🏷️ Basic Information

Make:

Land Rover

Model:

Discovery Series II

Platform Code:

LT95

Generation Name:

Series II

Production Years Covered By Manual:

1998-2004 (primarily 1999 onwards)

👋 Introduction

Vehicle Segment:

Premium Mid-size SUV / Off-road Vehicle

Target Audience:

Individuals seeking a capable, robust, and versatile SUV for on-road and off-road use, often with a focus on adventure and utility.

Key Competitors:

Jeep Grand Cherokee, Toyota Land Cruiser Prado, Mercedes-Benz M-Class, BMW X5, Nissan Pathfinder.

Distinguishing Features:

Permanent 4WD, sophisticated electronic traction control (HDC, TC), optional ACE (Active Cornering Enhancement) suspension system, powerful diesel and V8 engine options, robust construction.

Manual Advantage:

Provides in-depth technical knowledge that mirrors that of dealership technicians, enabling owners to perform complex repairs and maintenance themselves, saving significant costs.

📋 Manual Details

Coverage Scope:

Comprehensive workshop manual covering maintenance, servicing, diagnosis, and repair.

Engine Variants Covered:

Td5 Diesel, V8 Petrol

Transmission Variants Covered:

R380 Manual Gearbox, ZF4HP22/24 Automatic Gearbox

Chassis Systems Covered:

Front Axle, Rear Axle, Steering, Suspension, Brakes, Wheels and Tyres, Transfer Box (LT230SE)

Electrical Systems Covered:

Comprehensive electrical schematics and diagnosis for both Td5 and V8 models.

Body And Interior Covered:

Air Conditioning, Body and Trim, Restraint System, Heater.

Estimated Page Count:

Likely several thousand pages, typical for a complete FSM.

Manual Type:

Factory Service Manual (FSM) / Workshop Manual

Language:

English

Digital Format:

PDF

Delivery Method:

Download (RAR archive)

📖 Manual Coverage

Engine Mechanical:

Complete disassembly, inspection, repair, and reassembly of Td5 and V8 engines.

Engine Lubrication And Cooling:

Oil pump, lubrication circuits, radiator, coolant pump, thermostat, cooling fan operation.

Fuel And Emission Control:

Fuel pump, injectors, fuel lines, evaporative emissions system, exhaust systems.

Transmission And Drivetrain:

Clutch system (Td5), R380 manual gearbox, ZF4HP22/24 automatic gearbox, transfer box (LT230SE), propeller shafts, differentials.

Suspension And Steering:

Front and rear suspension components, springs, dampers, anti-roll bars, steering rack, power steering system.

Braking System:

Hydraulic system, ABS, brake discs, pads, calipers, fluid specifications, bleeding procedures.

Electrical System:

Wiring diagrams, battery, charging system, starter, lighting, instrument cluster, ECUs, sensors, actuators.

Climate Control:

Air conditioning system components, operation, diagnosis, and refrigerant handling.

Routine Maintenance:

Oil changes, filter replacements, fluid level checks, brake inspections, belt inspections.

Diagnostic Procedures:

Troubleshooting guides, fault code interpretation (if OBD-II supported), symptom-based diagnosis.

Repair And Rebuild:

Detailed steps for component removal, repair, installation, and adjustment for all major systems.

Special Tools And Equipment:

Identification and usage of specific tools required for certain procedures.

Electrical Component Testing:

Testing of sensors, actuators, wiring continuity, and electrical component function.

Depth Of Coverage:

Factory-level diagnostic and repair procedures, suitable for professional technicians and advanced DIY enthusiasts.

Diagnostic Complexity:

Includes troubleshooting trees, component resistance values, voltage checks, and signal waveforms where applicable.

Rebuild Detail:

Provides torque specifications, clearances, and assembly sequences for engine, transmission, and axle rebuilds.

📊 Manual Specifications

File Type:

RAR Archive

Required Software:

WinRAR or compatible archive utility

PDF Quality:

Assumed high-quality, with searchable text and clear diagrams as per FSM standards.

Binding:

N/A (Digital Download)

Paper Quality:

N/A (Digital Download)

⚙️ Engine Specifications

Engine Name:

Td5

Configuration:

2.5L Inline 5-cylinder Turbocharged Diesel

Power Output Td5:

Approximately 136 hp (101 kW) at 4200 rpm

Torque Output Td5:

Approximately 300 Nm (221 lb-ft) at 1900 rpm

Engine Name:

V8

Configuration:

4.0L or 4.6L V8 Petrol (Rover).

