Vehicle Segment:
Kei truck/van segment, known for utility, fuel efficiency, and compact size, popular in commercial and rural applications
Competitors:
Competes with other Japanese manufacturers' kei vehicles such as the Honda Acty, Subaru Sambar, and Mitsubishi Minicab
Utility:
Designed for practicality and cargo hauling, often featuring a flatbed or enclosed van body
Compact Size:
Benefits from Kei car regulations in Japan, offering maneuverability in tight spaces and lower running costs
Benefit To Owner:
Empowers owners and technicians to perform comprehensive maintenance, diagnostics, and repairs, extending vehicle life and ensuring optimal performance
Engine Mechanical:
Complete disassembly, assembly, repair, and adjustment of all internal engine components (pistons, rings, bearings, crankshaft, camshaft, valves, etc.)
Engine Management:
Fuel injection system, ignition system, emissions control, ECU diagnostics, sensor testing and replacement
Transmission Manual:
Removal, installation, disassembly, assembly, and adjustment of manual transmissions, including clutch system
Transmission Automatic:
Removal, installation, disassembly, assembly, and adjustment of automatic transmissions (if applicable to specific models within the year range)
Drivetrain:
Driveshafts, differentials, axles, hubs, and wheel bearings
Suspension:
Front and rear suspension components, shock absorbers, springs, control arms, ball joints, bushings
Steering:
Steering column, steering rack/gearbox, tie rods, power steering system (if equipped)
Brakes:
Brake system diagnosis, front and rear brake components (discs, drums, calipers, pads, shoes), hydraulic system, parking brake
Electrical System:
Wiring diagrams, battery, alternator, starter motor, lighting system, fuses, relays, control modules
Body And Chassis:
Body panel removal/installation, doors, hoods, bumpers, interior trim, chassis component inspection
Heating And Air Conditioning:
HVAC system components, refrigerant circuits, blower motor, controls
Comfort Features:
Power windows, door locks, wipers, washers, horn, instrumentation
Maintenance:
Regular maintenance procedures, fluid changes, filter replacements, spark plug replacement, brake checks, tire rotation
Troubleshooting:
Diagnostic procedures for common problems, symptom-based troubleshooting guides, fault code interpretation
Repair:
Detailed step-by-step instructions for repairing and replacing all vehicle components
Disassembly Assembly:
Comprehensive guides for dismantling and reassembling all major systems and components
Adjustments:
Precise instructions for adjusting critical components such as engine idle speed, ignition timing, brake adjustments, clutch free play
Depth:
Comprehensive, bumper-to-bumper coverage suitable for both professional mechanics and experienced DIY enthusiasts
Detail Level:
Includes detailed illustrations, exploded diagrams, pictorial diagrams, and specific service tool references
Specifications:
Provides essential service data, factory specifications, allowable limits, and tightening torques for all components
Engine Code Typical:
F6A (657cc, 3-cylinder, SOHC, naturally aspirated or turbocharged)
Engine Code Alternative:
K6A (658cc, 3-cylinder, DOHC, VVT, naturally aspirated or turbocharged) - introduced later in the generation
Horsepower Range Na:
Approx. 40-50 HP for naturally aspirated variants
Horsepower Range Turbo:
Approx. 55-65 HP for turbocharged variants
Torque Range:
Approx. 50-60 lb-ft for naturally aspirated, up to 70-80 lb-ft for turbocharged
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline
Cooling Method:
Liquid-cooled
Oil Type Specification:
API SG or higher, SAE 10W-30 or 10W-40 recommended (refer to manual for exact specifications)
F6A Features:
Compact design, reliable, available in naturally aspirated and turbocharged versions, often with intercooler for turbo variants
Transmission Type Standard:
5-speed Manual Transmission
Transmission Type Optional:
3-speed Automatic Transmission (less common on some utility variants)
Drive Layout:
Rear-Wheel Drive (RWD) standard, with optional 4-Wheel Drive (4WD) available on many models
Manual Transmission Fluid:
API GL-4, SAE 75W-90 or 80W-90 gear oil (refer to manual for specific fill levels and types)
Automatic Transmission Fluid:
Dexron III or equivalent (if equipped with automatic transmission)
Length:
Varies by body style, typically around 3,200-3,400 mm for utility variants (within Kei regulations)
Width:
Varies by body style, typically around 1,400-1,500 mm (within Kei regulations)
Height:
Varies by body style, typically around 1,800-1,900 mm for van variants
Curb Weight:
Approx. 700-900 kg, depending on configuration (2WD/4WD, van/truck)
Gross Vehicle Weight Rating Gvw:
Typically around 1,500-1,800 kg
Oil Change Interval:
Every 5,000-10,000 km or 6-12 months, depending on driving conditions (refer to manual)
Air Filter Replacement:
Every 20,000-30,000 km or as needed based on inspection
Spark Plug Replacement:
Every 30,000-60,000 km (depending on plug type, check manual)
Coolant Type:
Ethylene glycol-based coolant, pre-mixed or concentrate (refer to manual for specific type and mixture ratio)
Brake Fluid Type:
DOT 3 or DOT 4 (refer to manual for specific type)
Engine Oil Capacity:
Approx. 2.7 - 3.2 liters (including filter, refer to manual)
Common Wear Items:
Clutch wear, suspension bushings, exhaust system corrosion, engine mounts, ignition components (distributor cap/rotor on older models)
Common Electrical:
Corrosion on electrical connectors, aging wiring harness components
Importance Of Routine:
Adherence to the periodic maintenance chart in the manual is crucial for maximizing longevity and reliability
