Model Years Covered:
2007, 2008, 2009, 2010, 2011
Generation:
First Generation (2007-2012)
Platform:
Chrysler KA/KE (shared with Dodge Caliber, Jeep Compass, Jeep Patriot)
Vehicle Segment:
Compact/Mid-size SUV
Target Audience:
Off-road enthusiasts, families, individuals seeking a versatile utility vehicle
Key Competitors:
Jeep Cherokee (KK), Ford Edge, Chevrolet Equinox, Toyota RAV4, Honda CR-V
Vehicle Design:
Rugged exterior styling, boxy profile, upright stance, distinctive grille
Manual Value Proposition:
Empowers owners and technicians with detailed information to perform repairs and maintenance effectively, saving on labor costs.
Engine Mechanical:
Engine overhaul, assembly, disassembly, lubrication, cooling, fuel system, ignition, exhaust
Engine Electrical:
Engine control systems, sensors, actuators, diagnostics
Transmission Manual:
Manual transmission repair, clutch system, driveline
Transmission Automatic:
Automatic transmission repair, torque converter, electronic controls
Drivetrain AWD:
All-Wheel Drive system (if applicable to specific Nitro models) servicing
Brakes:
Brake system diagnostics, repair, ABS, parking brake
Steering:
Power steering system, steering column, tie rods, alignment
Suspension:
Front and rear suspension components, shocks, struts, springs, control arms
Electrical Body:
Body electrical systems, lighting, power accessories, body control modules
HVAC:
Heating, Ventilation, and Air Conditioning (HVAC) system diagnosis and repair
Body Interior:
Interior trim, seating, airbags, dashboard components
Body Exterior:
Body panels, doors, bumpers, glass, seals, exterior trim
Wiring Diagrams:
Comprehensive wiring schematics for all major electrical systems
Maintenance Procedures:
Scheduled maintenance, fluid changes, filter replacements, inspections
Repair Procedures:
Step-by-step repair instructions for all major components and systems
Troubleshooting:
Diagnostic flowcharts and troubleshooting guides for common and complex issues
Overhaul Procedures:
Detailed instructions for complete engine and transmission rebuilds
Diagnostics:
On-Board Diagnostics (OBD-II) information, diagnostic trouble codes (DTCs)
Depth Of Information:
Suitable for professional technicians and advanced DIY enthusiasts
Diagnostic Tools:
References diagnostic tools and procedures for accurate fault identification
Printability:
Full Printable (allows printing of specific sections)
Zoom Functionality:
Zoom IN/OUT enabled for detailed viewing
Binding Type:
Digital (No physical binding)
Paper Type:
Digital (N/A)
Operating Systems:
Compatible with all versions of Windows & Mac
Software Requirements:
Adobe PDF Reader & WinRAR
Engine Option 1:
2.8L VM Motori Turbo Diesel (R428 DOHC)
Engine Option 2:
3.7L Chrysler PowerTech V6 (SOHC)
Engine Option 3:
4.0L Chrysler PowerTech V6 (SOHC)
Engine Option 4:
3.5L High Output V6 (shared with Jeep Grand Cherokee)
Horsepower Range:
Approximately 177 hp (2.8L Diesel) to 260 hp (4.0L V6)
Torque Range:
Approximately 334 lb-ft (2.8L Diesel) to 265 lb-ft (3.7L V6)
Fuel Delivery:
Multi-point fuel injection (MPI) for gasoline engines, Common Rail Direct Injection (CRDI) for diesel
Transmission Option 1:
6-speed Manual Transmission (NSG 370 for some models)
Transmission Option 2:
4-speed Automatic Transmission (45RFE for 3.7L V6)
Transmission Option 3:
5-speed Automatic Transmission (NAG1/722.6 for 3.5L HO and 4.0L V6)
Drivetrain Configurations:
Rear-Wheel Drive (RWD), Select-able 4-Wheel Drive (4WD)
NHTSA Front Driver Side Impact:
5 Stars (for 2007 model)
NHTSA Front Passenger Side Impact:
5 Stars (for 2007 model)
IIHS Side Impact Rating:
Good (for models equipped with side airbags)
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Available Traction Control System (TCS)
Electronic Stability:
Available Electronic Stability Control (ESC)
Airbags:
Standard front airbags, optional front side-impact airbags, optional side-curtain airbags
Infotainment System:
Optional Boston Acoustics premium audio system, optional Uconnect hands-free communication system (availability varies by trim).
Driver Assistance Features:
Standard rearview mirror, optional rear parking assist.
Connectivity Options:
Auxiliary audio input jack (standard on most models), USB port (optional on some later models).
Oil Change Interval:
Every 3,000-6,000 miles or 3-6 months (depending on oil type and driving conditions)
Engine Air Filter:
Inspect every 15,000 miles, replace as needed
Cabin Air Filter:
Replace every 15,000-30,000 miles
Spark Plugs:
Replace at 100,000 miles (for most gasoline engines)
Engine Oil Type 3.7L V6:
SAE 5W-20, API SN or higher, meeting Chrysler MS-6395
Engine Oil Type 4.0L V6:
SAE 5W-20, API SN or higher, meeting Chrysler MS-6395
Transmission Fluid Automatic 45Rfe:
ATF+4 (Mopar P/N 05013457AA or equivalent)
Transmission Fluid Automatic Nag1:
MB-Approval 236.10 or 236.12 Automatic Transmission Fluid (e.g., Pentosin ATF1)
Coolant Type:
Chrysler HOAT (Hybrid Organic Additive Technology) Antifreeze/Coolant (Pink)
Common Problem 1:
Interior rattles and creaks due to less robust interior materials and construction.
Common Problem 2:
Rear differential leaks (especially on 4WD models).
Common Problem 3:
Water pump failures (often on V6 engines).
Common Problem 4:
Power steering pump noise or failure.
Common Problem 5:
ABS sensor failures, leading to ABS warning lights.
Dodge SUV Lineage:
Dodge's entry into the compact/mid-size SUV market, aiming to leverage a more rugged, lifestyle-oriented image.
First Generation Introduction:
Launched for the 2007 model year, based on the Dodge's 'Power Wagon' concept vehicle.
Mid-Cycle Updates:
Minor updates and feature shuffling across model years, but no major redesign within this generation.
Manufacturing Location:
Toluca, Mexico
Production Years For Manual:
2007-2011