Power Output V8:

4.0L: ~188 hp (140 kW), 4.6L: ~224 hp (167 kW)

Torque Output V8:

4.0L: ~340 Nm (251 lb-ft), 4.6L: ~400 Nm (295 lb-ft)

Td5 Fuel System:

Direct injection, electronically controlled rotary distributor fuel injection pump.

V8 Fuel System:

Multi-point fuel injection (MPI).

🔧 Transmission

Manual Gearbox:

R380 5-speed manual transmission.

Automatic Gearbox:

ZF 4HP22/24 4-speed automatic transmission.

Transfer Case Model:

LT230SE (with electronic locking differential on some models).

Transfer Case Features:

Permanent four-wheel drive with high/low range selectable gearing, center differential locking capability.

📐 Dimensions

Wheelbase:

Approx. 2545 mm (100.2 inches)

Length:

Approx. 4708 mm (185.4 inches)

Width:

Approx. 1889 mm (74.4 inches)

Height:

Approx. 1949 mm (76.7 inches)

Curb Weight:

Varies by engine and trim, approx. 2000-2200 kg (4400-4850 lbs)

Gross Vehicle Weight Rating:

Varies, typically around 2800-3000 kg (6170-6615 lbs)

🛡️ Safety Features

Crash Test Data Availability:

Limited publicly available standardized crash test data for this specific generation from major agencies like NHTSA/Euro NCAP compared to modern vehicles.

Traction Control:

Standard on all models, utilizing ABS sensors to manage wheel slip.

Hill Descent Control:

Standard, enabling controlled descent on steep gradients.

Airbags:

Driver and front passenger airbags. Side airbags available on some higher trims.

Seatbelts:

Three-point seatbelts with pretensioners for front occupants.

💡 Technology Features

Audio System:

Various radio/cassette or radio/CD players, often with optional premium sound systems.

ABS:

Anti-lock Braking System standard.

Hdl:

Hill Descent Control standard.

Ace System:

Active Cornering Enhancement (optional) uses hydraulic cylinders to counteract body roll in corners, significantly improving on-road handling.

OBD Port:

Typically OBD-II compliant, allowing for basic diagnostic scanning.

🔧 Maintenance

Oil Change Interval:

Typically every 10,000 miles or 12 months, whichever comes first. Check manual for specific engine variant.

Timing Belt Replacement:

Not applicable for Td5 (timing chain). V8 engines use a timing chain, generally considered maintenance-free unless symptoms arise.

Coolant Flush Interval:

Approximately every 3-5 years or 60,000 miles.

Engine Oil Td5:

API CD/CE/CF or ACEA B2/B3, SAE 15W-40 or 10W-40.

Engine Oil V8:

API SJ/SL or ACEA A2/A3, SAE 10W-40 or 20W-50 depending on climate and wear.

Automatic Transmission Fluid:

ZF TE-ML 14A (or equivalent specification, e.g., Esso LT 71141, Castrol TQ Dexron III).

Brake Fluid:

DOT 4.

Common Td5 Issues:

Injector harness failure, fuel pump relay issues, head gasket sealing, EGR valve clogging.

Common V8 Issues:

Head gasket leaks (especially 4.0L), coolant leaks from 'plastic' intake manifold, viscous fan coupling failure.

Chassis And Suspension Issues:

Slipping ECU (often located under driver's seat), Active Cornering Enhancement (ACE) system leaks or failures, differential wear, driveshaft universal joint wear.

📚 Vehicle History

Land Rover Legacy:

Land Rover has a long-standing reputation for producing robust, off-road capable vehicles with a focus on durability and go-anywhere ability.

Discovery Lineage:

The Discovery Series II built upon the success of the original Discovery (1989-1998), introducing significant updates to chassis, suspension, and technology while retaining its core off-road prowess.

Manufacturing Location:

Solihull, United Kingdom.

🏆 Awards & Recognition

Off Road Awards:

While specific awards for the Series II are less documented than for newer models, Land Rover vehicles consistently perform well in off-road capability tests and reviews.
