and manufacturer-specific diagnostic trouble codes (DTCs).

Special Tools:

Details on any specialized tools or equipment required for specific repairs or diagnostic procedures.

📊 Manual Specifications

Compatibility:

Compatible with all versions of Windows and macOS.

Searchability:

PDF format allows for keyword searching, enabling quick access to specific information.

Printability:

All pages are printable, allowing users to print specific sections or the entire manual as needed. Allows for enlargement of images and diagrams.

Binding:

Digital PDF format (no physical binding).

Paper Quality:

N/A (Digital format). User can print on preferred paper type.

⚙️ Engine Specifications

Engine Code Usdm:

The primary engine for the US market was the PE-VPS, a 2.5L naturally aspirated inline-4 cylinder engine.

Horsepower And Torque:

The 2.5L PE-VPS engine typically produced around 184 horsepower and 185 lb-ft of torque. (Exact figures may vary slightly by market and specific tuning).

Injection Type:

Direct Injection (with S-VT - Variable Valve Timing).

Skyactiv-G Technology:

The 2.5L engine is part of Mazda's SKYACTIV-G family, featuring technologies aimed at improving efficiency and performance, such as high compression ratios and lightweight construction.

🔧 Transmission

Transmission Type:

A 6-speed SKYACTIV-DRIVE automatic transmission was standard or widely available.

Manual Transmission Availability:

While less common in the US market for this generation, a 6-speed manual transmission might have been an option in certain regions or specific trims.

Transmission Features:

The SKYACTIV-DRIVE automatic transmission was designed to offer a balance of fuel efficiency and responsive performance, mimicking a traditional torque converter automatic with some of the direct feel of a dual-clutch transmission.

Lock-Up Clutch:

The SKYACTIV-DRIVE transmission incorporates a lock-up clutch that engages at lower speeds than conventional automatics, reducing slippage and improving fuel economy.

📐 Dimensions

Length:

Approximately 179.1 inches (4549 mm).

Width:

Approximately 72.4 inches (1839 mm).

Height:

Approximately 65.3 inches (1659 mm).

Curb Weight:

Curb weight varied by trim and drivetrain, generally ranging from approximately 3,430 lbs (1556 kg) for FWD models to over 3,600 lbs (1633 kg) for AWD models.

Wheelbase:

Approximately 106.3 inches (2700 mm).

🛡️ Safety Features

IIHS Top Safety Pick:

The 2017 Mazda CX-5 achieved IIHS Top Safety Pick+ ratings when equipped with specific front crash prevention systems, highlighting its strong structural integrity and advanced safety technologies.

Driver Assistance Systems:

Available features included: Blind Spot Monitoring (BSM), Rear Cross Traffic Alert (RCTA), Smart City Brake Support (SCBS), Lane Departure Warning System (LDWS), Lane Keep Assist System (LKAS), Radar Cruise Control (MRCC), High Beam Control (HBC).

Airbag System:

Comprehensive airbag system including: front dual-stage airbags, front side-impact airbags, side-curtain airbags (front and rear), and potentially a driver's knee airbag.

💡 Technology Features

Infotainment System:

The 2017 CX-5 featured the Mazda Connect infotainment system, controlled via a rotary dial and buttons on the center console, along with voice commands. It typically included a 7-inch touchscreen display, Bluetooth connectivity, USB/aux inputs, and optional navigation.

Apple Carplay Android Auto:

Apple CarPlay and Android Auto were not standard features on the 2017 CX-5 but may have become available via software updates or aftermarket solutions for later production runs.

Adas Suite:

Equipped with Mazda's i-ACTIVSENSE suite of advanced driver-assistance systems (as listed in safety section), designed to enhance safety and driver awareness.

Connectivity Options:

Standard Bluetooth for hands-free calling and audio streaming, USB and auxiliary inputs for external devices. SiriusXM satellite radio was often an option.

🔧 Maintenance

Oil Change Interval:

Typically recommended every 7,500 miles or 12 months, whichever comes first, under normal driving conditions. Severe driving conditions may require shorter intervals. Refer to the manual for specific severe service definition.

Tire Rotation Interval:

Recommended every 5,000 to 7,500 miles.

Engine Oil Type And Viscosity:

Typically requires SAE 0W-20 synthetic engine oil meeting API SN/ILSAC GF-5 specifications. Specific oil capacity is approximately 4.8 US quarts (4.5 liters) for the 2.5L engine.

Transmission Fluid Type:

For the SKYACTIV-DRIVE automatic transmission, Mazda ATF-FZ is the specified fluid. It is crucial to use only this specific fluid to avoid damage.

Coolant Type:

Mazda FL22 Long Life Antifreeze/Coolant (or equivalent blue-colored Asian vehicle coolant).

Brake Fluid Type:

DOT 3 or DOT 4 brake fluid.

Power Steering Fluid Type:

Typically uses a specific Mazda power steering fluid or a universal synthetic power steering fluid that meets specified compatibility requirements.

Common Minor Concerns:

Some owners have reported issues with infotainment system glitches or connectivity problems, and occasional minor wind noise at higher speeds. Carbon buildup on intake valves can occur in direct-injection engines over time, though typically not a major concern until higher mileage.

Potential Wear Items:

Brake pads and rotors, tires, suspension components (bushings, shocks/struts) are typical wear items. The battery life should also be monitored.

📚 Vehicle History

Mazda Philosophy:

Mazda's heritage is rooted in producing engaging and fun-to-drive vehicles, often with innovative engineering like its rotary engines. For its modern lineup, the 'Jinba-Ittai' (horse and rider as one) philosophy emphasizes a connected driving experience.

Cx-5 Development:

The CX-5 was Mazda's first vehicle to fully embody the Kodo design language and incorporate the full suite of SKYACTIV technologies, introduced globally in 2012. The 2017 model represents the second generation, featuring significant updates in styling, interior refinement, and technology.

Manufacturing Locations:

Key manufacturing plants for the 2017 CX-5 included Mazda's Hofu Plant in Japan, and assembly facilities in other regions depending on market demand, such as in Mexico for North American markets.

🏆 Awards & Recognition

IIHS Recognition:

As mentioned, earned IIHS Top Safety Pick+ designation in 2017 when properly equipped with optional safety features.

Kbb Best Buy:

The CX-5 lineup, including the 2017 model, has often been recognized by publications like Kelley Blue Book for its value and overall excellence in the compact SUV segment.

Consumer Reports Ratings:

Generally received good to excellent ratings from automotive critics and consumer organizations for its driving dynamics, interior quality, and fuel economy. Predicted reliability was often rated above average.
